- Page 6 AD-3000725-01...
- Page 7 Choose Building Regulations Notification Route Competent Person's Building Control Self Certification Scheme Contact your relevant Local Install and Commission this Authority Building Control appliance to manufacturer's (LABC) who will arrange instructions an inspection or contact a government approved inspector Complete the Benchmark Checklist If you notify via the ‘Gas Safe Register’, the register will issue...
- Page 16 The clearances shown in the diagram are minimum requirements to allow for case removal, spanner access and air movement. These should be observed at all times and kept clear of obstructions. PN-0000624 Ø116 min >1.5° Ø100 PN-0000649...
- Page 17 br bk PN-0000342...
- Page 18 PN-0000368...
- Page 19 PN-0000310...
- Page 20 PN-0000262 PN-0000387...
- Page 21 Reset PN-0000335 PN-0000337...
- Page 25 PN-0000604...
- Page 26 0.6m 2.25m 0.6m PN-0000400...
- Page 27 32mm 21.5mm PN-0000389...
- Page 28 PN-0000455...
- Page 29 PN-0000456...
- Page 30 PN-0000457 PN-0000458...
- Page 31 (ii) PN-0000459 PN-0000390...
- Page 32 PN-0000460 PN-0000461...
- Page 33 PN-0000345 Clearance above 178mm 116mm Dia Minimum Aperture For Flue Tube 150 mm Side Clearance 5mm Side Clearance 5mm 195.5mm 195.5mm Pipework run to rear of boiler. Pipe Profiles. (Where copper tails are not supplied with the boiler) If it is desired to route pipework vertically behind the boiler the To ensure that the vertical pipework is at the optimum distance (whether 5 position clip bracket must be used.
- Page 35 PN-0000320 PN-0000322 PN-0000632...
- Page 36 PN-0000602 PN-0000462 PN-0000463...
- Page 37 PN-0000464 PN-0000465...
- Page 38 Low Voltage Controls (OpenTherm) Outdoor Weather Sensor PN-0000395...
- Page 39 230V 230V 230V PN-0000396...
- Page 42 Reset PN-0000398 17-21 mbar 18-22 mbar 19-23 mbar PN-0000361...
- Page 43 PN-0000362 PN-0000363...
- Page 44 Reset PN-0000399...
- Page 45 Set Boiler to Maximum Rate Allow the combustion to stabilise. Do not insert probe to avoid ‘flooding’ the analyser. Perform Flue Integrity Combustion Check Insert the analyser probe into Verify Flue Integrity the air inlet test point, allowing Indication that products of Check CO &...
- Page 46 PN-0000333...
- Page 47 PN-0000335...
- Page 49 PN-0000363 PN-0000381...
- Page 50 PN-0000382 PN-0000394...
- Page 51 PN-0000331 PN-0000332 PN-0000384...
- Page 52 PN-0000383 PN-0000622...
- Page 53 PN-0000378 PN-0000308...
- Page 54 Reset PN-0000397...
- Page 55 PN-0000380 PN-0000379...
- Page 56 Reset PN-0000377...
- Page 57 Turn on mains power 09, 15, 110 or 384 is flashing or re-occurs Go to section ‘A’ The display illuminates regularly, check all PCB connections. If this has no effect replace the PCB. 09, 15, 110, 125, 133, Press the reset button for 110 is still flashing 134, 135 or 384 flashing 1 to 3 seconds...
- Page 58 Is there 230V at: Check electrical supply Main terminals L and N Connection OK at X41 Replace fuse Main terminal fuse Check wiring PCB - X10 connector Display Display or Main terminals L and N illuminated Main PCB fault Switch to DHW mode maximum flow and press reset. During next 3 minutes check:- 230V between PCB - X13 230V at PCB - X13 connector...
- Page 59 Check and correct if necessary 1. Ignition electrode and lead Check wiring - see Electrical Replace PCB 2. Electrode connection Wiring Diagram page 18 3. Spark gap and position Check supply pressure at the gas valve:- Natural Gas - Minimum 17 mbar Check and correct if necessary 1.
- Page 60 CH system pressure less than Restore system pressure 0.5 bar Check wiring and PCB - X22 Replace hydraulic pressure switch connector for approx. 5V DC between green & black - see Replace PCB Wiring Diagram Ensure that the boiler and System fault - correct system are fully vented Check flow temperature sensor connections...
- Page 63 PN-0000366...
- Page 64 Warning After servicing or performing any maintenance on the boiler ensure that This Commissioning Checklist is to be completed in full by the competent person who commissioned the boiler as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.
- Page 65 ALL INSTALLATIONS At max. rate: ppm AND CO/CO ² Ratio Record the following: At min. rate: (where possible) ppm AND CO/CO ² Ratio The heating and hot water system complies with the appropriate Building Regul The boiler and associated products have been installed and commissioned in accordance with the manufacturer’s The operation of the boiler and system controls have been demonstrated to and understood by the The manufacturer’s literature, including Benchmark Checklist and Service Record, has been explained and left with the Commissioning Engineer’s Signature...
- Page 66 SERVICE 07 SERVICE 08 Date: Date: Engineer name: Engineer name: Company name: Company name: Telephone No: Telephone No: Gas safe register No: Gas safe register No: At max. rate: ppm AND CO ² % At max. rate: ppm AND CO ² % Record: Record: At min.
- Page 68 For the warranty to be maintained, please make sure... Benchmark checklist is completed Warranty is registered within 30 days The boiler has an annual service For full terms and conditions, visit www.baxi.co.uk/terms. Failure to adhere to terms and conditions will void your manufacturer’s warranty. Baxi Brooks House,...
