www.
.ch
WA 1658
User manual
Washing machine
0848 559 111
www.fust.ch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOVAMATIC WA 1658 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FUST NOVAMATIC WA 1658

Summary of Contents for FUST NOVAMATIC WA 1658

  • Page 1 WA 1658 User manual Washing machine 0848 559 111 www.fust.ch...

  • Page 2: Table Of Contents

    Contents Safety information Helpful hints and tips Product description Care and cleaning Control panel What to do if… First use Technical data Personalization Consumption values Daily use Installation Washing programmes Environment concerns Subject to change without notice Safety information • Any objects such as coins, safety pins, Important! Read carefully &...
  • Page 3 • When unpacking the appliance, check that • Never pull the power supply cable to re- it is not damaged. If in doubt, do not use it move the plug from the socket; always and contact the Service Centre. take hold of the plug itself. •...

  • Page 4: Product Description

    Product description Product description Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. The NEW JET system allows total use of detergent and reduces water consumption so saving energy. Detergent dispenser drawer Rating plate Control panel Drain pump...

  • Page 5: Control Panel

    Control panel Below is a picture of the control panel. It shows the programme selector dial as well as the buttons and the display. These are presented by relevant numbers on the fol- lowing pages. Programme selector dial DELAY START button ( ZEITVORWAHL - DEPART DIFFERE ) TEMPERATURE button ( TEMP.

  • Page 6: First Use

    • The programme progress display shows – After the programme has started, the the washing phases of the selected pro- time remaining is updated every minute. gramme. • Delay start • During a washing cycle, a black line blinks – The selected delay (20 hours max) set under the washing phase symbol of the by means of the relevant button appears running programme.

  • Page 7: Daily Use

    dren might be injured by or cause damage to There are two different ways to set this op- the appliance. tion: This function remains able also when the • Before pressing button 7 : it will be impos- washing machine is not working. sible to start the machine.
  • Page 8 Select the required programme by proposes the maximum spin speed pro- vided for that programme. means of programme selector dial (1) You can choose the right programme for any Press this button repeatedly to change the type of laundry following the descriptions on spin speed, if you want your laundry to be the washing programme tables (see «Wash- spun at a speed different from the one pro-...
  • Page 9 has been set. Press the same button to de- If you wish to activate this option permanently activate the option. press simultaneously buttons 2 and 3 for After selecting the options, wait about few some seconds: the relevant symbol appears seconds until the display gets back to the on the display.
  • Page 10 and then by 1 hour up to a maximum of 20 starts blinking. Press the button again to re- hours by means of this button. start the programme. The selected delay time value will appear on Cancelling a programme the display for about 3 seconds, then the du- Turn the selector dial to to cancel a pro- ration of the programme will appear again.

  • Page 11: Washing Programmes

    open to prevent the formation of mildew and unpleasant smells. Stand by : once the programme has finished is reduced. By pressing any button the ap- after a few minutes the energy saving system pliance will come out of the energy saving will be enabled.
  • Page 12 Programme Maximum and Minimum Temperature Detergent Com- Cycle Description Options partment Maximum Fabrics Load Type of Laundry SPIN REDUCTION PFLEGELEICHT -SYNTHETIQUES SYNTHETICS NIGHT CYCLE 60°- Cold RINSE HOLD Main wash - Rinses - Short spin PREWASH Max. load 4 kg - Reduced load 2 kg STAIN Synthetic or mixed fabrics: underwear, coloured SENSITIVE...
  • Page 13 Programme Maximum and Minimum Temperature Detergent Com- Cycle Description Options partment Maximum Fabrics Load Type of Laundry SPIN REDUCTION SCHLEUDERN - ESSORAGE SPIN Drain and long spin Max. load 8 kg Separate spin for hand washed cotton garments and after programmes with the option selected that ends with water left in the tub.
  • Page 14 Programme Maximum and Minimum Temperature Detergent Com- Cycle Description Options partment Maximum Fabrics Load Type of Laundry SPIN REDUCTION SPORT INTENSIV - SPORT SPORT INTENSIVE NIGHT CYCLE 40° - Cold RINSE HOLD Prewash - Main wash - Rinses - Short spin EXTRA RINSE Max.

