Summary of Contents for Samsung AM112KN4DCH
- Page 1 Air conditioner User manual AM✴✴✴KN4DCH • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this manual carefully and retain it for future reference. DB68-06062A-03...
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Power Smart Features Operation Features Operating temperature and humidity Cleaning and Maintenance Cleaning and Maintaining Cleaning the indoor unit exterior • Disassembling the air filter • Cleaning the air filter • Reassembling the air filter •... -
Page 3: Safety Information
If you have any questions, call your nearest contact centre or find help and information online at www.samsung.com. WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 4 Safety Information The installation of this appliance must be performed by a qualified technician or service company. • Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury. Install a switch and circuit breaker dedicated to the air conditioner. •...
- Page 5 CAUTION Install your appliance on a level and hard floor that can support its weight. • Failing to do so may result in abnormal vibrations, noise, or problems with the product. Install the draining hose properly so that water is drained correctly. •...
- Page 6 Safety Information FOR USING WARNING If the appliance is flooded, please contact your nearest service centre. • Failing to do so may result in electric shock or fire. If the appliance generates a strange noise, a burning smell or smoke, cut-off the power supply immediately and contact the nearest service center •...
- Page 7 After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. • If a child places a bag over its head, it may result in suffocation. Do not touch the front panel with your hands or fingers during the heating operation.
- Page 8 Safety Information CAUTION Do not place objects or devices under the indoor unit. • Water dripping from the indoor unit may result in fire or property damage. Check that the installation frame of the outdoor unit is not broken at least once a year.
- Page 9 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.Children should be supervised to ensure that they do not play with the appliance.
-
Page 10: At A Glance
Indoor Unit Overview Square panel Circular panel 01 Display NOTE • For the AR-KH0** wireless remote control, the air flow direction indications appear on its display, too. • By using the AR-KH0** wireless remote control, you can turn on or turn off the air flow direction indications that appear on the indoor unit display. -
Page 11: Power Smart Features
Operation Features Operating temperature and humidity Mode Outdoor temperature Indoor temperature Indoor humidity Cool mode 18°C to 32°C 80% or less Depends on the Heat mode specifications of the 27°C or less outdoor unit. Dry mode 18°C to 32°C 80% or less CAUTION •... -
Page 12: Cleaning And Maintenance
Cleaning and Maintaining Cleaning the indoor unit exterior Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe off dirt from odd-shaped areas by using a soft brush. CAUTION • Do not use alkaline detergent, sulphuric acid, hydrochloric acid, or organic solvents (such as thinner, kerosene, and acetone) to clean the surfaces. - Page 13 Cleaning the air filter NOTE • Clean the air filter once every two weeks. • Spray water or use a vacuum cleaner to remove dust. • After removing dust, dry the air filter completely. – Avoid direct sunlight. Failure to do so may deform the air filter. Reassembling the air filter After cleaning and reassembling the air filter, reset the filter-cleaning reminder as follows: •...
- Page 14 Cleaning and Maintaining Periodical maintenance Requires qualified Unit Maintenance item Interval technicians Clean the air filter. At least once a month Clean the condensate drain pan. Once a year Required Indoor Clean up the heat exchange. Once a year Required unit Clean the condensate drain pipe.
- Page 15 Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expense. Problem Solution The air conditioner does not operate • Because of the protective mechanism, the appliance does not start immediately operating immediately to keep the unit from overloading. The air after it has been conditioner will start in 3 minutes.
- Page 16 Cleaning and Maintaining Problem Solution • Check whether the batteries are discharged. Replace the batteries with new ones. The wireless • Make sure that nothing is blocking the remote control sensor. remote control • Check whether any strong lighting sources are near the air does not operate.
- Page 17 Problem Solution • In the Cool mode, cool air does not come out if the set temperature is higher than the current temperature. – AR-EH0**, AR-EC0** remote control: Press the Temperature button repeatedly until the set temperature (minimum: 18°C) is set to lower than the current temperature.
- Page 18 Cleaning and Maintaining Problem Solution • In certain conditions (especially, when the outdoor temperature is lower than 20°C), a hissing, rumbling, or splashing sound may be heard while the refrigerant is circulating through the air conditioner. The air conditioner This is a normal operation. makes strange noises.
-
Page 19: Technical Specifications
DIMENSIONS OF THE UNIT [WxHxD] 947 x 281 x 947 mm 947 x 281 x 947 mm COUNTRY OF ORIGIN MADE IN KOREA MADE IN KOREA MODEL AM112KN4DCH AM128KN4DCH AM140KN4DCH CLIMATE CLASS 220 - 240 V~ 220 - 240 V~ 220 - 240 V~ RATED VOLTAGE &... - Page 20 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 8002474357 (800 (08:00 ~ 20:00 HELP) From Inside Saudi Arabia www.samsung.com/sa_en/support (English) SAUDI ARABIA +966112614718 From outside Saudi Arabia (Call charges may be applied ) www.samsung.com/sa/support (Arabic) Digital services (24/7 HELP)
