- Page 1 Slim duct : AM✴✴✴✴NLD✴✴✴ AM022/028/036✴NMD✴✴✴ MA duct : AM✴✴✴✴NMD✴✴✴ HSP duct : AM✴✴✴✴NHD✴✴✴ Home duct : AM✴✴✴MNL✴✴✴ Air Conditioner user manual imagine the possibilities Thank you for purchasing this Samsung product. EN TR RU UK KK IN FR AR DB68-03871A-13...
- Page 2 Features of your new air conditioner Cool Summer Offer On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest. This summer, beat the heat with your own air conditioner.
-
Page 3: Table Of Contents
Contents Safety precautions ....................4 Viewing your air conditioner . -
Page 4: Safety Precautions
If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. Important safety symbols and precautions: Hazards or unsafe practices that may result in severe WARNING personal injury or death. - Page 5 FOR INSTALLATION WARNING Install a switch and circuit breaker dedicated to the air conditioner. X Failing to do so may result in electric shock or fire. Fix the outdoor unit firmly so that the electric part of the outdoor unit is not exposed. X Failing to do so may result in electric shock or fire.
- Page 6 Safety precautions FOR INSTALLATION CAUTION Install your appliance on a level and hard floor that can support its weight. X Failing to do so may result in abnormal vibrations, noise, or problems with the product. Install the draining hose properly so that water is drained correctly. X Failing to do so may result in water overflowing and property damage.
- Page 7 FOR USING WARNING If the appliance is flooded, please contact your nearest service center. X Failing to do so may result in electric shock or fire. If the appliance generates a strange noise, a burning smell or smoke, unplug the power plug immediately and contact your nearest service center.
- Page 8 Safety precautions FOR USING WARNING Do not turn the air conditioner off with the circuit breaker while it is operating. X Turning the air conditioner off and then on again with the circuit breaker may cause a spark and result in electric shock or fire. After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children.
- Page 9 FOR USING CAUTION Do not place objects or devices under the indoor unit. X Water dripping from the indoor unit may result in fire or property damage. Check that the installation frame of the outdoor unit is not broken at least once a year.
- Page 10 Safety precautions FOR USING CAUTION Do not apply a strong impact to the remote controller and do not disassemble the remote controller. Do not touch the pipes connected with the product. X This may result in burns or injury. Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or for any other unusual purposes.
- Page 11 FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner or alcohol to clean the appliance. X This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, unplug the air conditioner from the wall socket and wait until the fan stops.
-
Page 12: Viewing Your Air Conditioner
Viewing your air conditioner Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool or warm with optimal efficiency. Please read the user manual to get started and to make the best use of the air conditioner. Slim duct type Air filter (the return air side) Ceiling... -
Page 13: Using Your Air Conditioner
Using your air conditioner Tips on using air conditioner Here are some tips that you would follow when using your air conditioner. TOPIC RECOMMENDATION • If current outside temperatures are much higher than the selected indoor temperature, it may take time to bring the inner temperature to the desired coolness. - Page 14 Using your air conditioner TOPIC RECOMMENDATION • If both indoor and outdoor temperatures are high High indoor/ and the air conditioner is running in Heat mode, the outdoor outdoor unit’s fan and compressor may stop at times. temperatures This is normal; wait until the air conditioner turns on again.
-
Page 15: Cleaning And Maintaining The Air Conditioner
Cleaning and maintaining the air conditioner For the best performance from your air conditioner, clean it periodically. When cleaning, make sure to unplug from the unit for user’s safety. Cleaning the filter When cleaning the filter, make sure to unplug the power from the unit. Washable foam based Air filter captures large particles from the air. - Page 16 Cleaning and maintaining the air conditioner MA/HSP duct type 1. Slide out the Air filter on the rear side panel to the right side. 2. Clean the Air filter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with running water and dry it in a ventilated area.
- Page 17 MAINTAINING YOUR AIR CONDITIONER If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. 1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect the power plug.
- Page 18 Cleaning and maintaining the air conditioner Internal protections via the unit control system This internal protection operates if an internal fault occurs in the air conditioner. Type Description Against cold air The internal fan will be off to against cold air when the heat pump is heating. De-ice cycle The internal fan will be off to against cold air when the heat pump is heating.
