Wichtiger Hinweis
Im Handbuch unter Pkt. 1.2 – Description- ist vermerkt, das der DS1100 mit einer
Betriebsspannung von 5V DC betrieben werden darf.
Soll einen höhere Spannung, z.B. von einer SPS verwendet werden, dann ist ein
DC/DC Konverter notwendig, der zwischen Anschlussbox und Scanner gesetzt wird.
Darüber hinaus ist auch eine DS1100 Version mit dem Kürzel :
Versions-Nummer verfügbar.
Diese ist direkt zwischen 10 – 30 V DC z.B. an einer SPS betreibbar.
Beachten Sie daher das Typenschild des Scanners vor dem Einbau.
Ohne diese SH-Nummer wird der Scanner nach Anlegen einer
Betriebsspannung > 5V DC zerstört !!
Gerd Schroedter
Tel: 0521-93270-55
E-Mail: gs@hiv-hoffmann.de
Seite 1 von 1
Datei: DS1100_warnung
Stand: A
SH 2347
hinter der
Datum: 02/2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Datalogic DS1100

Summary of Contents for Datalogic DS1100

  • Page 1 Wichtiger Hinweis Im Handbuch unter Pkt. 1.2 – Description- ist vermerkt, das der DS1100 mit einer Betriebsspannung von 5V DC betrieben werden darf. Soll einen höhere Spannung, z.B. von einer SPS verwendet werden, dann ist ein DC/DC Konverter notwendig, der zwischen Anschlussbox und Scanner gesetzt wird.
  • Page 3 DS1100 INSTALLATION MANUAL...
  • Page 4 Quality Assurance Supervisor Product names mentioned herein are for identification purposes only and may be trademarks and or registered trademarks of their respective companies. Datalogic reserves the right to make modifications and improvements without prior notification. © - 1999 Datalogic S.p.A. 821000380...

  • Page 5: Table Of Contents

    CONTENTS GUIDE TO INSTALLATION .............. iv General View ..................v SAFETY PRECAUTIONS ..............vi Laser Safety..................vi GENERAL FEATURES ..............1.1 Introduction ..................1.1 Description..................1.1 1.2.1 Indicators ..................1.2 Available Models................1.2 Accessory ..................1.3 INSTALLATION ................2.1 Package Contents ................2.1 Mechanical Installation ..............2.2 2.2.1 Reading Position................2.3 Electrical Connections ..............2.4 2.3.1 Power Supply...................2.4...

  • Page 6: Guide To Installation

    GUIDE TO INSTALLATION The following can be used as a checklist to verify all of the steps necessary for complete installation of the DS1100 scanner. 1) Read all information in the section "Safety Precautions” at the beginning of this manual.

  • Page 7: General View

    DS1100 General View Laser Beam Output Window Ext Trig LED TX Data LED Power ON LED Good Read LED Laser Warning and Device Class Label Laser ON LED Mounting Holes Figure A...

  • Page 8: Safety Precautions

    LASER SAFETY The following information is provided to comply with the rules imposed by international authorities and refers to the correct use of the DS1100 scanner. Standard Regulations This scanner utilizes a low-power laser diode. Although staring directly at the laser beam momentarily causes no known biological damage, avoid staring at the beam as one would with any very strong light source, such as the sun.
  • Page 9 The warning label indicating exposure to laser light and the device classification is applied onto the body of the scanner (Figure A, Warning and device class label For installation, use and maintenance it is not necessary to open the scanner. The laser diode used in this device is classified as a class 3B laser product according to IEC 825-1 regulations and as a Class IIIb laser product according to CDRH regulations.
  • Page 10 This page is intentionally left blank. viii...

  • Page 11: General Features

    DS1100 1 GENERAL FEATURES 1.1 INTRODUCTION The DS1100 scanner with decoder offers the best cost-effective solution for demanding industrial applications. The DS1100 ultra compact dimensions, based on Datalogic's experience in miniaturised laser components, have been specifically designed to make the scanner's integration into automated equipment extremely easy.

