ACIQ -18W-P Disassembly Manual

Pancake air handler
Hide thumbs Also See for ACiQ-18W-P:

Advertisement

Table of Contents

Pancake Air Handler - Disassembly Guide
Models Covered:
ACiQ-18W-P
ACiQ-24W-P
ACiQ-30W-P
ACiQ-36W-P
1.
Indoor Unit Disassembly .......................................................................................1
1.1
Electrical Parts ...............................................................................................2
1.2
Fan Motor and Fan ........................................................................................5
1.3
Evaporator .....................................................................................................7
Contents
VERSION DATE: 05-01-24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACiQ-18W-P and is the answer not in the manual?

Questions and answers

Related Manuals for ACIQ ACiQ-18W-P

Summary of Contents for ACIQ ACiQ-18W-P

  • Page 1 Pancake Air Handler - Disassembly Guide Models Covered: ACiQ-18W-P ACiQ-24W-P ACiQ-30W-P ACiQ-36W-P Contents Indoor Unit Disassembly ..................1 Electrical Parts ....................2 Fan Motor and Fan ..................5 Evaporator .....................7 VERSION DATE: 05-01-24...

  • Page 2: Indoor Unit Disassembly

    1. Indoor Unit Disassembly Electrical Parts (Antistatic gloves must be worn.) Procedure Illustration 1) Remove 8 screws(18k/24k models) or 10 screws(30k/36k models) of air inlet channel panel assembly and then remove it. (see CJ_Pan_001) 18k/24k 30k/36k 2) Remove 5 screws of cover of electric CJ_Pan_001 control box subassembly and then remove it.(see CJ_Pan_002)
  • Page 3 Procedure Illustration 3) Release 1 fixing screw and 1 earthing screw.(see CJ_Pan_003) 4) Unplug the plugs and then remove the main control board subassembly. (see CJ_Pan_003) 5) Release 2 screws and then remove the transformer. (see CJ_Pan_003) 6) Release 1 fixing screw of the data transfer module control board to remove it.

  • Page 4: Fan Motor And Fan

    Fan Motor and Fan Procedure Illustration 1) Remove 7 screws(18k/24k models)/8 screws(30k/36k models) of air inlet channel back panel assembly.(see CJ_ Pan_004) 18k/24k 30k/36k CJ_Pan_004 2) Remove 8 screws of fan and fan motor assembly. (see CJ_Pan_005) CJ_Pan_005 Note: This section is for reference only. Actual unit appearance may vary. ...
  • Page 5 Procedure Illustration 3) Remove 8 screws of left and right fan assembly. (see CJ_Pan_006) CJ_Pan_006 4) Rotate the volute and loosen the fixing screw. (see CJ_Pan_007) 5) Remove the fan assembly outward.(see CJ_Pan_007) 6) Repeat the above steps to remove the other one.
  • Page 6 Procedure Illustration 7) Remove 2 screws of motor driver.(see CJ_Pan_008) CJ_Pan_008 8) Remove 2 screws of fan motor fixing board(Up) and 1 screw used for the ground connection. (see CJ_Pan_009) 9) Then take out the fan. (see CJ_Pan_009) CJ_Pan_009 Note: This section is for reference only. Actual unit appearance may vary. ...

  • Page 7: Evaporator

    Evaporator Procedure Illustration 1) Remove 10 screws of left& right side plate subassembly. (see CJ_Pan_010) Note: The left and right side plate subassembly are symmetrical. CJ_Pan_010 2) Remove 3 screws of air inlet channel front panel assembly. (see CJ_Pan_011) CJ_Pan_011 Note: This section is for reference only.
  • Page 8 Procedure Illustration 3) Remove 6 screws(18k/24k/30k models)/8 screws(36k models) of electric control box. (see CJ_Pan_012) 4) Remove 3 screws of pipe clamp (see CJ_Pan_012 CJ_Pan_013) CJ_Pan_013 Note: This section is for reference only. Actual unit appearance may vary.  Indoor Unit Disassembly 8 ...
  • Page 9 Procedure Illustration 5) Remove 3 screws of water collector assembly. (see CJ_Pan_014) CJ_Pan_014 6) Remove 2 screws of flange subassembly. (see CJ_Pan_015) CJ_Pan_015 7) Remove 4 screws of waterproof board subassembly. (see CJ_Pan_016) CJ_Pan_016 Note: This section is for reference only. Actual unit appearance may vary. ...
  • Page 10 Procedure Illustration 8) Remove 5 screws of right supporter board. (see CJ_Pan_017) CJ_Pan_017 9) Remove 5 screws of left supporter board. (see CJ_Pan_018) 10) Take out the evaporator. CJ_Pan_018 Note: This section is for reference only. Actual unit appearance may vary. ...

This manual is also suitable for:

Aciq-24w-pAciq-30w-pAciq-36w-p