-
Page 19: Appendix
Appendix Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION The air conditioner • Because of the protective mechanism, the does not operate appliance does not start operating immediately immediately after it to keep the unit from overloading. - Page 20 Appendix PROBLEM SOLUTION • Check if the air conditioner has just been turned on. If so, wait 3 minutes. Cool air does not come out to protect the compressor of the outdoor unit. • Check if the air conditioner is installed in a place with a direct exposure to sunlight.
- Page 21 PROBLEM SOLUTION • Check if the appliance is running in a smoky Odors permeate in area or if there is a smell entering from outside. the room during Operate the air conditioner in Fan mode or operation. open the windows to air out the room. • A bubbling sound may be heard when the refrigerant is circulating through the compressor.
- Page 22 Appendix PROBLEM SOLUTION The air conditioner does not turn on or • Check if you set the wired remote control for off with the wired group control. remote control. • Check if TEST indicator is displayed on the The wired remote wired remote control.
- Page 23 OPERATION RANGES The table below indicates the temperature and humidity ranges the air conditioner can be operated within. Refer to the table for efficient use. OPERATIONAL TEMPERATURE INDOOR MODE IF OUT OF CONDITIONS HUMIDITY INDOOR OUTDOOR Condensation may occur on the indoor COOLING 18 ~ 32°C -5 ~ 48°C...
-
Page 24: Instruction For Packing And Unpacking The Unit
Instruction for packing and unpacking the unit ► Packing the unit as below procedure 1. Put the indoor unit onto the Cushion Base. 2. Assemble Cushion Left and Cushion Right to the both sides of indoor unit. 3. Put the Packing Case from the top of set. 4. - Page 25 AM056FNLDEH/TK AM071FNLDEH/TK MODEL AM056KNLDEH/TK AM071KNLDEH/TK CLIMATES CLASS RATED VOLTAGE & FREQUENCY 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz COOLING 0.53 A 0.53 A 0.60 A 0.60 A RATED CURRENT HEATING (H1) 0.53 A 0.60 A COOLING 95.00 W 95.00 W...
- Page 26 Technical Specifications COUNTRY OF ORIGIN MADE IN CHINA MADE IN CHINA AM022FNMDEH/TK AM028FNMDEH/TK MODEL AM022KNMDEH/TK AM028KNMDEH/TK CLIMATES CLASS RATED VOLTAGE & FREQUENCY 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz COOLING 0.40 A 0.40 A 0.40 A 0.40 A RATED CURRENT HEATING (H1)
- Page 27 NET WEIGHT 41.5 kg 41.5 kg DIMENSIONS OF THE UNIT [W×H×D] 1300×295×690 mm 1300×295×690 mm COUNTRY OF ORIGIN MADE IN CHINA MADE IN CHINA AM045FNMDEH/TK AM056FNMDEH/TK MODEL AM045KNMDEH/TK AM056KNMDEH/TK CLIMATES CLASS RATED VOLTAGE & FREQUENCY 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz COOLING 1.15 A...
- Page 28 Technical Specifications COOLING 260.00 W 260.00 W 370.00 W 370.00 W RATED POWER INPUT HEATING (H1) 260.00 W 370.00 W COOLING HEATING (H1) NET WEIGHT 36.5 kg / 36.0 kg 48.5 kg / 48.5 kg DIMENSIONS OF THE UNIT [W×H×D] 1150×320×480 mm 1200×360×650 mm COUNTRY OF ORIGIN...
- Page 29 COOLING 2.24 A 2.24 A 0.25 A 0.25 A RATED CURRENT HEATING (H1) 2.24 A 0.25 A COOLING 485.00 W 485.00 W 30.00 W 30.00 W RATED POWER INPUT HEATING (H1) 485.00 W 30.00 W COOLING HEATING (H1) NET WEIGHT 57 kg / 50.5 kg 15.3 kg DIMENSIONS OF THE UNIT [W×H×D]...
- Page 30 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT U.A.E 800-SAMSUNG (800 - 726 7864) OMAN 800-SAM CS (800-72627) www.samsung.com/ae/support (English) KUWAIT 183-CALL (183-2255) www.samsung.com/ae_ar/support (Arabic) BAHRAIN 8000-GSAM (8000-4726) QATAR 800-CALL (800-2255) 08000-7267864 EGYPT www.samsung.com/eg/support 16580 ALGERIA 3004 TUNISIA 80 1000 12 www.samsung.com/n_africa/support...