  • Page 12: Indicators

    The laser beam output window is on the side of the scanner in DS1100- XXX0 models and on the upper part of the scanner in DS1100-XXX1 models, (Figure A, A security system allows the laser to activate only once the motor has reached the correct rotational speed;...

  • Page 13: Accessory

    DATALOGIC DS1100 The following models are therefore available: DS1100 - X X X X Optical Resolution Reading Window Position 1 = Standard Resolution 0 = Direct 2 = High Resolution 1 = 90° Serial Interface Linear/Raster 1 = RS232 + RS485...
  • Page 14 DS1100 DATALOGIC This page is intentionally left blank. 1.4 - General Features...

  • Page 15: Installation

    DS1100 2 INSTALLATION 2.1 PACKAGE CONTENTS Verify that the DS1100 reader and all the parts supplied with the equipment are present and intact when opening the packaging; the list of parts includes: 1. DS1100 reader with cable 2. Installation Manual 3.

  • Page 16: Mechanical Installation

    DATALOGIC 2.2 MECHANICAL INSTALLATION DS1100 can be installed to operate in any position. There are three screw holes (M3 x 5) on the body of the reader for mounting. The diagram below gives all the information required for installation; refer to par.

  • Page 17: Reading Position

    DATALOGIC DS1100 2.2.1 Reading Position In DS1100-XXX1 models the laser beam is emitted from the output window with a 12° (± 2) skew angle. This allows installation with minimum overall dimensions. DS1100-XXX1 90° Reading Window Position Laser Beam 12° ± 2...

  • Page 18: Electrical Connections

    DS1100 DATALOGIC 2.3 ELECTRICAL CONNECTIONS The DS1100 cable is equipped with a 25-pin female D-sub connector for connection with the power supply and input/output signals: Figure 2.4 – 25-pin female D-sub connector 25-pin D-sub connector pinout Name Function 9,13 Power supply input voltage +...

  • Page 19: Main Serial Interface - Rs485 Half-Duplex

    It can be used for Multidrop connections in a master/slave layout or with a Datalogic Multiplexer, (see par. 2.5.2 and 2.5.3) exploiting a proprietary protocol based on polled mode called MUX32 protocol, where a master device polls slave devices to collect data.
  • Page 20 2 m DS1100 (up to 31) DS1100 RTX485 + DS1100 RTX485 - SGND Three wires + shield RTX485 + RTX485 - MULTIPLEXER RS485 REF SHIELD 120 Ohm Figure 2.7 - DS1100 Multidrop connection to a Multiplexer 2.6 - Installation...

  • Page 21: Auxiliary Interface - Rs232

    2.3.3 Auxiliary Interface - RS232 The auxiliary serial interface is used exclusively for RS232 point-to-point connections. It is also used for configuring the DS1100. The parameters relative to the auxiliary interface (baud rate, data bits, etc.) can be defined using the Winhost utility program or "Host Mode Programming", installed from the diskette.

  • Page 22: Inputs

    DS1100 DATALOGIC 2.3.4 Inputs The inputs available on the connector supplied with the scanner are indicated below: Name Function IN1 - Input 1 - EXT TRIG- External trigger (input -) I/O Reference The EXT TRIG input is used to connect the external trigger which tells the scanner to scan for a code.

  • Page 23: Outputs

    Figure 2.11 - DS1100 Output connections These outputs are both level or pulse configurable. 2.4 POSITIONING The DS1100 scanner is able to decode moving barcode labels at a variety of angles, however significant angular distortion may degrade reading Installation - 2.9...
  • Page 24 DS1100 DATALOGIC performance. When mounting the DS1100 take into consideration these three ideal label position angles: Pitch 0°, Skew 15° to 30° and Tilt 0°. Follow the suggestions for the best orientation: The Pitch angle is represented by the value P in Figure 2.12.

