- Page 1 Operating Instruction Maintenance Instruction Original Operating Instructions BPR 25/40 D S/N 101 692 79 1001> Reversible vibratory plate www.discount-equipment.com 008 202 70 EN © 11/2018...
- Page 2 Discount-Equipment.com is your online resource for quality parts & equipment. Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101 Need parts? Click on this link: http://www.discount-equipment.com/category/5443-parts/ choose one of the options to help get the right parts and equipment you are looking for.
- Page 3 WARNING: Breathing diesel engine exhaust exposes you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Always start and operate the engine in a well-ventilated area. If in an enclosed area, vent the exhaust to the outside. Do not modify or tamper with the exhaust system.
-
Page 4: Table Of Contents
Table of contents Table of contents Introduction............................7 1.1 Foreword............................8 1.2 Machine type plate and engine type plate................10 Technical data............................11 2.1 Noise and vibration data......................13 2.1.1 Noise data..........................14 2.1.2 Vibration data..........................14 Concerning your safety........................15 3.1 Basic prerequisites........................ - Page 5 Table of contents Indicators and control elements......................39 Checks prior to start up........................41 5.1 Notes on safety........................... 42 5.2 Visual inspections and function tests..................43 5.3 Checking the engine oil level..................... 44 5.4 Checking the fuel level; topping up fuel................... 45 5.5 Checking the rubber buffers......................
- Page 6 Table of contents 8.9.3 Checking the oil level in the exciter housing................88 8.9.4 Cleaning the machine........................ 89 8.9.5 Measures prior to extended shut-down period................90 Troubleshooting..........................91 9.1 Preliminary remarks........................92 9.2 Malfunctions during operation....................93 9.3 Engine faults..........................94 Disposal...............................
-
Page 7: Introduction
Introduction Introduction BPR 25/40 D... -
Page 8: Foreword
Introduction – Foreword 1.1 Foreword BOMAG manufactures machines for earth, asphalt and refuse compaction, stabilizers/recyclers as well as planers and pavers. BOMAG’s vast experience in connection with state-of-the-art production and testing methods, such as lifetime tests of all important components and highest quality demands guar- antee maximum reliability of your machine. - Page 9 Introduction – Foreword In the course of technical development we reserve the right for technical modifications without prior notification. These operating and maintenance instructions are also available in other languages. Apart from that, you can also order the spare parts catalogue against the serial number of your machine.
-
Page 10: Machine Type Plate And Engine Type Plate
Introduction – Machine type plate and engine type plate 1.2 Machine type plate and engine type plate Please enter here: Machine type (1): Made by Designation Type Serial number (2): Nominal Power Operating Mass Year of Construction Serial-No. Patent Protection 56154 Boppard;GERMANY Made in Germany B-DEC-0270... -
Page 11: Technical Data
Technical data Technical data BPR 25/40 D... - Page 12 Technical data Dimensions Fig. 3 1220 1460 (29.1) (34.3) (48.0) (57.5) (25.6) (15.7) Dimensions in millimetre (Dimensions in inch) Weights Operating weight (CECE) (331) (lbs) Basic weight (324) (lbs) Transport wheels (optional equipment) (+ 9) (lbs) BPR 25/40 D...
