• Altitude Hold: Holds current Altitude Reference.
Annunciation (Active):
Annunciation (Armed):
If Altitude Hold is active, the actual plane's altitude at the moment the
pilot presses ALT Button will show in green. If Altitude Hold is active
and the pilot changes the Autopilot Altitude Reference, the displayed
Altitude will display the Autopilot ALtitude Reference ±
• Flight Level Change: Holds aircraft airspeed while aircraft
is climbing/descending to the Selected Altitude.
Annunciation (Active):
Annunciation (Armed):
• Vertical Speed: Holds aircraft vertical speed; may be
used to climb/descend to the Selected Altitude.
Annunciation: VS VS
• Autoplit Altitude: Shows the Autopilot Altitude Reference.
Annunciation: ± XXXXX ± XXXXX
• Altitude Alert
Annunciation: ALERT ALERT
10
ALT ALT and ± ± XXXXX XXXXX
FT FT
ALT ALT
± XXXXX XXXXX
FLC FLC and ± ± XXX XXX
KT KT
FLC FLC and ± XXX ± XXX
KT KT
and ± ± XXXX XXXX
FPM FPM
FT FT
(flashing or static)
Illuminates as a solid alert in the region from 1000 to 200 feet from
the selected altitude if the airplane was previously outside of this
region. Flashes for 5 seconds the first time the airplane crossed the
selected altitude. Flashes continuously in the region from 1000 to
200 feet from the selected altitude if the plane was previously inside
of this region.
AUDIO PANEL
.
FT FT
To access the Audio Panel, touch the upper part of the screen
and slide down with your finger, the following menu will
appear. Below you will see the functionalities of each option.
• COM1: When selected, audio from the #1 COM receiver
can be heard.
