Support and E-Warranty Certificate
https://www.vevor.com/support
KTCHENL CART WITH WIRE BASKETS
B1Q01001
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and doses not necessarily mean to
cover all categories of tools offered by us.
You are kindly reminded to verify carefully when you are placing an order with
us if you are actually saving half in comparison with the top major brands.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B1Q01001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VEVOR B1Q01001

  • Page 1 Support and E-Warranty Certificate https://www.vevor.com/support KTCHENL CART WITH WIRE BASKETS B1Q01001 USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us.
  • Page 3 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...
  • Page 4: Product Parameters

    Static load bearing Dynamic load bearing Model NO. Max. 470 Pounds Max. 352.4 Pounds B1Q01001 (About 213.2 Kg) (About 160 Kg) CAUTION 1.Place the weight evenly on the three layers of steel plateto achievethe maximum bearing capacity! 2.Do not place all the weights on the same layer ! 3.The placement time under the maximum load bearing capacity shall not exceed 1 hour !
  • Page 5 PRODUCT PARAMETERS For additional information regarding the parts listed below, please refer to the Assembly Diagram of this manual. Unwrap and separate all parts in a clear work area. Bottom net Name Panel frame Pull the basket Whippletree frame Parts 1PCS 2PCS 1PCS...
  • Page 6: Assembly Steps

    ASSEMBLY STEPS STEP 1: Install the plastic clip (F) on the lower clip slot of each steel pipe. Make sure the arrow of all plastic clips(E) is pointed up, and the grooves of the pole are covered by the convex line of the plastic clips. Plastic Clips' arrow shall be pointed up! STEP 2:...
  • Page 7 STEP 3: Refer to Step 1, install plastic clips (F) at the height of 4 steel pipes(E) and install horizontal bars (D) at the top of both steel pipes, as shown in the figure below. STEP 4: Refer to Step 1 again, install the plastic clip (F) at the end and equal height of the 4 steel pipes respectively;...
  • Page 8 STEP 5: Screw the pulley (G) and the pulley (with gate) (H) clockwise from the screw hole at the bottom of the steel pipe (E), respectively. STEP 6: Position the basket (B) at the (D) card slot of the bar and push to complete the installation.
  • Page 9 STEP 7: After the Pull the basket(B) is installed,install the screws and nuts(I) to prevent the basket from coming out. Note: The pulley (H) shall be installed on the same side!
  • Page 10 Manufacturer: Guangdong Shunde Heavybao Commercial Kitchenware Co.,Ltd Address: No.3, Shatou Chung West Road, Jun'an Town, Shunde District, Foshan City, Guangdong Province, China Made in China EUREP UK LTD UK REP UNIT 2264, 100 OCK STREET, ABINGDON OXFORDSHIRE ENGLAND OX14 5DH Importer: FREE MOOD LTD Address: 2 Holywell Lane, London, England, EC2A 3ET EUREP GmbH...
  • Page 12 TOUGH TOOLS, HALF PRICE Support and E-Warranty Certificate https://www.vevor.com/support...