-
Page 13: Noise And Vibration Data
Technical data – Noise and vibration data Travel characteristics Max. working speed m/min (82) (ft/min) Max. gradability (depending on soil) Drive Engine manufacturer Hatz Type 1B20 Cooling Number of cylinders Rated power ISO 3046 (4.2) (hp) Rated speed 3000 Drive system mechanical Exciter system Frequency... -
Page 14: Noise Data
Technical data – Noise and vibration data During operation these values may vary because of the prevailing operating conditions. 2.1.1 Noise data Sound pressure level at the opera- = 95 dB(A), determined acc. to ISO 11201 and EN 500. tor's stand WARNING! Loss of hearing caused by too high noise bur- dens! -
Page 15: Concerning Your Safety
Concerning your safety Concerning your safety BPR 25/40 D... -
Page 16: Basic Prerequisites
Concerning your safety – Basic prerequisites 3.1 Basic prerequisites 3.1.1 General This machine has been built in compliance with the latest technical standard and complies with the applicable regulations and tech- nical rules. However, dangers for persons and property may arise from this machine, if: it is used for purposes other than the ones it is intended for, it is operated by untrained personnel,... -
Page 17: Personal Protective Equipment
Concerning your safety – Basic prerequisites CAUTION! Danger of injury if failing to comply! Sections marked accordingly indicate a dangerous situation that could lead to fatal or severe injuries, if this warning is disregarded. NOTICE! Danger of material damage if failing to comply! Sections marked accordingly indicate possible dangers for machines or components. -
Page 18: Intended Use
Concerning your safety – Basic prerequisites Safety goggles To protect the eyes against airborne particles and squirting fluids. Face protection To protect the face against airborne particles and squirting fluids. Hard hat To protect the head against falling parts and to protect against injuries. - Page 19 Concerning your safety – Basic prerequisites Examples for improper use are: dragging the machine along as a measure of transportation throwing the machine off the transport vehicle attaching an additional weight to the machine It is not permitted to stand on the machine while working. Lifting tackle must be removed before starting work.
-
Page 20: Definition Of Responsible Persons
Concerning your safety – Definition of responsible persons 3.2 Definition of responsible persons 3.2.1 Operating company The operating company is the natural or juridical person who uses the machine or in who's name the machine is used. The operating company must make sure that the machine is only used for the purpose it is intended for and in strict compliance with the safety regulations mentioned in these operating and mainte- nance instructions. - Page 21 Concerning your safety – Definition of responsible persons have made himself familiar with the operation of the machine, be physically and psychologically able to drive and operate the machine. Persons under the influence of alcohol, medication or drugs are not allowed to operate, service or repair the machine.
-
Page 22: Basic Safety Regulations For Safe Operation
Concerning your safety – Basic safety regulations for safe operation 3.3 Basic safety regulations for safe operation 3.3.1 Remaining dangers, remaining risks Despite careful work and compliance with standards and regula- tions it cannot be ruled out that further dangers may arise when working with and handling the machine. -
Page 23: Handling Fuels And Lubricants
Concerning your safety – Handling fuels and lubricants 3.4 Handling fuels and lubricants 3.4.1 Preliminary remarks The operating company must ensure that all professional users have read and follow the corresponding safety data sheets for the individual fuels and lubricants. Safety data sheets provide valuable information about the following characteristics: name of substance... -
Page 24: Safety Regulations And Environmental Protection Regulations For Handling Diesel Fuel
Concerning your safety – Handling fuels and lubricants 3.4.2 Safety regulations and environmental protection regulations for handling diesel fuel WARNING! Danger of burning by ignited diesel fuel! – Do not allow diesel fuel to come into contact with hot components. –... -
Page 25: Safety Regulations And Environmental Protection Regulations For Handling Oil