  • Page 25: Typical Layouts

    DATALOGIC DS1100 2.5 TYPICAL LAYOUTS 2.5.1 Point-to-Point In this layout data is transmitted to the Host on the RS232 Auxiliary serial interface. The Local Echo communication mode must be enabled (default) See the Winhost Help On Line. When On-Line Operating mode is used, the scanner is activated by an External Trigger (photoelectric sensor) when the object enters its reading zone.
  • Page 26 DS1100 DATALOGIC The External Trigger signal is unique to the system; there is a single reading phase and a single message from the master scanner to the Host computer. The main and auxiliary ports are connected as shown in the following figure.

  • Page 27: Multiplexer

    DATALOGIC DS1100 2.5.3 Multiplexer Each scanner is connected to a Multiplexer (for example MX4000) with the RS485 half-duplex main interface. MX4000 Figure 2.17 - Multiplexer layout The auxiliary serial interface can be used in Local Echo mode to control any single scanner (visualize collected data) or to configure it using the WinHost utility or Host Mode programming procedure.
  • Page 28 DS1100 DATALOGIC This page is intentionally left blank. 2.14 - Installation...

  • Page 29: Reading Features

    SN = number of effective scans LH = label height (in mm) LS = label movement speed (in mm/s) SS = number of scans per second For example, the DS1100 (350 scans/sec.) for a 25 mm high code moving at Reading Features - 3.1...

  • Page 30: Picket-Fence Mode

    SS = scans per second For example, for a 50 mm wide code moving in a point where the reading field is 180 mm wide at a 1300 mm/s speed, the DS1100 (350 scans per sec.), performs: [((180-50)/1300) * 350] - 2 = 33 scans...

  • Page 31: Performance

    DATALOGIC DS1100 3.3 PERFORMANCE The DS1100 scanner is available in different versions according to the reading performance.       mm (mils) scans/s 1XXX 0.20 (8) 2XXX 0.12 (5)      1XXX 30 mm (1.2 in) - 220 mm (8.7 in) on 0.50 mm (20 mils) codes 2XXX 10 mm (0.4 in) - 110 mm (4.3 in) on 0.30 mm (12 mils) codes...

  • Page 32: Reading Diagrams

    DS1100 DATALOGIC 3.4 READING DIAGRAMS The following diagrams show the reading distance for barcodes with different densities. DS1100-1XXX Standard Resolution 220 mm 0.20 mm 0.30 mm 0.50 mm, ( 20 mils ) ( 8 mils ) ( 12 mils )
  • Page 33 DATALOGIC DS1100 DS1100-2XXX High Resolution 0 0 0 0 0.20 mm 0.30mm ( 8 mils ) ( 12 mils ) 0.12 mm ( 5 mils ) NOTE (0,0) is the center of the laser beam output window. CONDITIONS: Code = Interleaved 2/5 or Code 39 = 0.90...
  • Page 34 DS1100 DATALOGIC This page is intentionally left blank. 3.6 - Reading Features...

  • Page 35: Maintenance

    Repeat the operation frequently in particularly dirty environments. Use soft material and alcohol to clean the windows and avoid any abrasive substances. WARNING Clean the window of the DS1100 when the scanner is turned off or, at least, when the laser beam is deactivated. Maintenance - 4.1...
  • Page 36 DS1100 DATALOGIC This page is intentionally left blank. 4.2 - Maintenance...

  • Page 37: Technical Features

    DATALOGIC DS1100 5 TECHNICAL FEATURES DS1100-1XXX DS1100-2XXX ELECTRICAL FEATURES Maximum input voltage 5 Vdc ± 5% Power consumption max. 1.5 W INPUTS / OUTPUTS Serial interfaces: Main RS485 half-duplex Auxiliary RS232 Baud Rates 150 to 115200 baud Control Inputs External Trigger; Aux. Input...
  • Page 38 DS1100 DATALOGIC SOFTWARE FEATURES READABLE CODE SYMBOLOGIES • EAN/UPC (including Add-on 2 and Add-on 5) • Code 93 • 2/5 Interleaved • Code 128 • Code 39 (Standard and Full ASCII) • EAN 128 • Codabar • Pharmacode Other symbologies available on request.
