Tyco SYSTEM 800 Installation Instructions Manual
Intrinsically safe mx addressable fire detection system
Hide thumbs
Also See for SYSTEM 800:
- Service and maintenance instructions (8 pages) ,
- Installation and commissioning instructions (4 pages)
Advertisement
Quick Links
DOCUMENT CONTROL NUMBER
SYSTEM 800 - INTRINSICALLY SAFE MX ADDRESSABLE
1.
INTRODUCTION
2.
GENERAL
3.
CERTIFICATION REQUIREMENTS
3.1
SYSTEM 800 - BASEEFA
CERTIFICATE
3.1.1 EQUIPMENT INSTALLED IN
SAFE AREA
3.1.2 EQUIPMENT PERMITTED
IN HAZARDOUS AREA
3.2
ISOLATED SOUNDER SYSTEM -
BASEEFA CERTIFICATE Ex872028 4
3.2.1 EQUIPMENT INSTALLED IN
SAFE AREA
3.2.2 EQUIPMENT PERMITTED
IN HAZARDOUS AREA
4.
CHECKING THE EQUIPMENT
www.acornfiresecurity.com
FIRE DETECTION SYSTEM
INSTALLATION INSTRUCTIONS
3
3
3
3
4
4
4
5
5
www.acornfiresecurity.com
EQUIPMENT:
PUBLICATION:
ISSUE No.
DATE:
&
/
5.
MOUNTING THE EQUIPMENT
5.1
I.S. INTERFACE
5.2
DETECTORS AND CALLPOINTS
5.3
SOUNDERS
5.4
SYSTEM CONDUITS AND CABLES 5
6.
INITIAL CONNECTIONS
7.
CONTINUITY
INSULATION TESTS
&
7.1
CONTINUITY TESTS
7.2
HIGH-VOLTAGE INSULATION
TESTS
8.
FINISHING OFF
I.S. SYSTEM 800
17A-13-I
1
1/03
5
5
5
5
6
6
6
6
6
Advertisement
Related Manuals for Tyco SYSTEM 800
Summary of Contents for Tyco SYSTEM 800
- Page 1 I.S. SYSTEM 800 EQUIPMENT: PUBLICATION: 17A-13-I ISSUE No. DATE: & 1/03 DOCUMENT CONTROL NUMBER SYSTEM 800 - INTRINSICALLY SAFE MX ADDRESSABLE FIRE DETECTION SYSTEM INSTALLATION INSTRUCTIONS INTRODUCTION MOUNTING THE EQUIPMENT I.S. INTERFACE DETECTORS AND CALLPOINTS GENERAL SOUNDERS SYSTEM CONDUITS AND CABLES 5...
- Page 2 I.S. SYSTEM 800 17A-13-I 1/03 LIST OF FIGURES Fig. 1 Overall and Fixing Dimensions for UC2 4-Way Housing Fig. 2 Overall and Fixing Dimensions for UC4 8-Way Housing Fig. 3 DX070 Overall Dimensions showing mounted MTL5000 modules Fig. 4 DX170 Overall Dimensions showing mounted MTL5000 modules Fig.
- Page 3 Safe Area (ie, an area with no definable hazard). Isolating I.S. interfaces and isolating sounder Note: In the I.S. manual for System 800, the words drivers if used exclusively in floating systems do not require a ‘Isolating Interface’...
- Page 4 Maximum of 30 Any Simple Apparatus Simple Apparatus Any Number per IF800Ex Table. 2 System 800 - Equipment Permitted in Hazardous Area 3.2.1 EQUIPMENT INSTALLED IN SAFE ISOLATED SOUNDER SYSTEM AREA BASEEFA CERTIFICATE Ex872028 The apparatus which can be installed in the Safe Area is This system provides an Intrinsically Safe fire alarm detailed in Table 3.
- Page 5 BS EN 60079-14). c) Ensure physical separation of at least 50mm is maintained between the I.S. and Non-I.S. wiring throughout, including inside the I.S. Interface. © 2003 Tyco Safety Products PAGE 5 of 14 www.acornfiresecurity.com...
- Page 6 I.S. SYSTEM 800 17A-13-I 1/03 d) Bond the steel conduit or copper sheath of b) To check the continuity of the cable screen, MICC cable to earth at one point only within short circuit the screen and one end of the the Hazardous Area.
- Page 7 I.S. SYSTEM 800 EQUIPMENT: PUBLICATION: 17A-13-I ISSUE No. DATE: & 1/03 INTERNAL FIXING Fig. 1 Overall and Fixing Dimensions for UC2 4-Way Housing - for I.S. Sounder Driver/EXI800 MX Loop Interface/Galvanic Isolator © 2003 Tyco Safety Products PAGE 7 of 14 www.acornfiresecurity.com...
- Page 8 I.S. SYSTEM 800 17A-13-I 1/03 KNOCKOUT HOLE NOTE: SCREW ON FIXING LUGS MAY BE POSITIONED AS SHOWN ADD 5mm TO DEPTH IF FIXING LUGS USED Fig. 2 Overall and Fixing Dimensions for UC4 8-Way Housing- for I.S.Sounder Driver/EXI800 MX Loop Interface/...
- Page 9 I.S. SYSTEM 800 EQUIPMENT: PUBLICATION: 17A-13-I ISSUE No. DATE: & 1/03 Fig. 3 DX070 Overall Dimensions Showing Mounted MTL5000 modules © 2003 Tyco Safety Products PAGE 9 of 14 www.acornfiresecurity.com...
- Page 10 I.S. SYSTEM 800 17A-13-I 1/03 Fig. 4 DX170 Overall Dimensions Showing Mounted MTL5000 modules PAGE 10 of 14 www.acornfiresecurity.com...
- Page 11 I.S. SYSTEM 800 EQUIPMENT: PUBLICATION: 17A-13-I ISSUE No. DATE: & 1/03 THIS PAGE INTENTIONALLY LEFT BLANK © 2003 Tyco Safety Products PAGE 11 of 14 www.acornfiresecurity.com...
- Page 12 I.S. SYSTEM 800 17A-13-I 1/03 Fig. 5a) I.S. Interconnection Diagram to MX Addressable Fire Detection Systems PAGE 12 of 14 www.acornfiresecurity.com...
- Page 13 I.S. SYSTEM 800 EQUIPMENT: PUBLICATION: 17A-13-I ISSUE No. DATE: & 1/03 Fig. 5b) I.S. Interconnection Diagram to MX Addressable Fire Detection Systems www.acornfiresecurity.com...
- Page 14 I.S. SYSTEM 800 17A-13-I 1/03 Fig. 6 S27li+ Wiring Diagram for Hazardous Areas PAGE 14 of 14 www.acornfiresecurity.com...