Concerning your safety – Handling fuels and lubricants 3.4.3 Safety regulations and environmental protection regulations for handling oil WARNING! Danger of burning by ignited oil! – Do not allow oil to come into contact with hot components. – Smoking and open fire is prohibited! –... -
Page 26: Safety Regulations And Environmental Protection Regulations For Handling Hydraulic Oil
Concerning your safety – Handling fuels and lubricants 3.4.4 Safety regulations and environmental protection regulations for handling hydraulic oil WARNING! Danger of injury caused by escaping pressure fluid! – Always depressurize the hydraulic system before starting work in the hydraulic system. –... -
Page 27: Loading/Transporting The Machine
Concerning your safety – Loading/transporting the machine 3.5 Loading/transporting the machine Make sure that persons are not endangered by the machine tipping or sliding off. Do not use damaged or in any other way impaired lashing points. Always use appropriate lifting and lashing means on the lifting and lashing points. -
Page 28: Start-Up Procedure
Concerning your safety – Start-up procedure 3.6 Start-up procedure 3.6.1 Prior to starting up Use only machines which are serviced at regular intervals. Become acquainted with the equipment, the indicators and control elements, the working principle of the machine and the working area. -
Page 29: Working Operation
Concerning your safety – Working operation 3.7 Working operation 3.7.1 Persons in the danger area Before taking up work, also after breaks, you should always con- vince yourself that the danger zone is free of persons or obstruc- tions. Give warning signals, if necessary. Stop work immediately if per- sons remain in the danger zone, despite the warning. -
Page 30: Refuelling
Concerning your safety – Refuelling 3.8 Refuelling Do not inhale any fuel fumes. Refuel only with the engine shut down. Do not refuel in closed rooms. No open fire, do not smoke. Ultra-low sulphur diesel fuel poses a higher risk of combustion caused by the static charging than diesel fuel with a higher sulphur content. -
Page 31: Maintenance Work
Concerning your safety – Maintenance work 3.9 Maintenance work 3.9.1 Preliminary remarks Adhere to the specified operating, maintenance and repair meas- ures. The machine must only be serviced by qualified personnel author- ised by the operating company. Keep unauthorised persons away from the machine. Perform maintenance work only with the engine shut down. -
Page 32: Repair
Concerning your safety – Repair 3.10 Repair Identify a defect machine with a warning sign. Only operate the machine after it has been repaired. When replacing safety relevant components, only original spare parts must be used. Repairs must only be performed by an expert/qualified person. When performing welding work on the machine you should cover the fuel tank with insulating material. -
Page 33: Signage
Concerning your safety – Signage 3.11 Signage Keep stickers and signage in good and legible condition and comply with their meaning. Replace damaged and illegible stickers or signage immediately. WARNING California Proposition 65 Warning This product contains chemicals that cause cancer + chemicals that are reproductive toxicants START START... - Page 34 Concerning your safety – Signage Warning sticker - Follow operating instructions Fig. 8 Warning sticker – California Proposition 65 WARNING California Proposition 65 Warning This product contains chemicals that cause cancer + chemicals that are reproductive toxicants B-DEC-0316 Fig. 9 Warning sticker - Starter rope Fig.
- Page 35 Concerning your safety – Signage Information sticker - Lifting point Fig. 12 Information sticker - Guaranteed sound capacity level Fig. 13 Operation sticker - Throttle lever Fig. 14 Operation sticker - Travel lever Fig. 15 BPR 25/40 D...
- Page 36 Concerning your safety – Signage Information sticker - Ultra-low sulphur fuel Fig. 16 Brief operating instructions Fig. 17 Maintenance sticker ASTM D975-09a 1-D S15 / 2-D S15 DIESEL before taking into operation weekly vor Inbetriebnahme wöchentlich avant la mise en service hebdomadairement anterior a la puesta en servicio cada semana...
- Page 37 Concerning your safety – Signage Engine type plate (example) B-HAT-0030 Fig. 20 BPR 25/40 D...
-
Page 38: Indicators And Control Elements
Indicators and control elements Indicators and control elements BPR 25/40 D... - Page 39 Indicators and control elements Fig. 21 Recoil starter Travel lever Handle Steering rod height adjustment Locking bolt Throttle lever BPR 25/40 D...
