OWNER'S MANUAL: Performance Series Perforated Cabinets
THIS MANUAL APPLIES TO THE FOLLOWING SKUs: 00301143, 00301144
Keep this information for further reference.
Thank you for purchasing a NavePoint product.
Please examine the product for any damaged parts. If any part is damaged or missing, contact NavePoint for assistance. Do not
attempt to install or use product if it has been damaged. This product contains small items that could be a choking hazard – keep these
items away from children.
During installation, lay product contents on cardboard or other protective surface to avoid any damage.
Do not use with equipment that is heavier than the indicated weight capacity for this product. This product is designed to be installed
indoors on wood stud walls, solid concrete walls or brick walls. Make sure that the supporting surface will safely support the weight of
the equipment and all attached hardware and components. It is recommended that installation be performed by a qualified installer.
NavePoint cannot be held responsible for damage to equipment or personal injury resulting from improper use or installation of
product.
Maintenance: Check that the product is secure and safe to use at regular intervals (at least every three months).
Limitations of Liability: In no event will NavePoint, LLC. be liable for any damages, whether direct or indirect, special, punitive,
incidental or consequential damages (including, but not limited to, lost profits or revenue, loss of use, lost business opportunities or loss
of goodwill) or for the costs of procuring substitute products, arising out of or in connection with the use of the product, whether such
liability arises from any claim based upon contract, warranty, tort (including negligence), product liability or otherwise, whether or not
seller has been advised of the possibility of such loss or damage. In no event will seller's total cumulative liability, from all causes of
action and all theories of liability, exceed the total amounts actually paid to seller by customer under the order that gives rise to any
liability hereunder.
© 2020 NavePoint, LLC
20200503-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Performance Series and is the answer not in the manual?

Questions and answers

Summary of Contents for NavePoint Performance Series

  • Page 1 Thank you for purchasing a NavePoint product. Please examine the product for any damaged parts. If any part is damaged or missing, contact NavePoint for assistance. Do not attempt to install or use product if it has been damaged. This product contains small items that could be a choking hazard – keep these items away from children.
  • Page 2: Feature Identification

    4- Removable Cable Access Panels (x2) 5- Hanger Bar 6- Horizontal Rails (x4) 7- Vertical Mounting Rails (x4) 8- “L” Brackets (x2) Hardware Included • M6 Mounting Screws x12 • M6 Plastic Washers x12 M6 Cage Nuts x12 • • Anchors x4 www.NavePoint.com customerservice@navepoint.com...
  • Page 3: Enclosure Configuration

    Cable Access and Management The top/bottom of the cabinet has rectangular openings for cable access and management. The cable access panels can easily be removed or installed with the included screws. www.NavePoint.com customerservice@navepoint.com...
  • Page 4 Using a Phillips-head screwdriver, remove the screws that fasten the rails to the enclosure. 2.Move the cage nuts to the desired depth and reinstall. 3. Slide the mounting rails to the desired depth and reattach them. www.NavePoint.com customerservice@navepoint.com...
  • Page 5: Mounting The Enclosure To The Wall

    The notches will fit over the hooks and the enclosure should slide down onto the hooks until secure. www.NavePoint.com customerservice@navepoint.com...
  • Page 6 Warning: Do not attempt to mount to wall, when equipment is already mounted inside the rack. The rack can hold up to 198 pounds evenly distributed. Make sure the wall surface can hold both the weight of the cabinet and the rack-mounted equipment. www.NavePoint.com customerservice@navepoint.com...
  • Page 7: Equipment Installation

    Repeat steps 1a and 1b until all required cage nuts are installed. 2 After installing the required cage nuts, use the included black mounting screws and cup washers to secure your equipment to the rack rail. Place the cup washers between the screws and the equipment mounting brackets. www.NavePoint.com customerservice@navepoint.com...
