Barcelona
600 CFM/13.5 SONES @ 0.10" WG. HVI CERTIFIED 120 Volts, 2.8 amps, 60 hz.
• Dimensions
Available widths: 36"
• Hood Body
Brushed stainless steel.
• Motor
3 speed, permanently split capacitor motor. Rated 120 volts,
60 hz.
• Lighting
2 - Hi spot ES 16, 50 watt maximum halogen lights.
• Ducting Options
Vertical ducting:6" round duct adapter complete with polymetric
back draft damper ensuring quiet operation.
Ductless: Requiers charcoal filter
• Blower Wheel
Dual inlet, electronically balanced polymetric centrifugal blower
wheel.
• Mounting
Wall mounted. Install 20" to 30" from cooking surface.
• Filters
Grease Filter: Dishwasher safe, BCGF-01
• Available Finishes
Stainless Steel.
Air Flow - CFM
607
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
C
US
Specifications subject to change without notice.
®
Collection
(not included).
.
(included)
Static Pressure (inches of w.g.)
0
0.1
0.25
0.5
600
590
571
IN
RPM
WATTS
W.G.
Wall Mounted Range Hood
PERFORMANCE
0.75
1.0
1.5
549
523
456
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
NAVARRA
RANGE HOODS
NAV SERIES
6
"
5 / 8
8
5 / 8
28" to
41" Max
35
3 / 8
HVI Sones
Fan Speed
@ .1 SP
2.0
363
13.5
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
™
"
"
19
"
11 / 16
Power
RPM
Watts
2560
548
Updated 8-07