-
Page 40: Checks Prior To Start Up
Checks prior to start up Checks prior to start up BPR 25/40 D... -
Page 41: Notes On Safety
Checks prior to start up – Notes on safety 5.1 Notes on safety If the following tests reveal damages or other defects, the machine must not be operated, until these deficiencies have been corrected. Do not operate the machine with defective indicators and control elements. -
Page 42: Visual Inspections And Function Tests
Checks prior to start up – Visual inspections and function tests 5.2 Visual inspections and function tests Check fuel tank and lines for condition and leaks. Check bolted connections for tight fit. Check machine for contamination and damage. Check the hydraulic oil cooler for dirt. Check starter rope for chafing. -
Page 43: Checking The Engine Oil Level
Checks prior to start up – Checking the engine oil level 5.3 Checking the engine oil level NOTICE! Danger of engine damage! – +Use only oil of the permitted specification Ä Chapter 8.2.1 „Engine oil“ on page 63. B-SYM-1068 Fig. 22 Protective equipment: Working clothes Safety shoes... -
Page 44: Checking The Fuel Level; Topping Up Fuel
Checks prior to start up – Checking the fuel level; topping up fuel 5.4 Checking the fuel level; topping up fuel NOTICE! Danger of engine damage! – Monitor the entire refuelling process. – Contaminated fuel can cause malfunction or B-SYM-1069 even damage of the engine. -
Page 45: Checking The Rubber Buffers
Checks prior to start up – Checking the rubber buffers 5.5 Checking the rubber buffers B-SYM-1073 Fig. 26 Protective equipment: Working clothes Safety shoes Protective gloves Check the rubber buffer pairs, left and right, for tight fit, cracks and tear-offs. ð... -
Page 46: Operation
Operation Operation BPR 25/40 D... -
Page 47: Folding Down The Steering Rod
Operation – Folding down the steering rod 6.1 Folding down the steering rod Pull out and turn the locking bolt (2). Fold down the steering rod. ð The steering rod can swing freely. Adjust the steering rod with the height adjustment (1) to the required height. -
Page 48: Starting The Engine
Operation – Starting the engine 6.2 Starting the engine Exhaust fumes contain toxic substances and can damage your health, cause unconsciousness or even death. WARNING! Danger of poisoning by exhaust gases! – Do not inhale exhaust gases. – Avoid operation in closed or partly closed rooms, or ensure adequate ventilation when working in trenches. - Page 49 Operation – Starting the engine Pull the rope by the starter handle, until resistance can be felt. Guide the starter handle back to initial position. Fig. 31 CAUTION! Danger of injury caused by uncontrolled machine movement! – Always hold on to a running machine. –...
-
Page 50: Operation
Operation – Operation 6.3 Operation Operate the machine only with the steering rod folded down. Use only the steering rod to steer the machine. Guide the machine so that your hands do not hit against solid objects. CAUTION! Danger of injury caused by uncontrolled machine movement! –... - Page 51 Operation – Operation CAUTION! Danger of injury caused by the crushing of body parts! – When reversing, steer the machine from the side using the steering handle. Pull the travel lever back. ð The machines vibrates backwards with a speed which corresponds with the travel lever position.
-
Page 52: Parking The Machine In Secured Condition
Operation – Parking the machine in secured condition 6.4 Parking the machine in secured condition Park the machine on level and firm ground. Set the throttle lever to position "MIN" (idle speed). ð Vibration is shut down. Fig. 39 NOTICE! Danger of engine damage! –... -
Page 53: Loading / Transporting The Machine
Loading / transporting the machine Loading / transporting the machine BPR 25/40 D... -
Page 54: Loading The Machine
Loading / transporting the machine – Loading the machine 7.1 Loading the machine Loads must only be attached and hoisted by an expert / qualified person. Do not use damaged or in any other way impaired lifting points. Use only lifting and lashing tackle with sufficient load bearing capacity for the weight to be loaded. -
Page 55: Lashing The Machine To The Transport Vehicle
Loading / transporting the machine – Lashing the machine to the transport vehicle 7.2 Lashing the machine to the transport vehicle Do not use damaged or in any other way impaired lifting points. Always use appropriate lifting and lashing tackle on the lifting and lashing points. -
Page 56: Transport Wheels
Loading / transporting the machine – Transport wheels 7.3 Transport wheels Protective equipment: Safety shoes Ä Chapter 6.4 Park the machine in secured condition „Parking the machine in secured condition“ on page 53. Pull out and turn the locking bolt (1). Move the steering rod to an upright position and engage the locking bolt securely. - Page 57 Loading / transporting the machine – Transport wheels Insert the transport wheel into the holding fixture. Fig. 47 Secure the transport wheel with the split pin. Install the second transport wheel on the opposite side and secure it with the split pin. Fig.
