- Page 1 C19 Laundrylux Laundry Installation Guide For BluKey™ Pro Serial/Pulse and BluKey™ Pulse Devices Harness - “Laundry C19: Alliance (ACA)” BluKey™ Pro Serial BluKey™ Pulse BluKey™ Pro Pulse Laundrylux Machines (Crossover/Encore Machines)
- Page 2 “C19” Harness BluKey to Machine BluKey™ Pulse BluKey device accepts payment from PayRange mobile app. Laundry Interface Kit (includes Cable Harnesses and Card Adapter Board) connects BluKey to Laundry Machine and converts electrical signals between them. Supported Machines Laundrylux Crossover/Encore controllers.
- Page 3 Machine Controller Configuration (Pulse) Washing machines can be set to 2 types of mode: Serial and Pulse. Dryers can only be set to Pulse. Configure Washing machine for Pulse Mode The washer can accept payment using coins or tokens in COIN MODE or using payment cards in CARD MODE (serial).
- Page 4 Note: If machine has a 2-pin power connector (shown below), remove P19 harness from PayRange harness and connect PayRange 2-pin connector to the machine’s 2-pin power connector. Newer machines may have a 5-pin connector for power, then use P19 PayRange harness to connect to power. Top Load Washer...
- Page 5 Disconnect machine 4-pin coin/service harness from machine. o Plug PayRange coin pass-through into machine. o Plug machine 4-pin coin/service harness into PayRange pass- through connector. Front Load Washer Top Load Washer Step 6: Configure Laundry Interface Module (BluKey Pulse Only) Switches must be set to match install scenario.
- Page 6 2. Insert a card into the reader – verify normal card operation and machine can start. 3. Rapid advance machine to clear cycle 4. Select the machine in the PayRange App and swipe to pay – verify machine displays PayRange balance (or value of free purchase code) and can start.
