Quickplay PRO ALU MATCH Manual

Goal 3x2m
Hide thumbs Also See for PRO ALU MATCH:

Advertisement

Quick Links

Download this manual
3X2M
PRO ALU MATCH GOAL
@quickplay_sport / @quickplay_soccer
www.quickplaysport.com / www.quickplaysport.us
Customer service: info@quickplaysport.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO ALU MATCH and is the answer not in the manual?

Questions and answers

Related Manuals for Quickplay PRO ALU MATCH

Summary of Contents for Quickplay PRO ALU MATCH

  • Page 1 3X2M PRO ALU MATCH GOAL @quickplay_sport / @quickplay_soccer www.quickplaysport.com / www.quickplaysport.us Customer service: info@quickplaysport.com...

  • Page 2: Parts List

    PARTS LIST PARTS LIST AL3M-9 AL3M-10 Top Connector (2x) AL3M-1 Top Side Frame (2x) Crossbar (2x) AL3M-2 Upright (2x) AL3M-8 Diagonol Side Frame (2x) AL3M-4 F/F Basebar (1x) AL3M-6 AL3M-5 AL3M-7 M/F Basebar (1x) Bottom Side Frame (2x) Bottom Connector (2x) ALU-1 Crossbar Connector (1x) (1x)

  • Page 3: Handy Extras

    HANDY EXTRAS PARTS LIST Wrench Allen Key Ratchet with Sockets WARNING INFORMATION 1. Read through the instruction manual thoroughly before assembling the goal. 2. Check parts for any defects prior to the assembly of the goal. 3. Only use the goal on a flat surface. 4.

  • Page 4: Product Assembly

    PRODUCT ASSEMBLY HANDY EXTRAS PARTS LIST AL3M-1 Figure.1 (Figure 1) ALU-1 STEP 1 - Crossbar Layout the crossbar parts (AL3M-1) and crossbar AL3M-1 connector (ALU-1). Slide 2x M10x20 Bolts parts (A1) into parts (ALU-1) ensuring they are between the holes as per diagram. Slot the connector piece (ALU-1) into the (AL3M-1) ensuring the holes align STEP 2 - Crossbar (Figure 2)

  • Page 5: Detail View

    STEP 3 - Attach Crossbar to uprights AL3M-1 (Figure 3) Slide 4x M10x25 bolts (A1) into both corner joints (ALU-3) Figure.3 Attach the corner joints to the crossbar and uprights (AL3M-1, AL3M-2) ALU-3 ALU-3 AL3M-2 DETAIL VIEW STEP 4 - Fixing Crossbar to uprights (Figure 4) AL3M-1 Place the Right corner bracket (ALU-5)
  • Page 6 STEP 5 - Fixing Bottom brackets to uprights (Figure 5) Figure.3 lide 1x M10x25 Bolt (A1) into the base of both uprights (AL3M-2) Place the bottom brackets (ALU-6) onto the Uprights and ensure the (A1) bolt slots through the required hole on the bottom bracket.
  • Page 7 STEP 7 - Fix Basebar joints to side frames (Figure 7) Figure.7 lace the Basebar joint (ALU-7) over the unsecured M8x45 Bolts (B3) Secure each Basebar joint to the bottom side frame (AL3M-6) with an M8 lock nut (B2) ALU-7 AL3M-6 AL3M-7 Figure.8...
  • Page 8 STEP 9 - Side frames (Figure 9) Slot Basebar pieces (AL3M-4 & AL3M-5) together. The parts will need to be attached using the spring clips, to do this push on the spring clip and push the tubes together at the same time. (See diagram below) Figure.9 STEP 10 - Secure...
  • Page 9 STEP 12 - Attaching the Net Figure.12a Place the net over the frame, denote that ‘Top Corner’ tabs as per (Figure 12a). Attach net the to the frame using the net clips (NC-1). The push and twist technique is shown in the (Figure. 12b) Figure.12b NC-1...
  • Page 10 Figure.12c Secure the net along the Basebar, using the cable ties (CT -1), As per Figure. 12c, you may also wish to add cable ties to the side bars which may add more tension to your goal Cable ties Place each Cable tie CT-1 three net sqaures apart...
  • Page 11 Undo Cable ties connecting the net to the Basebar Undo securing pin from Basebar brackets, then remove Basebar. Fold Sidebars inwards 90 degrees towards the crossbar.
