Redx RX Series User Manual

Hybrid inverter
Hide thumbs Also See for RX Series:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
RX SERIES HYBRID INVERTER
Plus Series
RX-5006Plus / 7006Plus
RX-5010Plus / 7010Plus
RX-5013Plus / 7013Plus

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RX Series and is the answer not in the manual?

Questions and answers

Related Manuals for Redx RX Series

Summary of Contents for Redx RX Series

  • Page 1 User Manual RX SERIES HYBRID INVERTER Plus Series RX-5006Plus / 7006Plus RX-5010Plus / 7010Plus RX-5013Plus / 7013Plus...
  • Page 3 Software Licenses It is prohibited to use data confirmed in firmware or software developed by Redx, in part or in full, for commercial purposes by any means. It is prohibited to perform reverse engineering, cracking, or any other operations that compromise the original program design of the software developed by Redx.
  • Page 4 Redx Hybrid inverter (RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus). Please read this manual carefully before using this product and store the manual in a safe place. Redx will not notify the user of any changes to this manual. This manual applies to the RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus Hybrid inverter.

  • Page 5: Table Of Contents

    7 RX-Plus Series System Turn On and Turn Off……….……………………..…....31 7.1 Turn on Plus Series……….……………………………...…..........31 7.2 Turn off Plus Series ……….………………………………..........31 8 Troubleshooting & Maintenance……….………………………………........31 8.1 Troubleshooting……….………………………………...…………........31 8.2 Maintenance……….………………………………...……………........34 8.3 Routine Maintenance……….………………………………...………......35 9 Redx Power App……….………………………………...……………........36 10 Quality Assurance……….………………………………...……………........36 11 Appendix……….………………………………...……………..........37 11.1 Optional Accessories……….………………………………...………......37 12 Contact……….………………………………...…………….............38...

  • Page 6: Safety

    (a) Do not open the case as risk of electric shock (b) Maintenance should be carried out by a professional licensed technician (c) Read this manual before operating the system. Redx is not responsible for failure or loss arising out of improper operation.
  • Page 7 Table 1-1 - Warnings Danger! Removal of any protection, incorrect use, incorrect installation, or incorrect operation may result in death/serious personal injury or device damage. Transportation, loading and unloading, installation, start-up and maintenance must be carried out by qualified or trained engineer/technician. Danger! Before maintenance or touching any parts, or installation, make sure that the energy storage unit is disconnected and wait 5 minutes to ensure that the...
  • Page 8 Warning! The product is not tested to section 5 of AS/NZS 4777.2:2020 and is not to be used in multiple inverter combinations without additional considerations by the system designer Warning! The load capacity of the output of the inverter load is as follows: Inductive load (such as air conditioning, washing machine, motor, etc.).

  • Page 9: Product Introduction

    2 Product Introduction 2.1 System Diagram The RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus is a Hybrid inverter combined with PV and energy storage systems. it utilizes solar power and battery power to ensure continuous power supply even during a grid outage, the unused power can also be fed into the power grid. it also provides additional expansion ports and expansion ports for compatible connections.
  • Page 10 Figure 2.1.2 The Plus Series application Blue indicates a power cable， indicates a signal cable The explanation is as follows: Table 2.1.2 - Diagram elements explained Number Name Circuit Breaker PV Panel Regular Loads Smartmeter / CT Grid Plus Series Hybrid Inverter Four Battery Modules Backup Loads Rev 20240516...
  • Page 11 The explanation is as follows: Table 2.1.3 - Diagram elements explained Number Name Plus Series Hybrid Inverter Redx Power App 4G Module Internet Wi-Fi Router Cloud Server Wi-Fi Module Rev 20240516 Plus Series...

  • Page 12: Production Details

    2.2 Production Details 2.2.1 Appearance and Dimensions Items Name GRID BACKUP DRMO / METER PARALLEL ON-OFF PV SW GRID BREAKER BACKUP BREAKER WIFI / 4G BAT BREAKER Table 2.2.1 - Diagram elements explained Rev 20240516 Plus Series Page 7 of 39...
  • Page 13 2.2.2 Dimension 210mm 750mm 210mm 480mm RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus 210mm 210mm 750mm 1540mm Figure 2.2.2 Plus Series Dimensions Rev 20240516 Plus Series Page 8 of 39...

  • Page 14: Led Indicator Panel And Switches

    2.3 LED Indicator Panel and Switches Main power switch ON - OFF Figure 2.3.1 RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus On-Off switch Table 2.3.1 - Status LED elements explained SOC Led lndicate Charging ● ● ● ● ● flash 0-20% 21-40% flash 41-60% flash 61-80% flash 81-100% flash...
  • Page 15 Display Logic Bi-colour LED2 LED3 LED1 Grid/Gen Battery System Status System Information LED4(Green/RED) Wifi/Ethernet/Fault ▲ ▲ ▲ ▲ Power on ■ ■ ■ ■ Power off Normal information Promote update Promote update success ★ ★ ★ ★ ■ ■ Battery not connected ●...

