WI TH DUAL VACUUM SYSTEM
READ ALL I NSTRUCTI ONS AND WARNI NGS
BEFORE OPERATI NG THI S LI FTER
DESI GNED FOR THE MATERI ALS HANDLI NG PROFESSI ONAL
QUADRA-TI LT ROTATOR
DC-VOLTAGE
I NSTRUCTI ONS
I nternational Version
MODEL NUMBER:
SERI AL NUMBER:
__________
__________
Advertisement
Table of Contents
Related Manuals for WOOD'S POWR-GRIP MRTA611LDC
Summary of Contents for WOOD'S POWR-GRIP MRTA611LDC
- Page 1 KEEP FOR FUTURE REFERENCE I NSTRUCTI ONS I nternational Version P.O. Box 368 – 908 West Main Laurel, MT USA 59044 phone 800-548-7341 MODEL NUMBER: __________ phone 406-628-8231 SERI AL NUMBER: __________ fax 406-628-8354 QUADRA-TI LT ROTATOR DC-VOLTAGE WI TH DUAL VACUUM SYSTEM READ ALL I NSTRUCTI ONS AND WARNI NGS BEFORE OPERATI NG THI S LI FTER DESI GNED FOR THE MATERI ALS HANDLI NG PROFESSI ONAL...
-
Page 2: Specifications
Model Number: MRTA611LDC Description: Designed for use with a crane or other hoisting equipment, the MRTA611LDC lifter employs vacuum to hold a load for lifting, and it provides manual 360° rotation and mechanically assisted, manual 90° tilt movements for load manipulation. - Page 3 Wood’s Powr-Grip cannot be responsible for the safety of a lifter that has been modified by the customer. For consultation, contact Wood's Powr-Grip. Rev 3.0/ 10-06 QUADRA-TI LT ROTATOR • DC-VOLTAGE...
-
Page 4: Operating Features
OPERATI NG FEATURES Note: Components featured in the following instructions for assembling, operating or maintaining the vacuum lifter are underlined on their first appearance in each section. Standard MRTA611LDC shown. 1 LI FT SPOOL 8 AI R FI LTER 15 VACUUM PUMP... - Page 5 ASSEMBLY ET UP THE I FTER 1) Remove the top of the shipping crate and all devices for restraining the vacuum lifter during shipping. Save the crate for use whenever the lifter is transported. 2) Suspend the lifter from a crane as follows: Select hoisting equipment (crane and hoist, when applicable) rated to carry the maximum load weight plus the lifter weight (see SPECI FI CATI ONS: Maximum Load Capacity and Lifter Weight).
- Page 6 HANGE THE RAME ONFI GURATI ON The lifter offers a variety of pad frame configurations to accommodate different load dimensions and weights (see SPECI FI CATI ONS: Pad Spread and Load Capacity). The following illustration shows several possible configurations. Select a configuration to provide optimal support across the load surface and to minimize load overhang (see OPERATI ON: B EFORE SI NG THE...
- Page 7 Configurations are created by installing or removing the pad frame’s extension arms, by repositioning or removing the movable pad mounts, and by connecting or disconnecting the vacuum hoses to certain vacuum pads. Always assemble the pad frame in a symmetrical arrangement, to keep the lifter balanced (see illustration).
- Page 8 To Reposition ( or Remove) Movable Pad Mounts 1) Remove the cotterless hitch pin from one movable pad mount by pulling on the pull ring. 2) Move the pad mount to the desired position on the pad frame and align the holes for the cotterless hitch pin in the pad mount with COTTERLESS HI TCH PI N the corresponding holes in the pad frame.
-
Page 9: Intended Use
(see MAI NTENANCE: V : Friction Coefficient), as ACUUM AI NTENANCE verified by a friction test. I f necessary, contact Wood's Powr-Grip for help in conducting a friction test. minimum • While the length and width of the load are determined by the Pad Spread (see... -
Page 10: Operating Environment
Conversely, allowable thickness increases as load weight decreases. I n addition, an operator may be able to manually counteract the tendency of unstable loads to tilt out of the upright position, provided that the operator maintains control of the load at all times (see OPERATI ON: T : About the Tilt Linkage and T ). -
Page 11: Operation
OPERATI ON EFORE SI NG THE I FTER The operator must determine whether the lifter is capable of performing each intended task, in I NSTRUCTI ONS accordance with the SPECI FI CATI ONS and I NTENDED USE sections of this manual. - Page 12 PPLY THE ADS TO A Positioning the Lifter on the Load Make certain that the contact surfaces of the load and all vacuum pads are free of any contaminates that could prevent the pads from sealing against the load (see MAI NTENANCE: ).
- Page 13 Vacuum Level on Optimal Surfaces When the lifter is attached to clean, smooth, nonporous load surfaces, it should be able to maintain a vacuum level in the green range on both vacuum gauges, except when used at high elevations (see SPECI FI CATI ONS: Operating Elevation). I f not, make sure both vacuum switches are adjusted correctly (see MAI NTENANCE: V ).
- Page 14 I FT AND OVE THE About the Tilt Linkage WARNI NG: Make sure load is positioned correctly on lifter; unbalanced loads may tilt unexpectedly. The lifter’s tilt linkage is designed to automatically hold a balanced load in either the upright or the flat position.
