Bucktool BG1600S Instruction Manual

6” bench grinder & 1” x 30” sander combo
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
6" BENCH GRINDER &
1" X 30" SANDER COMBO
IMPORTANT:
For your own safety, read and follow all of the Safety
Guidelines and Operating Instructions before operating
this product.
Contact Us:
email: service@bucktool.com
https://www.bucktool.com
909-255-1088 (8AM-5PM PST)
GET IT DONE !
INSTRUCTION
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG1600S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bucktool BG1600S

Summary of Contents for Bucktool BG1600S

  • Page 1 GET IT DONE ! 6” BENCH GRINDER & 1” X 30” SANDER COMBO Contact Us: email: service@bucktool.com https://www.bucktool.com 909-255-1088 (8AM-5PM PST) IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety Guidelines and Operating Instructions before operating MANUAL this product.

  • Page 2: Table Of Contents

    BG1600S TABLE OF CONTENTS Specifications Safety guidelines Package contents Operating instructions Maintenance Troubleshooting Exploded view Parts list Warranty SPECIFICATIONS Motor 120VAC, 60Hz , 2.1A Speed (no load) 1790RPM Belt size 1" x 30" , 120 Grit Belt speed 1700 FPM...

  • Page 3: Safety Guidelines

    BG1600S GENERAL SAFETY GUIDELINES • Operate in a safe work environment. Keep your work area clean, well lit and free of distractions. • Keep anyone not wearing the appropriate safety equipment away from the work area. • Store tools properly in a safe and dry location. Keep tools out of the reach of children.
  • Page 4 BG1600S ADDITIONAL SPECIFIC SAFETY RULES 1. Only use a grinding wheel with the correct arbor size and shape that matches the grinder’s spindle. 2. Ensure the grinding wheel has a clean edge. Check the grinding wheel for wear or chipping and replace if necessary.
  • Page 5 BG1600S 20. Do not touch an operating motor. Motors can operate at high temperatures. 21. Only use accessories that are specifically designed for use with the tool. Ensure the accessory is tightly installed. 22. Only use an accessory that exceeds the No Load Speed rating.
  • Page 6 BG1600S IMPORTANT INFORMATION-Electrical A separate electrical circuit should be used for your machines. This circuit should not be less than #12 wire and should be protected with a 20-A time-lag fuse. If an extension cord is used, use only 3-wire extension cords which have 3-pronged grounding type plugs and matching receptacle which will accept the machine’s plug.
  • Page 7 BG1600S The plug must be plugged into a matching outlet that is properly installed and grounded in accordance with all local codes and ordinances. Do not modify the plug provided–if it will not fit the outlet, have the proper outlet installed by a qualified electrician.

  • Page 8: Package Contents

    BG1600S Package contents No. Description Qty. Belt work table Inner hex bolt Flat washer Support rod Belt tension handle Right Tool Rest Tool Rest Knob Flat Washer Eye Shield Eye Shield Locking Konb Philips screw Spark Deflector Philips Screw Inner hex wrench...

  • Page 9: Operating Instructions

    BG1600S WARNING! Do not plug in or turn on the tool until it is fully assembled according to the instructions. Failure to follow the safety instructions may result in serious personal injury. INSTALL SANDING BELT TABLE 1. Install the supprot rod (1) to the belt frame (2).
  • Page 10 BG1600S INSTALLING WORK REST 1. Attach the left tool rest (1) to the grinder as the upper slot (2) to the nut (3) and lower slot (4) to the protrude cylinder (5). 2. Place the lock knob (6) through the washer (7) and lower slot (4) into the hole (8) to lock the tool rest (1) in place.
  • Page 11 BG1600S ON/OFF SWITCH The ON/OFF power switch is located on the front of the sander, and incorporates a removable safety key. In situations where the sander may be left unattended, the operator has the option of removing the safety key of the ON/OFF switch to render the sander inoperable.

  • Page 12: Maintenance

    BG1600S CHANGING GRINDING WHEELS CAUTION Turn off and unplug the bench grinder. Use only grinding wheels that measure 6 in. (150 mm) in diameter. This tool has 1/2 in. (12.7 mm) arbors on both sides. 1. Raise the eye shield (1) out of the way and adjust the spark guard (2) in its highest setting.
  • Page 13 BG1600S 6. Remove the hex nut (9), the outside wheel flange (10) and the wheel (11). 7. Inspect the wheel (11) for cracks, chips or any other visible damage (other than normal wear) and discard if such damage is found. Inspect the blotter/cardboard disc for damage.
  • Page 14 BG1600S REPLACING SANDING BELT 1. Turn the knob (1) clockwise to open the belt cover (2). 2. Release belt tension by pulling down on tension handle (3). Slide old belt off the drive and tracking wheels. NOTE: The sanding belt can be removed directly without removing the belt work table.

  • Page 15: Troubleshooting

    BG1600S WARNING! To avoid injury from an accidental start, turn the switch OFF and always remove the plug from the power source before making any adjustments. PROBLEM PROBLEM CAUSE SUGGESTED CORRECTIVE ACTION Motor will not 1. Short circuit in line, cord or 1.
  • Page 16 BG1600S WARNING! To avoid injury from an accidental start, turn the switch OFF and always remove the plug from the power source before making any adjustments. PROBLEM PROBLEM CAUSE SUGGESTED CORRECTIVE ACTION Wavy condition 1. Machine vibrating. 1. Make sure machines is securely on surface of mounted on a solid surface.

  • Page 17: Exploded View

    BG1600S...

  • Page 18: Parts List

    BG1600S Item Description Qty. Stator Bearing Wave spring washer D35 End cap Hex flange nut M4 Cord bushing Base Philips screw+spring washer assy M6x18 Philips screw+spring washer+flat washer assy M4x7 Tooth lock washer D4 Capacitor support Capacitor Hex nut M8...
  • Page 19 BG1600S Item Description Qty. Miter gauge knob Support base Hex bolt M10x90 Hex nut M10 Belt adjustbale plate Philips screw+spring washer+flat washer assy M5x10 Eccentric shaft assy Circlip for shaft D16 Tension spring Tension handle base Inner hex bolt M8x12...

  • Page 20: Warranty

    GET IT DONE ! TWO-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : service@bucktool.com https://www.bucktool.com 909-255-1088 (8AM-5PM PST) https://www.bucktool.com...
