- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. DYNA-GLO LPFA150WH-1 Owner's Manual Shop genuine replacement parts for DYNA-GLO LPFA150WH-1 Find Your DYNA-GLO HVAC Parts - Select From 146 Models -------- Manual continues below --------...
- Page 2 PROPANE CONSTRUCTION HEATER USER’S MANUAL AND OPERATING INSTRUCTIONS MODELS: LPFA40WH (40,000 BTU/HR, FORCED - AIR) LPFA60WH (30,000/60,000 BTU/HR, FORCED - AIR) LPFA125WH (70,000/125,000 BTU/HR, FORCED - AIR) LPFA150WH (120,000/150,000 BTU/HR, FORCED - AIR) ANS Z83.7-2011 CSA 2.14-2011 Adequate ventilation must be provided. GENERAL HAZARD WARNING FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS,...
-
Page 3: Table Of Contents
PROPANE CONSTRUCTION HEATER TABLE OF CONTENTS Introduction & Specifications ..........3 •... -
Page 4: Introduction & Specifications
PROPANE CONSTRUCTION HEATER PROPANE FORCED AIR CONSTRUCTION HEATERS The heater is designed and approved for use as a construction heater under ANS Z83.7 CSA 2.14. It is hard CHECK WITH YOUR LOCAL FIRE SAFETY to anticipate every use which may be made of this heater. AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS. -
Page 5: General Safety Instructions
PROPANE CONSTRUCTION HEATER GENERAL SAFETY INSTRUCTION Accidents are always tragic especially because so many of them could have been prevented with little care and judgment. There are some basic good practices, we hope you will follow for safe use of your heater. IMPORTANT SAFETY INSTRUCTION •... -
Page 6: Unpacking Heater
PROPANE CONSTRUCTION HEATER UNPACKING HEATER 1. Remove heater from carton. 2. Remove all protective packing applied to heater for shipment. 3. Retain cartons and packaging material until unit is operated and found in good condition. 4. Check heater for any shipping damage. If heater shows any external or internal damage, promptly inform dealer/distributor where you purchased heater. -
Page 7: Size & Capacity Of Propane Cylinders
PROPANE CONSTRUCTION HEATER INFORMATION ON SIZE * CAPACITY OF PROPANE GAS CYLINDERS: The chart below shows the number and size of propane tanks needed to run this heater. *Less gas is vaporized at lower temperatures. You may need two or more 100 pound (45 kg) tanks or one larger tank in colder weather. (See the parts list for your model of heater to get the specified regulator assembly.) Number of Tanks Temperature... -
Page 8: Installation To The Propane Gas Tank
PROPANE CONSTRUCTION HEATER INSTALLATION TO THE PROPANE GAS TANK IMPORTANT: You must use a propane/LP gas supply cylinder that is compatible with the connection device provided with the hose and regulator. Regulator Propane/LP Supply Valve Propane/LP Fuel Gas Tank Fitting Hose to Heater Hose to Regulator... -
Page 9: Leak Checking & Positioning Heater
PROPANE CONSTRUCTION HEATER PROPANE SAFETY Propane is safe to use when properly handled. Careless handling of the Propane gas tank could result in fire and/or an explosion. Therefore: • Always keep tank/cylinder securely fastened in an upright position. • Avoid tipping tank on its side when connected to a regulator since this may cause damage to diaphragm in regulator. -
Page 10: Test Firing Heater & Storage
PROPANE CONSTRUCTION HEATER SHUTDOWN INSTRUCTIONS WARNING : Motor and fan must be running before lighting, during operation and at shutdown, in order to prevent a flame-out condition which could result in personal injury or property damage. Turn gas valve knob clockwise to OFF position. -
Page 11: Troubleshooting
PROPANE CONSTRUCTION HEATER TROUBLESHOOTING TROUBLESHOOTING: PROBLEM POSSIBLE C AUSE CORRECTIVE A CTION 1. Control d ial i s o ff a nd u nit i s 1. This h eater u ses a c on4nuous s park 1. -
Page 12: Wiring Diagrams
PROPANE CONSTRUCTION HEATER WIRING DIAGRAMS NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! - Page 13 PROPANE CONSTRUCTION HEATER WIRING DIAGRAMS 100K,125K & 150K Models only 100K,125K & 150KSólo modelos 100K,125K & 150K Les modèles Seulement NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
-
Page 14: Replacement Parts List
PROPANE CONSTRUCTION HEATER REPLACEMENT PARTS LIST MODELS: LPFA40WH LPFA60WH NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! - Page 15 PROPANE CONSTRUCTION HEATER REPLACEMENT PARTS LIST PART N UMBER ITEM N o. DESCRIPTION LPFA40WH LPFA60WH INNER S HELL A SSEMBLY 2304818 2304818 NOZZLE *2304829 *2325121 FLAME C AP 2304819 2325120 THERMAL S WITCH B RACKET 2304826 2304826 THERMAL ...
-
Page 16: Gfa100 / Gfa125A / Gfa150A
PROPANE CONSTRUCTION HEATER PROPANE CONSTRUCTION HEATER ILLUSTRATED / PARTS BREAKDOWN MODELS: LPFA125WH LPFA150WH NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! - Page 17 PROPANE CONSTRUCTION HEATER REPLACEMENT PARTS LIST PART N UMBER ITEM DESCRIPTION No. LPFA125WH LPFA150WH INNER ...
-
Page 18: Warranty
WARRANTY LIMITED WARRANTY: This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale (lifetime warranty for the brass nozzle burner only). GHP Group, Inc., at it’s option, will either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase. - Page 19 WARRANTY REGISTRATION IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14) days of date of purchase. You can also register your warranty on the internet at www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card for your records.