  • Page 16: Technical Fata

    2.4 Technical Data Figure 2.3.2 - RX-7000Plus Technical information Items Specifications RX-7006Plus RX-7010Plus RX-7013Plus Model: Max. input power 3000W Rated Input Power 2500W Quantity of MPPTs / MPPT Max. input voltage 550V MPPT voltage range / MPPT 120 ~ 500V MPPT voltage range (full load) 200V - 400V MPPT rated working voltage / MPPT...
  • Page 17 30.5A Rated current Frequency 50Hz ± 0.1Hz Back - up switch time ≤ 20ms Efficiency Max. Efficiency between 96.8% 96.6% BAT and grid General Data Dimension(H*W*D) 1040*750*210mm 1290*750*210mm 1540*750*210mm (with decoration panel) 107kg Weight 140.5kg 174kg Noise emission ≤ 35dB Operating ambient temperature -20℃~ 55℃...
  • Page 18 Figure 2.3.3 - RX-5000Plus Technical information Items Specifications RX-5006Plus RX-5010Plus RX-5013Plus Model: Max. input power 3000W Rated Input Power 2500W Quantity of MPPTs / MPPT Max. input voltage 550V MPPT voltage range / MPPT 120 ~ 500V MPPT voltage range (full load) 200V - 400V MPPT rated working voltage / MPPT 300V...
  • Page 19 Rated current Frequency 50Hz ± 0.1Hz Back - up switch time ≤ 20ms Efficiency Max. Efficiency between 96.8% 96.6% BAT and grid General Data Dimension(H*W*D) 1040*750*210mm 1290*750*210mm 1540*750*210mm (with decoration panel) 107kg Weight 174kg 140.5kg Noise emission ≤ 35dB Operating ambient temperature -20℃~ 55℃...

  • Page 20: Product Features

    2.5 Product Features a. Backup power supply b. Noiseless with no fan inside c. Compatible with various application scenarios d. Intelligent management e. Remote scheduling f. Multiple protection g． Stacked battery, no installation required h． Long product life without bus electrolytic capacitor 3 Installation Storage Store the storage unit properly when the unit is not installed immediately...
  • Page 21 RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus Standard Accessories Hybrid Inverter Base Components Side cover(right) Side cover(left) 1PCS 1PCS 1PCS 1PCS PCS bracket A PCS bracket B Base bracket Battery Connecting buckle 1PCS 1PCS 2PCS 2PCS PV output connector PV input connector RJ45 waterproof plug 3PCS 3PCS 4PCS Smartmeter+CT...

  • Page 22: Installation

    3.1 Installation Preparation a. Not to be installed in direct sunlight. Vertical mounting only. b. Install in a ventilated location. There must be enough clearance to ensure that the module operates in the optimal heat dissipation state. c. Install at suitable distance from any restricted areas, please review Standard ASNZS5140. d.

  • Page 23: Installation Tools

    3.2 Installation Tools Prepare the following tools before installation: Figure 3.2.1 - RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus Installation tools Type Tool Packaging tape Marker Measuring tape Level General tools Multimeter Measurement range: Protective ≥ Utility knife Wrist strap 1100Vdc clothing Protective gloves Dust mask Earplugs Goggles Insulated shoes...

  • Page 24: Installation Guide

    4 Installation Guide 4.1 Physics Installation Avoid water and electricity when drilling, bit size φ8mm, drilling depth 40mm. Expansion 2.8 N.M Bolts 5 N.M Expansion Bolts 5 N.M Refer to the electrical connection section for wiring Rev 20240516 Plus Series Page 19 of 39...

  • Page 25: Electrical Connection

    5 Electrical Connection An independent circuit breaker must be configured for each power interface. The table below is a recommendation for cable selection and the Recommended specifications of circuit breaker. Engineers should refer to local standards to select cables. Cable length is generally 2 to 10 meters, long cable will lead to voltage deviation from the rated value, consequently requiring an increase of the cross-sectional area.

  • Page 26: Pv Connection

    Devices that are connected to the Internet with Wi-Fi/4G, the alarm information will be shown on the monitoring website www.redxpower.com, and also will be displayed in the Redx Power app. PV Connection...

  • Page 27: Wifi/4G Dongle

    PV Arrays can be installed according to the needs of customers. Click PV Arrays Figure 5.2.2 - RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus PV connection 5.3 WiFi / 4G Dongle 0.8-1.1N m Tighten connector on the thread once Dongle is in. Rev 20240516 Plus Series Page 22 of 39...

