SECO-LARM SLI ENFORCER VIDEO EVT-PH16-4T2 Manual

ENFORCER 16-Port Passive Video Transceiver Hub Manual
TROUBLE SHOOTING
The screen is blank • Check that the CCTV camera is powered up.
• Check that the monitor is powered up.
• Check that the video cable connecting the camera to the hub is connected properly.
• Check that the cable(s) connecting the hub to the monitor, switcher, DVR, or multiplexer are
connected properly.
• Double-check the connections to any passive or active baluns.
The screen image is dim • Clean the camera lens (using a soft, clean cloth).
• Check that the camera light source is adequate.
• Clean the camera dome (if applicable).
• If the backlight control (BLC) DIP switch on the camera is set to OFF, try setting it to ON.
The screen image is dark • Check that the automatic electronic shutter (AES) DIP switch on the camera is turned OFF.
The screen image has poor contrast • Adjust the monitor's contrast knob.
• Change the position of the camera.
The screen image flickers • Change the position of the camera.
The screen image rolls • If multiple cameras are used, make sure the polarity of the power connections is consistent.
The screen image is distorted • (24VAC only) If more than one camera is attached to the same power source, adjust the other
camera's linelock sync.
• Change the position of the camera.
The camera case is hot • Check that the correct power supply is in use.
IMPORTANT: Users and installers of this product are responsible for ensuring this product complies with all national,
state, and local laws and statutes related to monitoring and recording audio and video signals. SECO-LARM will not be held
responsible for the use of this product in violation of any current laws or statutes.
WARNING: Incorrect mounting which leads to exposure to rain or moisture inside the enclosure could cause a
dangerous electric shock, damage the device, and void the warranty. Do not open the case of this device, as there are no
field-serviceable components inside.
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original consumer customer. Our obligation is limited to the
repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. For complete
details regarding the SECO-LARM warranty, please contact SECO-LARM.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right to
change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2005 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in
part, without the written permission of SECO-LARM.
