Instructions for reversing the door
English
11. Install the freezer compartment door.
12. Remove the hole cover from the door bushing hole at the top left of the freezer door, then move the
door pin from the top right of the door to the top left of the door. Install the hole cover on the hole in the
pin hole at the top right of the door.
Passage hole cover
Door pin
Freezer door
13. Remove the plugs from the centre hinge screw holes on the left side of the freezer and install the
plugs in the screw holes on the right side of the freezer.
Plugs for screw holes
14. Install the centre hinge on the left side using the screws removed earlier.
Centre hinge spacer
Central hinge
Door pins
Screws
15. Remove the screw securing the door stops from the bottom of the refrigerator door, then remove the
door stops and install them on the lower left side.
Refrigerator door
Door stoppers
