Outdoor Unit Disassembly
ACiQ-18-AC
ACiQ-24-AC
ACiQ-30-AC
ACiQ-36-AC
ACiQ-48-AC
1.
Dimension ..............................................................................................................2
2.
Outdoor Unit Disassembly ....................................................................................3
2.1
Panel Plate .....................................................................................................3
2.2
Electrical Parts ...............................................................................................6
2.3
Fan Assembly ................................................................................................8
2.4
Fan Motor .....................................................................................................9
2.5
Sound blanket .............................................................................................10
2.6
Four-way valve .............................................................................................11
2.7
Compressor .................................................................................................12
Contents
Version Date: 05-13-24
Advertisement
Table of Contents
Related Manuals for ACIQ ACiQ-18-AC
Summary of Contents for ACIQ ACiQ-18-AC
-
Page 1: Table Of Contents
Version Date: 05-13-24 Outdoor Unit Disassembly ACiQ-18-AC ACiQ-24-AC ACiQ-30-AC ACiQ-36-AC ACiQ-48-AC Contents Dimension ......................2 Outdoor Unit Disassembly ..................3 Panel Plate .....................3 Electrical Parts ....................6 Fan Assembly ....................8 Fan Motor .....................9 Sound blanket .....................10 Four-way valve .....................11 Compressor ....................12... -
Page 2: Dimension
1. Dimension Outdoor Unit Disassembly 2 ... -
Page 3: Outdoor Unit Disassembly
2. Outdoor Unit Disassembly Panel Plate Procedure Illustration 1) Turn off the air conditioner and the power breaker. 2) Remove the screw of the big handle and then remove the big handle (3 screws) (see CJ_X430_001). Big Handle For US models (3 screws） CJ_X430_001 Top Cover 3) Remove the screws of the top cover... - Page 4 Procedure Illustration 4) Remove the screws of water collecting cover and then remove the water collecting cover (2 screws) (see CJ_ X430_003). Water Collecting Cover CJ_X430_003 5) Remove the screws of the front panel and then remove the front panel (7 screws(onoff models) or 9 screws(inverter models) (see CJ_ X430_004).
- Page 5 Procedure Illustration 6) Remove the screws of the right panel and then remove the right panel (6 screws) (see CJ_X430_005). Right Panel CJ_X430_005 Note: This section is for reference only. Actual unit appearance may vary. Outdoor Unit Disassembly 5 ...
-
Page 6: Electrical Parts
Electrical parts Antistatic gloves must be worn when you disassemble the electronic box. WARNING: Note: Remove the air outlet grille(refer to 2.1 Panel Plate) before disassembling electrical parts. Procedure Illustration 1) Remove the 5 screws and unfix two CJ_ODU_PCB_003-1 ). hooks.(see Note:Electric control box cover cannot be removed, so the voltage between P... - Page 7 Procedure Illustration 9) Remove the 1 screw and disconnect the wires and then remove the 24V board.(see CJ_ODU_PCB_003-3 )(for some models) CJ_ODU_PCB_003-3(for some models) Note: This section is for reference only. Actual unit appearance may vary. Outdoor Unit Disassembly 7 ...
-
Page 8: Fan Assembly
Fan Assembly Note: Remove the panel plate (refer to 2.1 Panel Plate) before disassembling fan. Procedure Illustration 1) Remove the nut securing the fan with a spanner (see CJ_ODU_ FAN_001). 2) Remove the fan. CJ_ODU_FAN_001 Note: This section is for reference only. Actual unit appearance may vary. ... -
Page 9: Fan Motor
Fan Motor Note: Remove the panel plate and the connection of fan motor on PCB (refer to 2.1 Panel Plate and 2.2 Electrical parts) before disassembling fan motor. Procedure Illustration 3) Remove the fixing screws of the fan motor (4 screws) (see CJ_ODU_MOTOR_001). 4) Remove the fan motor. -
Page 10: Sound Blanket
Sound blanket Note: Remove the panel plate (refer to 2.1 Panel plate) before disassembling sound blanket. Procedure Illustration 1) Remove the sound blanket (side and top) (see CJ_ODU_BLANKET_001). Sound Blanket(top) (Applicable to models with blanket) Sound Blanket(side) (Applicable to models with blanket) CJ_ODU_BLANKET_001 Note: This section is for reference only. -
Page 11: Four-Way Valve
Four-way valve (for heat pump models) WARNING: Evacuate the system and confirm that there is no refrigerant left in the system before removing the four-way valve and the compressor. (For R32 & R290, you should evacuate the system with the vacuum pump; flush the system with nitrogen;... -
Page 12: Compressor
Compressor WARNING: Evacuate the system and confirm that there is no refrigerant left in the system before removing the four-way valve and the compressor. (For R32 & R290, you should evacuate the system with the vacuum pump; flush the system with nitrogen; then repeat the two steps before heating up the brazed parts. The operations above should be implemented by professionals.) Note: Remove the panel plate, connection of compressor on PCB (refer to 2.1 Panel plate and 2.2 Electrical parts) before disassembling sound blanket. - Page 13 Procedure Illustration 3) Remove the hex nuts and washers securing the compressor, located on the bottom plate (see CJ_ODU_COMP_003). CJ_ODU_COMP_003 Suction Pipe 4) Heat up the brazed parts and then remove the the discharge pipe and the suction pipe (see CJ_ODU_COMP_004). Discharge Pipe 5) Lift the compressor from the base pan assembly with pliers.
