LIGHT TRUSS BAT 41
User Manual – Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIGHT TRUSS BAT 41 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mark LIGHT TRUSS BAT 41

  • Page 1 LIGHT TRUSS BAT 41 User Manual – Version 1.0...
  • Page 2: Safety Instructions

    8. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 9. Only use attachments/accessories specified by MARK PRO. 10. Unplug this device during lightning storms or when unused for long periods of time.
  • Page 3 OVERVIEW LIGHT TRUSS BAT 41 is a lighting projector very adequate for truss lighting. It includes 3x 4W RGBW (4 in 1) LEDs. These brilliant LEDs allow to obtain a rich colour spectrum mixing the red, green, blue and white colours. The configuration interface has a display with all the information and buttons to navigate through menus, selecting parameters such as: manual level of each colour, strobe or inner effects.
  • Page 4: Installation

    Rechargable Lithium ion battery - 6x cells, 18650 type - 4400 mA - 4-5 hours of charge time INSTALLATION This product is only suitable for professional use. This device should be kept dry to avoid moisture, overheating or dusty environment. Ensure that the unit does not come into contact with water or any other liquid.
  • Page 5 Connect the DMX512 input terminal to the controller. After that, connect the output terminal to the next device. Repeat this step with all fixtures in the chain. To prevent system errors, the last device in a DMX chain needs to be equipped with a terminating resistor (120 ohm, 1/4 Watt). Pin occupation Pin 1: Ground Pin 2: Pin -...
  • Page 6: Advanced Use

    ADVANCED USE RECARGABLE BATTERY The unit can operate with the internal battery after to be charged. The process is automatic while the device is connected to an adequate AC plug. You can check the charge level through LED bar closed the switches.
  • Page 7 In the following table are shown all the options displayed in the menu interface to configure the LIGHT TRUSS BAR 41: Display Function d001 – d511 (DMX starting channel) SLAu Slave operation r000 – r255 (Red colour dimming) g000 – g255 (Green colour dimming) b000 –...
  • Page 8 R dimming Red dimming from minimum to maximum 0 - 255 G dimming Green dimming from minimum to maximum 0 - 255 B dimming Blue dimming from minimum to maximum 0 - 255 W dimming White dimming from minimum to maximum 0 - 255 8 channels mode No Function...
  • Page 9 5. Do not replace with non-original spare parts. Contact your MARK PRO dealer. Unpacking Note: Before unpacking, check it for possible damage that might have occurred during transportation. If you find any damage, please do not use the unit and contact the MARK PRO dealer.
  • Page 10: Troubleshooting

    This short guide is meant to help and try to solve simple problems. If they continue and the device cannot operate, please, don’t try to repair it by yourself, return the device to your MARK PRO dealer. If a problem occurs, carry out the following steps in sequence until find the problem solved. If the light effect does not operate properly, refer servicing to a technician.
  • Page 11: Indicaciones De Seguridad

    8. Proteja el cable de alimentación para no ser pisado o manipulado, particularmente en los conectores (mural y de entrada a la unidad). 9. Utilice únicamente accesorios especificados por MARK PRO. 10. Desconecte el dispositivo si no va a ser utilizado durante largos periodos de tiempo.
  • Page 12 17. Este dispositivo incluye una batería recargable (de ión de litio). Por favor, siga las leyes locales para ocuparse de la batería, retirándola del dispositivo y reciclándola en una planta de reciclaje adecuada.
  • Page 13: Vista General

    VISTA GENERAL LIGHT TRUSS BAT 41 es un proyector de iluminación muy adecuado para iluminar trusses. Incluye 3 LEDs RGBW (4 en 1) de 4W cada uno. Estos brillantes LEDs permiten obtener un rico espectro de colores mezclando los colores rojo, verde, azul y blanco.
  • Page 14: Instalación

    LIGHT TRUSS BAT 41 se puede colocar en una superficie plana y estable o en un soporte, pero el modo de funcionamiento común es el rigging en un sistema truss. Por favor, compruebe y siga las siguientes...
  • Page 15 Conecte el terminal de entrada DMX512 al controlador. Después, conecte el terminal de salida al siguiente dispositivo. Repita el paso anterior para conectar otro dispositivo y así sucesivamente. Para evitar errores en el sistema, el último dispositivo de una cadena DMX debe estar equipado con una resistencia de terminación (120 Ohmios, 1/4 W).
  • Page 16 Para el uso con batería, presione el interruptor Battery Switch. Para funcionar conectado a una toma AC, presione ambos interruptores (Battery switch y Power switch) LIGHT TRUSS BAT 41 incorpora un mando remoto que integra las funciones básicas: - Cambio de color - Modos automáticos...
  • Page 17 Utilice los botones UP y DOWN para navegar entre cada función para seleccionar el valor correcto. (Pulse ENTER para confirmar la configuración). En la siguiente tabla se muestran todas las opciones para configurar el LIGHT TRUSS BAT 41 en la interfaz del menú: Display Función...
  • Page 18 MODO DE CONTROL DMX Las siguientes tablas muestran las funciones de los canales DMX: Modo de 4 canales No Función Descripción Valor Dimmer R Dimmer Rojo de mínimo a máximo 0 - 255 Dimmer G Dimmer Verde de mínimo a máximo 0 - 255 Dimmer B Dimmer Azul de mínimo a máximo...
  • Page 19 Program 6 180 - 215 Program 7 216 - 251 Program 8 252 - Rojo 0 – 20 Verde 21 – 42 Azul 43 – 64 Blanco 65 – 85 Amarillo 86 - 107 Cyan 108 - 128 Colores estáticos (Cuando Violeta 129 - 150 Program 1 en CH 3 está...
  • Page 20 Si el dispositivo tiene un problema, siga los siguientes puntos hasta que lo encuentre y pueda solucionarlo. Si la iluminación no funciona correctamente, envíe el dispositivo al servicio técnico MARK PRO. Si el dispositivo no enciende: Posibles problemas: Fuente de alimentación.
  • Page 21 4- Si usted no puede determinar la causa de los problemas que presenta la unidad, no la desmonte o intente reparar por sí mismo ya que perderá la garantía. 5- Devuelva la unidad a servicio técnico de MARK PRO. Si no responde el protocolo DMX: Posibles problemas: Verifique que el cable de conexión DMX está...