-
Page 58: Maintenance
Maintenance Maintenance BPR 25/40 D... -
Page 59: Preliminary Remarks And Safety Notes
Maintenance – Preliminary remarks and safety notes 8.1 Preliminary remarks and safety notes DANGER! Danger to life caused by an operationally unsafe machine! – The machine must only be serviced by quali- fied and authorized personnel. – Follow the safety regulations for maintenance Ä... -
Page 60: Fuels And Lubricants
Maintenance – Fuels and lubricants 8.2 Fuels and lubricants 8.2.1 Engine oil 8.2.1.1 Oil quality The following engine oil specifications are permitted: API CF/CH-4 or higher quality ACEA B3/E4 or higher quality Avoid mixing engine oils. 8.2.1.2 Oil viscosity Since engine oil changes its viscosity with the temperature, the ambient temperature at the operating location of the engine is of utmost importance when choosing the viscosity class (SAE-class). -
Page 61: Oil For Exciter Shaft Housing
Maintenance – Fuels and lubricants 8.2.2.2 Winter fuel For winter operation use only winter diesel fuel, to avoid clogging because of paraffin separation. At very low temperatures disturbing paraffin separation can also be expected when using winter diesel fuel. Diesel fuels suitable for temperatures down to -44 °C (-47 °F) are available for Arctic climates. - Page 62 Maintenance – Fuels and lubricants The viscosity index must be at least 150 (observe information of manufacturer). BPR 25/40 D...
-
Page 63: List Of Fuels And Lubricants
Maintenance – List of fuels and lubricants 8.3 List of fuels and lubricants Assembly group Fuel or lubricant Filling quantity Summer Winter Observe the level mark! Engine oil SAE 10W-40 0.9 l Ä Chapter 8.2.1 „Engine oil“ on page 63 Specification: (0.24 gal us) SAE 15W-40... -
Page 64: Running-In Instructions
Maintenance – Running-in instructions 8.4 Running-in instructions 8.4.1 General The following maintenance work must be performed when running in new machines or overhauled engines. 8.4.2 After 25 operating hours Ä Chapter 8.7.1 „Changing the engine Change the engine oil oil and cleaning the oil filter“ on page 72. Ä... -
Page 65: Maintenance Table
Maintenance – Maintenance Table 8.5 Maintenance Table Maintenance works Page Weekly 8.6.1 Checking, cleaning the air filter 8.6.2 Checking and cleaning the water separator Annually 8.7.1 Changing the engine oil and cleaning the oil filter 8.7.2 Changing the oil in the exciter housing 8.7.3 Replacing the air filter 8.7.4... -
Page 66: Weekly
Maintenance – Weekly 8.6 Weekly 8.6.1 Checking, cleaning the air filter NOTICE! Danger of engine damage! – Do not start the engine after having removed the air filter. B-SYM-1074 – If necessary, the air filter may be cleaned up to Fig. - Page 67 Maintenance – Weekly CAUTION! Danger of eye injuries caused by particles flying around! – Wear your personal protective equipment (safety gloves, protective working clothes, goggles). Blow the air filter out with dry compressed air (max. 5 bar B-GEN-0042 (73 psi)) from inside to outside by moving the gun up and down inside the element, until it is free of dust.
-
Page 68: Checking And Cleaning The Water Separator
Maintenance – Weekly 8.6.2 Checking and cleaning the water separator The service intervals for the water separator depend on the water content in the fuel and can therefore not be determined precisely. After taking the engine into operation you should B-SYM-1075 check for signs of water and dirt initially every day. -
Page 69: Annually
Maintenance – Annually 8.7 Annually 8.7.1 Changing the engine oil and cleaning the oil filter Change the engine oil at the latest after 250 oper- ating hours. NOTICE! Danger of engine damage! – Change the oil only with the engine at oper- ating temperature. - Page 70 Maintenance – Annually Cleaning the oil filter Loosen the screw (1) for approx. five turns and pull the oil filter (2) out of the housing. Fig. 58 CAUTION! Danger of eye injuries caused by particles flying around! – Wear your personal protective equipment (safety gloves, protective working clothes, goggles).
