Thank you for purchasing the ACM5504-5-G-I Remote Infrastructure Management (RIM)
appliance. This Quick Start walks you through both installation and configuration. For
more details refer to the
Step1 Check kit contents
Step 2 Configure the hardware
Attach rubber feet to base. Also attach the desired mounting tab and screw the
3G antenna on to the main
Note: If you have purchased a diversity or GPS antenna, screw it on to
The ACM5504-5-G-I works with GSM carriers globally. Your carrier will provide a
SIM card for activating you data plan. Unscrew the SIM card access panel and
insert the SIM card in the bottom SIM slot with contacts facing
downward and the notch to RHS. Then replace the SIM card access panel.
Refer User manual for multiple SIM installation
Connect the Ethernet
devices to the
Plug your serial console devices into
Connect your USB devices to the two
Plug in the green screw terminal block and attach external sensors and DIO
Note: Refer ACM5500-I Addendum for RS422/485 and DIO details
Apply power. The ACM5504-5-G-I can now be powered externally by either:
connecting the provided external power pack to the
connecting an external 9 to 24 VAC source to the
connecting +9V to 30 VDC to
Note: If you ordered the -SDC option you'll have an external DC-DC
power converter (input voltage +/- 36V DC to 72V DC. The
converter power cable/ connector plugs into the
The ACM5504-5-G-I is ready for activation when the PWR status LED on the front panel
of the unit is lit steady, and the H/B (heartbeat) LED is flashing.
ACM5504-5-G Quick Start (520039-Rev 1.2)
User Manual
on the CDROM.
ACM5504-5-G-I device.
tabs. External
cables & straight (319014) & crossover (319015) DB9F-
RJ45S. Quick Start and CDROM. 12V DC power pack.
Cell (M)
LAN
port to your network. Connect your management LAN
ETHERNET 1-4
ports
DC PWR
ACM5504-5-G-I
Quick Start Guide
External rack and DIN rail
green connector block and
connector
SERIAL 1-4
(all Cisco RJ45 pin-out).
USB
ports
12VDC
12VDC
GND
and
on the green terminal block
12VDC
socket
mount
3G antenna. UTP
Cell A
barrel socket or
barrel socket or
Page 1
Advertisement
Related Manuals for Opengear ACM5504-5-G-I
Summary of Contents for Opengear ACM5504-5-G-I
- Page 1 The ACM5504-5-G-I is ready for activation when the PWR status LED on the front panel of the unit is lit steady, and the H/B (heartbeat) LED is flashing. ACM5504-5-G Quick Start (520039-Rev 1.2)
- Page 2 IP address in the same network range (192.168.0.xxx) as the ACM5504-5-G-I. If this is not convenient, you can use the ARP Ping command to set the IP address. Refer to the User Manual or online FAQ for details.
- Page 3 High and ON=Strong Step 5 OoB access To directly access the ACM5504-5-G-I, it needs a Public IP address and must not have SSH access firewalled. Almost all carriers offer corporate mobile data service/plans with a Public (static or dynamic) IP address. These plans often have a service fee attached.
- Page 4 Step 6 Enable cellular router features The ACM5504-5-G-I can provide cellular routing (although this is disabled by default). In this mode the connection to the carrier cellular network is always on, but IP traffic is selectively routed between the cellular connected network and the local Ethernet network (LAN): Select the Forwarding &Masquerading tab on System: Firewall...
