Summary of Contents for Electrolux SFE818E1DC

  • Page 1 EN User Manual | Refrigerator SFE818E1DC...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................6 4. CONTROL PANEL..................9 5.
  • Page 3 of age should be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Children shall not carry out cleaning and user maintenance of the appliance without supervision. •...

  • Page 4: Safety Instructions

    • Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects. • When the appliance is empty for long period, switch it off, defrost, clean, dry and leave the door open to prevent mould from developing within the appliance.
  • Page 5 • Make sure not to cause damage to the • Do not remove or touch items from the electrical components (e.g. mains plug, freezer compartment if your hands are wet mains cable, compressor). Contact the or damp. Authorised Service Centre or an •...

  • Page 6: Installation

    2.6 Service • Disconnect the appliance from the mains supply. • To repair the appliance contact the • Cut off the mains cable and discard it. Authorised Service Centre. Use original • Remove the door to prevent children and spare parts only. pets to be closed inside of the appliance.
  • Page 7 3.1 Dimensions Overall dimensions ¹ Space required in use ² 1769 1780 ¹ the height, width and depth of the appliance ² the height, width and depth of the appliance without the handle including the handle, plus the space necessary for free circulation of the cooling Space required in use ²...
  • Page 8 3.3 Electrical connection Overall space required in use ³ • Before plugging in, ensure that the voltage and frequency shown on the rating plate H3 (A+B) 1816 correspond to your domestic power supply. • The appliance must be earthed. The 1085 power supply cable plug is provided with a ³...

  • Page 9: Control Panel

    4. CONTROL PANEL Display Fridge Temperature colder button Freezer Temperature warmer button ON/OFF Freezer Temperature colder button It is possible to change predefined sound of buttons by pressing together Mode and temperature colder button for a few seconds. Mode Change is reversible. Fridge Temperature warmer button 4.1 Display A.
  • Page 10 This function stops automatically after 52 hours. The set temperature will be reached You can deactivate the Frostmatic function within 24 hours. before its automatic end by repeating the After a power failure the set temperature procedure until the Frostmatic indicator turns remains stored.

  • Page 11: Daily Use

    4.9 DrinksChill function earlier power failure), the alarm and freezer temperature indicators flash and the sound is The DrinksChill function is to be used to set an acoustic alarm at the preferred time, To deactivate the alarm: useful for example when a recipe requires to 1.
  • Page 12 Do not move the glass shelf above the vegetable drawer to ensure correct air circulation. 5.3 Vegetable drawer The drawer is suitable for storing fruit and vegetables. To remove the drawer (e.g. for cleaning): 1. Pull out the drawer and lift it up. This model is equipped with a variable storage box which can be moved sideways.
  • Page 13 1. Pull out the rails. WARNING! Do not remove the Styrofoam at the bottom of the device. 2. Place the rear part of the drawer (1) on the rails. This device activates automatically when needed. It is also possible to switch on the device manually when needed (refer to "DYNAMICAIR function").

  • Page 14: Hints And Tips

    5.6 Storage of frozen food 5.7 Thawing When activating an appliance for the first time Deep-frozen or frozen food, prior to being or after a period out of use, before putting the consumed, can be thawed in the refrigerator products in the compartment let the appliance or inside a plastic bag under cold water.
  • Page 15 at room temperature in the part of the • It is important to wrap the food in such a freezer compartment where there is no way that prevents water, humidity or frozen food. condensation from getting inside. • Do not eat ice cubes, water ices or ice 6.4 Shopping tips lollies immediately after taking them out of the freezer.

  • Page 16: Care And Cleaning

    Type of food Shelf life (months) Poultry 9 - 12 Beef 6 - 12 Lamb 6 - 9 Sausage 1 - 2 Leftovers with meat 2 - 3 6.6 Hints for fresh food refrigeration • Meat (all types): wrap in a suitable packaging and place it on the glass shelf •...
  • Page 17 7.2 Periodic cleaning The equipment has to be cleaned regularly: About 12 hours prior to defrosting set a 1. Clean the inside and accessories with lower temperature in order to build up lukewarm water and some neutral soap. sufficient chill reserve in case of any 2.

  • Page 18: Troubleshooting

    5. Leave the doors open to prevent unpleasant smells. 8. TROUBLESHOOTING WARNING! Refer to Safety chapters. 8.1 What to do if... Problem Possible cause Solution The appliance does not operate. The appliance is switched off. Switch on the appliance. The mains plug is not connected to Connect the mains plug to the the mains socket correctly.
  • Page 19 Problem Possible cause Solution Door does not open easily. You attempted to re-open the door Wait a few seconds between closing immediately after closing. and re-opening of the door. The lamp does not work. The lamp is in stand-by mode. Close and open the door.
  • Page 20 Problem Possible cause Solution Many food products are stored at Store less food products at the the same time. same time. The thickness of the frost is greater Defrost the appliance. than 4-5 mm. The door has been opened often. Open the door only if necessary.

  • Page 21: Noises

    9. NOISES SSSRRR! BRRR! CLICK! HISSS! BLUBB! 10. TECHNICAL DATA The technical information is situated in the It is also possible to find the same information rating plate on the internal side of the in EPREL using the link https://eprel.ec.europa.eu and the model appliance and on the energy label.

  • Page 22: Environmental Concerns

    12. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
  • Page 24 222382078-A-372023...
