Summary of Contents for dji CP.FP.00000020.02
- Page 1 Motion Controller User Manual v1.0 2021.03...
- Page 2 Searching for Keywords Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search. Navigating to a Topic View a complete list of topics in the table of contents.
-
Page 3: Using This Manual
Download the DJI Fly App Scan the QR code on the right to download DJI Fly. The Android version of DJI Fly is compatible with Android v6.0 and later. The iOS version of DJI Fly is compatible with iOS v11.0 and later. -
Page 4: Table Of Contents
Contents Using this Manual Legend Read Before the First Flight Download the DJI Fly App Download the DJI Virtual Flight App Download DJI Assistant 2 (DJI FPV series) Warnings Product Profile Introduction Diagram Operation Powering On/Off Charging Linking Activation Controlling the Aircraft... -
Page 5: Product Profile
Product Profile Introduction When used with the DJI FPV Goggles V2, the DJI Motion Controller provides an immersive and intuitive flying experience that allows users to easily control the aircraft using hand movements. Built into the DJI Motion Controller is DJI's O3 transmission technology, offering a maximum transmission range of 6 mi (10 km). The motion controller works at both 2.4 and 5.8 GHz and is capable of selecting the best transmission channel... - Page 6 For charging or connecting the motion controller to a computer to update firmware. 10. Power Button Press once to check the current battery level. Press once then again and hold to power the motion controller on or off. © 2021 DJI All Rights Reserved.
-
Page 7: Operation
The table below shows the battery level during charging. LED1 LED2 LED3 LED4 Battery Level 0% < Battery Level ≤ 50% 50% < Battery Level ≤ 75% 75% < Battery Level < 100% Fully charged © 2021 DJI All Rights Reserved. -
Page 8: Linking
Activation The DJI Motion Controller must be activated before using for the first time. Make sure all devices are linked after powering on the aircraft, goggles, and motion controller. Connect the USB-C port of the goggles to the mobile device, run DJI Fly, and follow the prompts to activate. - Page 9 Press the accelerator to fly in the direction of the circle in the goggles. Apply more pressure to accelerate. Release to stop and hover. © 2021 DJI All Rights Reserved.
- Page 10 The motion controller sounds an alert when the battery level is 6% to 15%. A low battery level alert can be cancelled by pressing the power button. A critical battery level alert will sound when the battery level is less than 5% and cannot be cancelled. © 2021 DJI All Rights Reserved.
-
Page 11: Controlling The Camera
The signal between the aircraft and the motion controller is most reliable when the motion controller is positioned in relation to the aircraft as shown below. Optimal Transmission Zone In order to avoid interference, DO NOT use other wireless devices on the same frequency as the motion controller. © 2021 DJI All Rights Reserved. -
Page 12: Goggles Screen
Goggles Screen The motion controller should be used with the DJI FPV Goggles V2, which give users a first-person view from the aerial camera with real-time video and audio transmission. 15min 15min 10min 10min Press Brake button to cancel RTH Low battery RTH 20.5km/h... - Page 13 Using the goggles does not satisfy the requirement of visual line of sight (VLOS). Some countries or regions require a visual observer to assist during flight. Make sure to comply with local regulations when using the goggles. © 2021 DJI All Rights Reserved.
-
Page 14: Appendix
Power on the aircraft, goggles, and motion controller. Make sure all the devices are linked. Connect the USB-C port of the goggles to the mobile device, run DJI Fly, and follow the prompt to update. An internet connection is required. -
Page 15: After-Sales Information
The firmware update will take approximately 5 minutes. Make sure the mobile device or the computer is connected to the internet. After-Sales Information Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and support. © 2021 DJI All Rights Reserved. - Page 16 DJI Support http://www.dji.com/support This content is subject to change. Download the latest version from https://www.dji.com/dji-fpv If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. © Copyright 2021 DJI All Rights Reserved.
