- Page 1 C5 LG-C Laundry Installation Guide For BluKey™ Pro Serial/Pulse and BluKey™ Pulse Devices Harness - “Laundry C5: LG-C” BluKey™ Pro Serial BluKey™ Pulse BluKey™ Pro Pulse LG Machines Equipped with Debit-Capable Controllers © 2021 PayRange Inc.
- Page 2 Coin-Op Machine “C5” Harness BluKey™ Pulse BluKey device accepts payment from PayRange mobile app. Laundry Interface Kit (includes Laundry Interface Module and Cable Harnesses) connects BluKey to Laundry Machine and converts electrical signals between them. Supported Machines LG Commercial with C-series controller.
-
Page 3: Installation Steps
Installation Steps IMPORTANT: PayRange service requires data connection on a user’s mobile device. Prior to installation, verify location has adequate cellular reception or a WIFI network that users can access. If mobile web browser can load a website relatively quickly, data connection should be adequate. - Page 4 Step 3: Connect to laundry machine (Pulse Installation) • eSuds (credit) Disconnect machine’s blue 6-pin e-Suds connector, then connect PayRange 6-pin connector in its place (machine blue 6-pin connector will remain unconnected) • Coin Pass-Through (not required*) Disconnect machine’s 12-pin coin/service connectors, then connect PayRange 12-pin connectors in-...
- Page 5 2. Insert a card into the reader – verify normal card operation and machine can start. 3. Rapid advance machine to clear cycle 4. Select the machine in the PayRange App and swipe to pay – verify machine displays PayRange balance (or value of free purchase code) and can start.