-
Page 71: Changing The Oil In The Exciter Housing
Maintenance – Annually Filling in engine oil Fill in new engine oil. After a short test run check the oil level on the dipstick; if nec- essary, top up to the top dipstick mark. Fig. 61 Final work Check oil filter and drain plug for leaks. Dispose of oil in an environmentally friendly way. -
Page 72: Replacing The Air Filter
Maintenance – Annually Tilt the machine to the opposite side and secure it properly. NOTICE! Components may get damaged! Do not use low-ash engine oils for the exciter shaft housing. Fill in new oil. B-692-0010 Fig. 63 Stand the machine horizontally and check the oil level. ð... -
Page 73: Replacing The Fuel Filter
Maintenance – Annually NOTICE! Danger of engine damage! – Prevent dirt from getting into the air intake opening. – Do not clean the air filter housing with compressed air. Clean the filter housing with a clean, lint-free cloth. Replace the air filter. Insert the air filter (1) carefully into the filter housing and fasten it with the knurled nut (2). -
Page 74: Replacing The V-Belt
Maintenance – Annually Pull the fuel filter out of the tank by the string. Pull the fuel hose (3) off the fuel filter (2). Take the fuel filter out of the bracket (1) and replace it with a new one. Plug on the fuel line. - Page 75 Maintenance – Annually Fasten the V-belt guard (1). B-692-0151 Fig. 70 8.7.5.1 Checking the frequency of the base plate Keep feet and hands clear of the vibrating base plate. CAUTION! Danger of injury caused by uncontrolled machine movement! – Always hold on to a running machine. –...
-
Page 76: Checking, Adjusting The Valve Clearance
Maintenance – Annually 8.7.6 Checking, adjusting the valve clearance NOTICE! Danger of engine damage! We recommend to have this work carried out by trained personnel or our after sales service. – Before checking the valve clearance let the engine cool down. Preparations Protective equipment: Working clothes... - Page 77 Maintenance – Annually Checking the valve clearance Valve clearance: Intake valve (IN) 0.20 mm (0.008 in) Exhaust valve (EX) 0.20 mm (0.008 in) Crank the engine, until the exhaust valve (EX) is fully open. Check the valve clearance on the intake valve (IN) with a feeler gauge (1), adjust if necessary.
-
Page 78: Replacing The Starter Rope
Maintenance – Annually Assemble covering (1) and air filter cover (2). After a short test run check the valve cover for leaks. Fig. 76 8.7.7 Replacing the starter rope Protective equipment: Working clothes Protective gloves Park the machine in secured condition Ä... - Page 79 Maintenance – Annually Thread in the new starter rope and fix it with knots on both ends . A = 15 mm (0.6 in) Fig. 79 Pre-tension the coil by approx. 4 rotations in direction of arrow. Thereby place the starter rope into the recess in the coil . Fig.
-
Page 80: Checking The Hydraulic Oil Level
Maintenance – Annually 8.7.8 Checking the hydraulic oil level Protective equipment: Working clothes Protective gloves Ä Chapter 6.4 Park the machine in secured condition „Parking the machine in secured condition“ on page 53. Adjust the steering rod with height adjustment so that the area with the filler plug is horizontal. - Page 81 Maintenance – Annually Press the travel lever forward against the end stop and hold it in this position. Fig. 86 Place a cloth underneath the bleeding screw to collect leaking oil. Slacken the bleeding screw. Wait until all air has escaped and then tighten the bleeding screw.
