Instructions for reversing the door
8. Install the pin bolt into the left hole and insert the pin shafts into the adjacent holes, then secure the
pin bolt with the washer and nut.
*** If your model uses bottom hinges, refer to the following steps:
Remove the pin shaft from the right-hand hole in the lower hinge.
9. Install the bottom hinge on the left side of the cabinet and install the adjustment foot on the right side
of the cabinet.
10. Remove the screw securing the door stops from the bottom right-hand side of the freezer
compartment door, then remove the door stops and install them on the bottom left-hand side.
Door stoppers
*** Some models use this type of door stops, please reverse them using the same method.
Pin shaft
Refrigerator door
Pin shaft
Pin screw
Pin shaft
Washer
Nut
Insert the pin shaft into the left hole of the
lower hinge.
42
