Ricoh SG 3110DN
PowerDriver V4
INsTALLATION GUIDE
Windows 7 & 8
CAUTION
DO NOT INSTALL THE RICOH (OEM) INKS THAT WERE PROVIDED WITH THE PRINTER.
DO NOT POWER ON THE PRINTER BEFORE INSTALLING SAWGRASS SUBLIJET-R INK CARTRIDGES.
DURING DOWNTIME, IT IS HIGHLY RECOMMENDED TO LEAVE THE PRINTER POWERED ON TO ALLOW
CLEAR.
THE RICOH AUTOMATIC MAINTENANCE UTILITIES TO KEEP THE PRINT HEAD NOZZLES
v20140113
Advertisement
Related Manuals for Ricoh SG 3110DN
Summary of Contents for Ricoh SG 3110DN
-
Page 1: Installation Guide
Windows 7 & 8 CAUTION DO NOT INSTALL THE RICOH (OEM) INKS THAT WERE PROVIDED WITH THE PRINTER. DO NOT POWER ON THE PRINTER BEFORE INSTALLING SAWGRASS SUBLIJET-R INK CARTRIDGES. DURING DOWNTIME, IT IS HIGHLY RECOMMENDED TO LEAVE THE PRINTER POWERED ON TO ALLOW CLEAR. - Page 2 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation Select the appropriate language and click OK to continue (see FIGURE 7). FIGURE 7 Verify that the PowerDriver is for the correct printer. If so, click Next (see FIGURE 8).
- Page 3 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation If you agree with the terms of the License Agreement, click I Agree (see FIGURE 9). FIGURE 9 Click Install to allow PowerDriver to be installed into the correct destination folder (see FIGURE 10).
- Page 4 22. Once the download has complete the Ricoh OEM driver will be installed. You will need to accept the Software License Agreement for installation to continue. If you agree with the terms select I accept the agreement and click Next (see FIGURE 12).
- Page 5 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation Select Add a new printer and click Next (see FIGURE 13). FIGURE 13 Select how the printer is connected to your computer and click Next (see FIGURE 14). For this example we will select Connect USB cable.
- Page 6 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation The following screen will appear asking you to select your printer (see FIGURE 15). Highlight RICOH AficioSG3110DN RPCS-R and click Next. FIGURE 15 Ensure your printer is powered OFF and click Next to continue (see FIGURE 16).
- Page 7 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation Once the files are finished copying, ensure your printer is powered ON and the computer will begin auto- detecting the port (see FIGURE 17).
- Page 8 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation Click Set Now to continue (see FIGURE 19) FIGURE 19 Click OK to continue (see FIGURE 20). FIGURE 20 PAGE 10 of 15 >>...
- Page 9 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation Select No, restart later. Click Finish to continue PowerDriver installation (see FIGURE 21). FIGURE 21 The following screen may or may not appear. If it does, you will need to accept the software license terms for the installation to continue.
- Page 10 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation Once this portion of the installation is complete the following screen will appear. Click Close to continue (see FIGURE 23). FIGURE 23 Click Yes when prompted to Register the PowerDriver. A separate Registration window will appear (see FIGURE 24).
- Page 11 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation Take note of the Product ID number, it will be needed to register your software. Click the Obtain Registration Code button (see FIGURE 25).
- Page 12 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation When the email with the Registration Code is received, enter it into the Registration Code text box and click Apply Registration Code (see FIGURE 27).
- Page 13 SubliJet-R: Ricoh SG 3110DN – Installation Guide Step 1 of 2: PowerDriver V4 Download & Installation The following screen confirming that the driver settings have been initialized will appear. Click OK to continue (see FIGURE 29). FIGURE 29 You must restart your computer to complete the installation. Save and close any work that may be open and click Finish (see FIGURE 30).
