Standard Equipment Set - NAVTELECOM SMART S-2425 Operation Manual

№
1 Device unit
2 14-pin connector of Microfit-14 with two power wires
3 Cable set of 5 installation wires
4 Interface cable with MiniUSB connector
5 Passport
6 Package
Some cases may require connection of additional equipment not included in the standard equipment set, for example:
 fuse and fuse holder;
 fuel level sensor;
 external LED;
 temperature sensor;
 TouchMemory contact key reader.

1.6 Standard equipment set

Name
Figure 4. 14-pin connector of Microfit-14
Figure 5. Interface cable with MiniUSB connector
Figure 6. Fuse and fuse holder
Version of complete set
Number of pieces
1
1
1
1
1
1
Tab. 2
A B
+ +
+ +
+ +
+
+ +
+