  • Page 28: Communication Connection

    Communication Connection 5.4.1 Dry Contact Connection The dry contact is connected based on customer requirements Dry Contact Connect with weak current Group Definition DRY_1_NC 1 2 3 4 5 6 7 8 DRY_1_COM RJ45 DRY_1_NO Rev 20240516 Plus Series Page 23 of 39...
  • Page 29 5.4.2 CT/METER/DRM0 Terminal Connection The CT/METER is used to monitor the status of the energy consumption. When RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus is installed in some states in Australia, the DRMO terminal needs to be connected (Australia Only). The connection method is as follows: CT / Smart meter / DRM0 Smart meter 485,DRM0 signal, external CT Group...

  • Page 30: Grid Connection

    5.4.3 Parallel Terminal Connection Network cable (8pin) ① The parallel function determines whether to install according to customer requirements ② The parallel ports are RJ45 terminals and areconnected using conventional 8pin network cables 5.5 Grid Connection Requirements 1.Install an AC circuit breaker between the inverter and the grid, before connecting the system to the grid.

  • Page 31: Eps Load/Generator Connection

    Grid Connector Click Note： for details about the electrical connection, see Figure 2.1.2-2.1.3。 1.The GRID terminal and off-grid（EPS LOAD） terminal cannot be connected together, otherwise the system will be damaged. 2.The battery needs to be activated by the grid when the system starts for the first time. 5.6 EPS Load / Generator Connection Rev 20240516 Plus Series...

  • Page 32: Operation

    Tighten the screw once connector is in. Figure 5.6.1 - RX-5006Plus/7006Plus/5010Plus/7010Plus/5013Plus/7013Plus EPS connector assembly Do not connect the port to other power supplies. Otherwise, the inverter may be damaged, causing risks. 6 Operation 6.1 Checklist Before Operation 1. Check whether the system is firmly installed, and the installation position is easy for operation and maintenance.
  • Page 33 The installer can also edit the Generation and Export Limit Control Settings on the Deploy page. Figure 6-1 - Export Soft and Hard Limit settings on Deploy page Figure 6-2- Region selector in the Redx Power App Turning SWBackFlow and HDBackflow settings to "On" sets the soft export limit to the value of SWBackVal, and the hard export limit to the value of HDBackVal respectively.

  • Page 34: Operation Checks

    If there is voltage on the grid terminals, but unit is still not illuminating the LEDs– please contact local Redx dealer. (b) Install the Redx Power APP or open web page according to the attached instructions, and then configure the WIFI connection.
  • Page 35 B．Off - Grid / EPS Functionality When the power grid is cut off, the system will automatically switch to off-grid mode. The system will supply power to the load from the battery via the EPS terminals. Note: in off-grid mode, the maximum system output power using only the battery is 5000W, meaning the load power of the EPS circuit should not exceed 5000W.

  • Page 36: Rx-Plus Series System Turn On And Turn Off

    6.3.7 Shutdown Status Disconnect all power supply, turn everything off and the system will automatically enter the Off state. The specific steps are as follows: 1.Turn off the power button 2.Turn off the battery switch 3.Disconnect the grid supply, the LED light and the battery power display LED light will be turned off.
  • Page 37 Suggestion Fault information Fault reason The battery connection No battery is detected Check whether the battery circuit breaker is on If the error message remains, contact installation error partner. 1. Check whether the battery is correctly connected and whether the battery voltage is normal.
  • Page 38 1. Check whether the AC circuit breaker of the grid is disconnected and whether the connecting cables are securely connected. Islanding protection Islanding protection check 2. Check whether the grid has power. 3. If all conditions are correct and the fault still occurs, contact installation partner.

  • Page 39: Maintenance

    1. Remove some loads. Ensure that the load is smaller than the maximum output power of the Output overload Overloaded outputs inverter. 2. Restart the inverter. 1. The inverter installation 1. Check whether the operating environment location is not ventilated. Radiator over exceeds the operating temperature range of the 2.

  • Page 40: Routine Maintenance

    The repair of the battery should be carried out or supervised by personnel with battery knowledge and necessary precautions. Do not mix batteries of different types and capacities, please use all batteries of the same model. If the inverter is not used for more than 7 days, turn off the AC input, PV input, and battery input switches.

  • Page 41: Redx Power App

    Evidence During the warranty period, the customer shall provide the product purchase invoice and date. Since the date of purchase by the user from Redx (hereinafter referred to as the manufacturer), the user will enjoy the following after-sales warranty service 1.A 10-year warranty commences from the date of shipment from, during the warranty period...

  • Page 42: Appendix

    (c) The user intentionally conceals the improper use of the product during installation, wiring, operation, maintenance or other processes to the after-sales service provider of the manufacturer. *Redx reserve the right to change the contents of this specification and product performance without informing users. 11 Appendix 11.1 Optional Accessories...

  • Page 43: Contact

    12 Contact If you have any questions about our products, please contact our service hotline or dealers. please provide the following information when inquiring: 1.System serial number 2.System model 3.Fault code/Name 4.Briefly describe the fault symptom Rev 20240516 Plus Series Page 38 of 39...
