Air King RS Series Operating Manual

IMPORTANT INSTRUCTIONS -
RS Series
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN
THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY
INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY
WARNING:
ELECTRIC SHOCK AND INJURY TO PERSON, OBSERVE THE
FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer.If you have questions,
contact the manufacturer.
WARNING:
ELECTRIC SHOCK AND INJURY TO PERSON, OBSERVE THE
FOLLOWING:
b) When cutting or drilling into wall or ceiling, do not damage electrical wiring and other
hidden utilities.
d) Read all instructions before installing or using shell.
WARNING:
FIRE:
a) Never leave surface units unattended at high settings. Boilovers cause smoking and
greasy spillovers that may ignite. Heat oils slowly on low or medium settings.
b) Use proper pan size. Always use cookware appropriate for the size of the surface element.
INSTALLATION INSTRUCTIONS
SECTION 1
Preparing the Shell
1. Unpack shell from the carton and confirm that all pieces are present. In addition to the
shell you should have:
2 - #8 x 3/8 AB Screws
4 - #8 Mounting Screws
1 - Instruction/Safety Sheet
NOTE: Some shells may be shipped with a protective plastic adhered to the shell. It is
recommended to leave this in place during installation to protect the shell from scratching.
Remove when the installation is complete.
SECTION 2
Prepare the location for Shell Support
1. If the shell will be installed under cabinets that have a recessed bottom, it will be necessary
to install wood mounting strips (not included) so the shell will mount properly (Figure 2).
6728041 Rev. B 12-18
OPERATING MANUAL
AND/OR PROPERTY DAMAGE!
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL SAFETY INFORMATION
TO REDUCE THE RISK OF FIRE,
TO REDUCE THE RISK OF FIRE,
TO REDUCE THE RISK OF A RANGE TOP GREASE
SAVE THESE INSTRUCTIONS
a) SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn off
burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately,
EVACUATE AND CALL THE FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN - You may be burned.
c) DO NOT USE WATER, including wet dishcloths or towels -
a violent steam explosion will result.
d) Use an extinguisher ONLY if:
I. You know you have a Class ABC extinguisher, and you already know how to operate it.
II. The fire is small and contained in the area where it started.
III. The fire department is being called.
IV. You can fight the fire with your back to an exit.
Wood Strip
Figure 2
2. The thickness of the strips should be the same as the recess of the cabinet and they
should be approximately 2" wide.
3. Install the strips using appropriate length wood screws (not included). Make sure the
strips line up to the keyhole slots of the shell.
SECTION 3
Installing the Shell
1. Hold the shell up to the installation location and mark the locations of the mounting holes or
mark the locations by measurement.
www.airkinglimited.com
Range Hood
WARNING:
TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING:
1 of 2
