Standard Equipment Set - NAVTELECOM SIGNAL S-2651 Operation Manual

№
1 SIGNAL device unit
2 GLONASS/GPS-antenna
3 GSM-antenna
4 Fuse 1 А
5 Fuse holder
6 14-pin connector of Microfit-14 with two power wires
7 6-contact connector of Microfit-6 type
8 4-contact connector of Microfit-4 type
9 Cable set of 10 installation wires
10 Passport
11 Interface cable with MiniUSB connector
12 Package

1.6 Standard equipment set

Name
Figure 4. GLONASS/GPS-antenna
Figure 5. GSM-antenna
Figure 6. Fuse and fuse holder
Version of complete set
Number of pieces
1
1
1
2
1
1
1
1
1
1
1
1
Tab. 2
A B
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+ +
+
+
