- Page 1 Range Hood HH-X6907GB...
-
Page 2: Table Of Contents
CONTENTS Safety and warnings Using your range hood Control panel Care and cleaning Troubleshooting Safety and warnings Parts supplied Product components Product dimensions Installation height Installation About your range hood Manufacturer’s Warranty IMPORTANT! SAVE THESE INSTRUCTIONS... -
Page 3: Safety And Warnings
SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. • Always disconnect the appliance from the mains power supply before carrying out any maintenance or repairs. Failure to do so can result in death, electric shock, fire or injury to persons. -
Page 4: Using Your Range Hood
USING YOUR RANGE HOOD It is recommend to turn on the range hood for a few minutes before cooking in order to establish air currents upward through the range hood. This will also enable hot air removal from your kitchen and keep the range hood surface cool. When heat, smoke, moisture, grease and cooking odours are produced, they will be carried outside instead of drifting into other rooms. -
Page 5: Control Panel
CONTROL PANEL Press to turn the range hood on/off. Power on/off switch to the low speed When turning the range hood off, the fan will and continue to run for 3 minutes. Press a second time to turn the fan off immediately. -
Page 6: Care And Cleaning
CARE AND CLEANING This rangehood should be cleaned regularly using a mild, liquid detergent and a clean soft cloth to avoid a build-up of grease occurring. Avoid the use of corrosive chemicals, abrasive cleaning products, hard brushes and steel wool pads. Grease deposits are corrosive which can cause damage. - Page 7 CARE AND CLEANING Impeller It is recommend to clean the impeller every 3 months by the authorized technicians. It may need to be cleaned more frequently depending on the cooking methods frequency of use. Do not clean the inside. Cleaning the fan will require two people to disassemble and reassemble the range hood. The fan should be removed and cleaned with hot soapy water.
-
Page 8: Troubleshooting
TROUBLESHOOTING If there is a problem with your rangehood, please check the following points before contacting your local trained and supported service technician or the Customer Care Centre. POSSIBLE CAUSES WHAT TO DO PROBLEM Check the power plug is properly Power supply plug is not plugged in or not properly connected. -
Page 9: Safety And Warnings
SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. Always disconnect the appliance from the • mains po wer supply before carrying out any maintenance or repairs. Failure to do so can result in death, electric shock, fire or injury to persons. - Page 10 SAFETY AND WARNINGS READ AND SAVE THESE INSTRUCTIONS WARNING! Please read the entire set of instructions before installing or using this appliance. Please make this information available to the person installing the appliance – doing so could reduce your installation costs. Always switch the power off prior to installation, servicing or cleaning of the appliance.
-
Page 11: Parts Supplied
ST3.9 x 13 (2) M4 x 12 (2) M4 x 10 (4) ST3.9 x 10 (4) Haier Warranty card Self-tapping Self-tapping Warranty card (1) screw ST3.9 x 8 (2) screw ST3.5 x 9.5 (2) -
Page 12: Product Components
PRODUCT COMPONENTS Range hood Lower duct cover Upper duct cover main housing Hand-tightened Impeller Volute Check valve Intake ring Oil cup assembly Oil filter NO-clean module... -
Page 13: Product Dimensions
PRODUCT DIMENSIONS PLAN FRONT PROFILE PRODUCT DIMENSIONS Maximum overall height of product 1320 Minimum overall height of product C Over all width of product D Over all depth of product Width of chimney Depth of chimney G Distance from centre of ducting outlet to back of product Distance from centre of ducting outlet to side of product... -
Page 14: Installation Height
INSTALLATION HEIGHT HEIGHT DIMENSIONS Ducted installation Minimum height 1320 Maximum height Height top of cooktop to base of product min 300 – max 350 Electric cooktop min 300 – max 350 Gas cooktop This rangehood must be installed no lower than the minimum height indicated in the table above. Minimum installation height may be greater if required by the cooktop, refer to your cooktop installation instructions. -
Page 15: Installation
Installation Use the supplied mounting screws and expansion plugs if attaching to concrete HANG RANGE HOOD or brick walls. Different fixings will be required for other types of wall construction. Central axis Upper duct cover bracket ① Lock screw Attach the rangehood to the wall bracket. Mounting bracket Ensure the rangehood and wall bracket are firmly locked together. -
Page 16: About Your Range Hood
ABOUT YOUR RANGE HOOD TECHNICAL DATA 2W x 1 Light bulbs Rated voltage: 220-240 V~ Type of power Rated frequency: 50 Hz 258 W Motor input power 260 W Rated input power 1500 m³/hr Air flow 2200 m³/hr Unrestricted air flow Maximum: 1100 Pa Air pressure Noise... -
Page 17: Manufacturer's Warranty
MANUFACTURER’S WARRANTY...