-
Page 82: Every 2 Years / Every 500 Operating Hours
Maintenance – Every 2 years / every 500 operating hours 8.8 Every 2 years / every 500 operating hours 8.8.1 Changing the hydraulic oil Protective equipment: Working clothes Safety shoes Protective gloves Ä Chapter 6.4 „Parking the machine Park the machine safely in secured condition“... - Page 83 Maintenance – Every 2 years / every 500 operating hours NOTICE! Components may get damaged! – Use only oil of the permitted specifica- tion. 40 mm Fill in hydraulic oil up to the mark on the steering rod head. Mark: approx. 40 mm (1.6 in) below the filler opening B-692-0047 Fig.
-
Page 84: As Required
Maintenance – As required 8.9 As required 8.9.1 Cleaning the cooling fins and the cooling air intake openings How dirty the cooling fins and cooling air intake openings are depends very much on the daily operating conditions; clean daily if necessary. Protective equipment: Working clothes Protective gloves... -
Page 85: Checking The Oil Level In The Exciter Housing
Maintenance – As required Unscrew the V-belt guard (1). B-692-0151 Fig. 98 Check condition and tension of V-belt. ð Compression measurement: 5 - 15 mm (0.2 - 0.6 in). The V-belt cannot be re-tightened. Replace the V-belt if it is damaged or if the compression Ä... -
Page 86: Cleaning The Machine
Maintenance – As required Protective equipment: Working clothes Safety shoes Protective gloves Park the machine on level ground. Park the machine safely Ä Chapter 6.4 „Parking the machine in secured condition“ on page 53. Allow the machine to cool down. Clean the area around the bleeding screw (1) and filling/drain plug (2). -
Page 87: Measures Prior To Extended Shut-Down Period
Maintenance – As required 8.9.5 Measures prior to extended shut-down period 8.9.5.1 Measures before shutting down If the machine is shut down for a longer period of time, e.g. winter season, the following work must be carried out: Clean the machine thoroughly. Clean the water separator. -
Page 88: Troubleshooting
Troubleshooting Troubleshooting BPR 25/40 D... -
Page 89: Preliminary Remarks
Troubleshooting – Preliminary remarks 9.1 Preliminary remarks Malfunctions are frequently caused by incorrect operation of the machine or insufficient maintenance. Whenever a fault occurs you should therefore thoroughly read these instructions on correct operation and maintenance. If you cannot locate the cause of a fault or rectify it yourself by fol- lowing the trouble shooting chart, you should contact our customer service department. -
Page 90: Malfunctions During Operation
Troubleshooting – Malfunctions during operation 9.2 Malfunctions during operation Fault Possible cause Remedy The machines Air in the hydraulic system of the steering Release pressure from the steering rod vibrates forward with a strongly The oil level in the exciter shaft housing Check the oil level in the exciter shaft reduced speed is too low... -
Page 91: Engine Faults
Troubleshooting – Engine faults 9.3 Engine faults Fault Possible cause Remedy No or poor starting Fuel tank empty Check the fuel level, top up if necessary of engine Fuel filter clogged Check the fuel filter, replace if necessary Fuel lines leaking Check the fuel lines Incorrect valve clearance Check, adjust the valve clearance... - Page 92 Troubleshooting – Engine faults Fault Possible cause Remedy Engine overheating Engine oil level too high Check, drain off if necessary Lack of cooling air Cleaning the cooling fins and the cooling air intake openings. Check air guide plates and ducts for com- pleteness and good sealing.
-
Page 93: Disposal
Disposal Disposal BPR 25/40 D... -
Page 94: Final Decommissioning Of Machine
Disposal – Final decommissioning of machine 10.1 Final decommissioning of machine If the machine can no longer be used and needs to be finally decommissioned, you must carry out the following work and have the machine disassembled by an officially recognized recycling company. -
Page 95: List Of Special Tools
List of special tools List of special tools BPR 25/40 D... - Page 96 List of special tools Sirometer Measuring instrument for speed and frequency BOMAG 059 710 02 Fig. BPR 25/40 D...
- Page 97 Discount-Equipment.com is your online resource for quality parts & equipment. Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101 Need parts? Click on this link: http://www.discount-equipment.com/category/5443-parts/ choose one of the options to help get the right parts and equipment you are looking for.
