Texas Instruments TPSM82866AA0PEVM User Manual

www.ti.com
EVM User's Guide: TPSM82866AA0PEVM, TPSM82866CA3PEVM
TM
MagPack Technology 6A Power Module Evaluation
Module
Description
The TPSM82866AA0PEVM and
TPSM82866CA3PEVM evaluation modules
(EVM) facilitate the evaluation
of the TPSM82866AA0PRCFR and
TPSM82866CA3PRCFR, 6A pin-to-pin compatible
step-down power modules in a 2.3mm ×
3mm x 1.95mm MagPack
TPSM82866AA0PEVM provides an adjustable
output voltage down to 0.6V, with 1% accuracy
from input voltages from 2.4V to 5.5V. The
TPSM82866CA3PEVM provides an I
output voltage down to 0.8V, with 1% accuracy from
input voltages from 2.4V to 5.5V.
SLUUD38 – JUNE 2024
Submit Document Feedback
™ package. The
2
C adjustable
Copyright © 2024 Texas Instruments Incorporated
Features
• 6A output current power module with integrated
inductor in a MagPack package
• 2.3mm x 3mm power module provides 28mm
solution-size with 1.95mm height
• Excellent thermal performance (θ
• Start-up output voltage adjustable to 1 of 16 values
(TPSM82866CA3PEVM, with I
• Highly accurate output voltage with excellent
transient response
TM
MagPack Technology 6A Power Module Evaluation Module
Description
2
total
= 29.7 °C/W)
JA
2
C)
1
