Mishimoto RTWRX08EBK Installation Manual

2008 2014 SUBARU WRX
—
ALUMINUM COOLANT EXPANSION TANK
PARTS LIST AND INSTALLATION GUIDE
PARTS INCLUDED
1PC | ALUMINUM EXPANSION TANK
1PC | MISHIMOTO RADIATOR CAP
MOUNTING HARDWARE
TOOLS NEEDED
12MM SOCKET
1/4" DRIVE RATCHET
FLATHEAD SCREWDRIVER
PHILLIPS SCREWDRIVER
INSTALL TIME 1.5 HOURS
INSTALL DIFFICULTY
DISCLAIMER
• Raise vehicle only on jack stands or on a vehicle lift.
• Allow vehicle to cool completely prior to attempting installation.
• Do not run the engine or drive the vehicle while overheating;
serious damage can occur.
• Please dispose of any liquids properly.
• Mishimoto is not responsible for any vehicle damage or
personal injury due to installation errors, misuse, or removal
of Mishimoto products.
• Mishimoto suggests that a trained professional install all
Mishimoto products.
CAUTION
Never work on the cooling system when it is hot. The coolant
temperature in the radiator can be considerably higher than
boiling, and the system may be under pressure. Opening a cooling
system that is hot or under pressure can result in serious injury.
Always wait until the system has cooled completely before
servicing it in any way.
18 BOULDEN CIRCLE, NEW CASTLE, DE 19720
MISHIMOTO |
NEEDLENOSE PLIERS
FUNNEL
MISHIMOTO LIQUID CHILL®
®
INSTALL PROCEDURE
01. Set the vehicle on an automotive lift, or raise it with a jack and
place it securely on jack stands. Refer to your owner's manual
for safe lifting points if you are unsure.
02. Remove the fi ve fasteners that secure the undertray, and then
remove the undertray. (3x 12mm bolts, 2x pop-clips)
03. Place a drain pan or bucket under the radiator petcock.
Loosen the petcock on the radiator to drain the coolant until
the expansion tank is empty. Remove the pressure cap from
the expansion tank to accelerate the draining process.
04. Tighten the petcock on the radiator once the coolant has
drained below the expansion tank.
CONTINUED ON FO LLOWING PAGE