-
Page 15: In Case Of Power Failure
Monitoring Vacuum I ndicators The low vacuum warning light and both vacuum gauges must remain completely visible to the operator, so that they can be monitored throughout the entire lift. WARNI NG: Vacuum indicators must be visible to operator throughout entire lift. I f the vacuum system experiences leakage while the lifter is attached to the load, the vacuum pump turns on automatically, as required to maintain sufficient vacuum for lifting the maximum load weight. - Page 16 OTATE THE DGEWI SE WARNI NG: Make sure load is positioned correctly on lifter; unbalanced loads may rotate unexpectedly. Remember that the load is longer in its diagonal dimensions than in its side dimensions. Make sure there is sufficient clearance for the load to rotate without contacting the operator or any nearby objects.
- Page 17 ELEASE THE ADS FROM THE WARNI NG: Load must be fully supported before releasing vacuum pads. When the load is at rest and fully supported, pinch the valve release lever against the valve handle, and push the valve handle inward to the “RELEASE” position (power off) until the vacuum pads disengage completely from the load.
-
Page 18: Maintenance
MAI NTENANCE WARNI NG: Alw ays make sure battery is disconnected before servicing lifter. NSPECTI ON CHEDULE Perform inspections routinely, according to the following frequency schedule: Every-Lift I nspection • Examine the vacuum pads and load surface for contamination or debris (see V ACUUM to follow). -
Page 19: Operational Tests
ESTI NG CHEDULE initially each time following a repair or Perform these tests when placing the lifter in service modification . Correct any deficiency and retest before using the lifter. Operational Tests • Perform the V to follow. ACUUM • Test all features and functions of the lifter (see OPERATI NG FEATURES, OPERATI ON and MAI NTENANCE). -
Page 20: Battery Test
ATTERY ECHARGE Only use a battery charger supplied by or approved by Wood's Powr-Grip; other chargers may reduce battery life. Charge the battery as soon as possible after any extended use of the lifter, or whenever the battery gauge indicates diminished energy (see B preceding). -
Page 21: Battery Charger Test
I n addition, all pads should be replaced on a regular basis, preferably after no more than 2 years, to ensure that the friction coefficient is not compromised. I f necessary, contact your dealer or Wood's Powr-Grip for more information. I nspection... -
Page 22: Vacuum Test
Cleaning Regularly clean the face of each vacuum pad to remove oil, dust and any other contaminates. Acceptable cleaning agents include soapy water, glass cleaner and alcohol. Do use other solvents, petroleum-based products (including kerosene, gasoline and diesel fuel) or any harsh chemicals for cleaning, because they can damage the pad and create a hazard to the operator or others. -
Page 23: Filter Maintenance
I LTER AI NTENANCE (for brass bowl type filters) Filter Function and Conditions Requiring Service An air filter prevents solid particles from contaminating components in the vacuum system. CAUTI ON: Examine air filter regularly and empty w hen necessary. Open each filter regularly to determine whether liquid or other contaminants are trapped inside. Remove any liquid or contaminants found in the filter bowl. - Page 24 ACUUM AI NTENANCE (for Thomas pump nos. 107BA20964, 107BD20964 & 107CDC20) WARNI NG: Before proceeding w ith any maintenance, disconnect pow er source. I f the vacuum pump (14) takes too long to attain full vacuum, it may require maintenance. Replace the diaphragm, valve flappers or head gasket as necessary to obtain acceptable pump performance.
-
Page 25: Swi Tch Adjustment
ACUUM WI TCH DJUSTMENT Vacuum Sw itch Function A vacuum sensor/ electrical switch assembly controls the low vacuum warning light and the vacuum pump: The valve handle activates the warning light and the pump, which evacuates the vacuum pads. After the lifter attains a vacuum level sufficient for lifting the maximum load weight (hereafter, “minimum lifting level”), the vacuum switch automatically turns off the pump and the warning light. -
Page 26: Adjustment Procedure
Adjustment Procedure WARNI NG: Lifting capacity decreases w henever vacuum sw itch is adjusted to maintain low er vacuum level. 1) Using a 1/ 4" open-end wrench (as provided), turn the adjustment screw about 1/ 6th turn at a time (approximately one flat of the screw head). lower clockwise To maintain a... -
Page 27: Replacement Parts List
REPLACEMENT PARTS LI ST Stock No. Description Qty. 66466 Spring Plunger with T-Handle - 5/ 8-11 Thread (for optional tilt locks) 66195 Pump Repair Kit (including diaphragm, head gasket and valve flappers) 66130 Vacuum Pump - Diaphragm Type - 1-SCFM [ 28 liters/ minute] - 12 V DC 65442AM Vacuum Hose - 1/ 4"... -
Page 28: Limited Warranty
For purchases in Contact your dealer or the Technical Service Department at Wood’s Powr-Grip Co. for assistance. Wood's Powr-Grip Co., I nc. 908 West Main St. / P.O. Box 368 Laurel, MT USA 59044 phone 800-548-7341 phone 406-628-8231 fax 406-628-8354 Rev 3.0/ 10-06... - Page 29 LOW VACUUM WARNI NG BUZZER PECI FI CATI ONS Maximum Alarm Volume: 103 dBa at 2' [ 60 cm] Function: While the lifter is powered up, an audible alarm warns the operator whenever vacuum is not sufficient for lifting the maximum load weight. PERATI ON Before Using the Lifter WARNI NG: Make sure alarm is clearly audible over ambient noise at operator...
- Page 30 I f the vacuum system experiences leakage while the lifter is attached to the load, the vacuum pump turns on automatically, as required to maintain sufficient vacuum. The alarm also sounds while the pump is running, to signal the reduction in vacuum to the operator. I f the alarm sounds while you are lifting a load, make sure the vacuum gauge shows a vacuum level of 16"...