  • Page 15: Helpful Hints And Tips

    Programme Maximum and Minimum Temperature Detergent Com- Cycle Description Options partment Maximum Fabrics Load Type of Laundry / AUS ARRET = OFF For cancelling the programme which is running or to switch the machine off . 1) If using liquid detergents, a programme without prewash must be selected. 2) Stain option can be selected only at the temperature of 40°C or higher.

  • Page 16: Care And Cleaning

    The choice of detergent will depend on the Quantity of detergent to be used type of fabric (delicates, woollens, cottons, The type and quantity of detergent will de- etc.), the colour, washing temperature and pend on the type of fabric, load size, degree degree of soiling.
  • Page 17 3. Clean all parts with water. 4. Put the conditioner insert in as far as it will Drain pump go, so that it is firmly in place. 5. Clean all parts of the washing machine, The pump should be inspected regularly and especially the nozzles in the top of the particularly if: washing-in chamber, with a brush.
  • Page 18 water in the pump. Never remove the pump cover during a wash cycle, always wait until the appliance has finished the cycle, and is empty. When replacing the cover, ensure it is securely retightened so as to stop leaks and young children being able to remove it. Cleaning the water inlet filters Important! If the appliance doesn't fill, takes long to fill water, the starting button blinks...

  • Page 19: What To Do If

    7. Screw the hose back to the machine and By doing this, any water remaining in the ma- make sure the connection is tight. chine is removed, avoiding ice forming and consequently damage to the appliance. When you use the machine again, make sure that the ambient temperature is above 0°C.
  • Page 20 Problem Possible cause/Solution The door has not been closed. • Close the door firmly. The plug is not properly inserted in the power socket. • Insert the plug into the power socket. There is no power at the socket. • Please check your domestic electrical installa- tion.
  • Page 21 Problem Possible cause/Solution Too much detergent or unsuitable detergent (cre- ates too much foam) has been used. • Reduce the detergent quantity or use another one. Check whether there are any leaks from one of the inlet hose fittings. It is not always easy to see this as the water runs down the hose;...

  • Page 22: Technical Data

    Problem Possible cause/Solution The electronic unbalance detection device has cut in because the laundry is not evenly distrib- uted in the drum. The laundry is redistributed by reverse rotation of the drum. This may happen several times before the unbalance disappears Spinning starts late or the machine does not and normal spinning can resume.

  • Page 23: Consumption Values

    Spin Speed Maximum 1600 rpm Consumption values Programme Energy consumption Water consumption Programme duration (KWh) (litres) (Minutes) White Cottons 95° Cottons 60° Cotton Energy Saving 1.20 For the duration of the programmes, Programme 60° please refer to the Cottons 40° 0.97 display on the con- trol panel.
  • Page 24 plug caps supplied in the bag containing the instruction booklet. 4. Slide out the relevant plastic spacers. 7. Connect the water inlet hose as descri- bed under the paragraph «Water inlet». Positioning and levelling Install the machine on a flat hard floor. Make sure that air circulation around the ma- chine is not impeded by carpets, rugs etc.
  • Page 25 Please ensure that when the appliance is in- stalled, it is easily accessible for the engineer in the event of a breakdown. Carefully level by screwing the adjustable feet in or out. Never place cardboard, wood or similar materials under the machine to com- pensate for any unevenness in the floor.

  • Page 26: Environment Concerns

    This could be done by tying it to the tap with a piece of string or attaching it to the wall. 2. In a sink drain pipe branch. This branch must be above the trap so that the Water drainage bend is at least 60 cm above the ground.
  • Page 27 product, please contact your local council, • Normally soiled laundry may be washed your household waste disposal service or the without prewashing in order to save deter- shop where you purchased the product. gent, water and time (the environment is protected too!).
  • Page 28 Warranty / customer service Garantiebedingungen / Kundendienst For each product we provide a two-year guarantee from the date of purchase or Für jedes Produkt gewähren Wir ab Verkauf delivery to the consumer (with a guarantee bzw. Lieferdatum an den Endverbraucher certificate, invoice or sales receipt serving as eine Garantie von 2 Jahren.
  • Page 29 Our customer service telephone number: 0848 559 111 oder unter ou sur Internet oppure su Internet or in the internet www.fust.ch Dipl. Ing FUST AG Dipl. Ing. FUST AG Dipl. Ing. FUST AG Ing. dipl. FUST SA Buchental 4 Riedmoosstrasse An der Rheinstrasse Hyper-Fust Romanel Centre 9245 Oberbüren...
  • Page 32 www. 132947460 - 00 - 062010...
