  • Page 1 WelcomeHive Pro 2 Doorphone Monitor User Manual Register your product on www.philips.com/register...
  • Page 2: Table Of Contents

    Contents 1. Safety instructions ................2 2. Kit contents .................... 2 3. General information ................3 4. Detailed description ................3 5. Wiring...................... 4 5.1. General wiring diagram .............. 4 5.2. Monitor wiring configuration ............ 5 6. Installation....................7 7. Settings ....................8 7.1.
  • Page 3 8. Use......................13 8.1. Calls ....................13 8.2. Missed calls ..................14 9. Technical features ................. 15 10. FAQ - Common problems and solutions ........15 11. Technical support - Warranty ............18 12. Safety measures ................... 19 13. FCC/CE warning ................... 19 14.
  • Page 4: Safety Instructions

    • If you are installing this product for someone else, remember to leave the manual or a copy of it with the end user. • This product is designed to work exclusively with one of the entry panels in the Philips WelcomeHive Pro 2 range.
  • Page 5: General Information

    3. General information This entry panel is designed for use with monitors in the WelcomeHive Pro 2 range. Ideal for professional installations, it features a flush-mounted design, a machined aluminium front panel and a single DIN rail power supply unit and offers top-of-the-range features such as high image resolution, visitor memory, the option of adding a second screen per home, and a digital BUS system that reduces the length of wires required for installation.
  • Page 6: Wiring

    Each monitor has a corresponding call button. Up to 2 monitors can be assigned to each call button, up to a maximum of 16 monitors per system. Please note: the video doorphone uses digital BUS technology, so the monitors must be connected one after the other for optimum results: 230 Vac 50 Hz 230 Vac 50 Hz Philips - WelcomeHive Pro 2...
  • Page 7: Monitor Wiring Configuration

    • DIP switches no. 1 to 5: Used to select the call button corresponding to the monitor: Monitor Monitor Positions to be set Positions to be set number number WelcomeHive WelcomeHive Corresponding Corresponding Pro 2 entry Pro 2 entry monitor numbers monitor numbers panel model panel model 1 name 2 names (DES 9801 VDP) (DES 9802 VDP) Philips - WelcomeHive Pro 2...
  • Page 8 • DIP switch No. 7: Set to down (OFF position): • DIP switch no. 8: Closes the circuit: If one pair of cables arrives at the monitor and another leaves for another monitor, set DIP switch 8 to down (‘OFF’ position): Philips - WelcomeHive Pro 2...
  • Page 9: Installation

    Wire the monitor to the ‘BUS1(IM)’ and ‘BUS2(IM)’ outputs of the entry panel power supply or to another monitor, respecting the general wiring diagram above. Refer to the WelcomeHive Pro 2 entry panel instructions for more information on wiring and the type of cables to use.
  • Page 10: Settings

    Important: the video-recording function requires a microSD card to be inserted in the monitor. A 32 GB card is pre-inserted in the slot on the edge of the monitor. The photo-taking function does not require a memory card. Philips - WelcomeHive Pro 2...
  • Page 11 - If you have selected to take photos, go to the settings menu and then to the menu to choose the number of photos to be taken with each call (1 to 3 photos per press): Philips - WelcomeHive Pro 2...
  • Page 12: Intercom Mode

    To activate it, go to the second page of the settings menu and tap Select ‘ON’ to activate intercom mode. Once intercom mode has been activated, you can access the call menu from the monitor’s main page by tapping Philips - WelcomeHive Pro 2...
  • Page 13: Sound, Image, Time And Night Mode Time Period Settings

    (see below). The fi rst page lets you set the date and time: 2024 2017 The second page lets you choose the date and time format to be used: YYYY/MM/DD YYYY/MM/DD 24 H 24 H Philips - WelcomeHive Pro 2...
  • Page 14 - Tap the icon to adjust the image brightness Each value can be set from 1 to 10. To adjust the sound and chime volume, go to the settings menu and click on the icon: Philips - WelcomeHive Pro 2...
  • Page 15: Use

    - If another monitor is calling and not the entry panel (intercom function), the screen will look like this: Number of the monitor calling Answer and speak with the monitor calling Hang up without taking the call Philips - WelcomeHive Pro 2...
  • Page 16: Missed Calls

    1 - 1 - 2024 Delete the photo/ video currently on the screen Navigation button for Photo/video previous/next number and total entry Play/pause button 0001/0001 (in the case of a video) Back to the list Philips - WelcomeHive Pro 2...
  • Page 17: Technical Features

    9. Technical features Model Philips WelcomeHive Pro 2 DES 9806 VDP monitor Power supply Provided by the entry panel Assembly Surface-mounting to the wall Additional - Visitor memory: up to 100 photos (internal memory) functions - Slot for microSDXC card up to 128 GB to increase the number of photos or record 10s to 30s videos instead.
  • Page 18 • Check that the entry panel’s DIP monitor from the entry of the entry panel and/or switches are in the correct position panel monitor • Check that the DIP switches on each monitor are set correctly (master/slave setting, call button assignment) Philips - WelcomeHive Pro 2...
  • Page 19 • The exit button to be connected point opens during a button to the EXT and GND terminals of the power cut entry panel must be a normally open contact: the contact closes when the button is pressed Philips - WelcomeHive Pro 2...
  • Page 20: Technical Support - Warranty

    Phone number : Address : E-mail : Date of purchase : (DD/MM/YYYY) Dealer : Dealer Phone : Dealer address : Serial number PHI/1031/ Important : Please keep this warranty card with your proof of purchase. Philips - WelcomeHive Pro 2...
  • Page 21: Safety Measures

    • Redirect or move the receptor antenna. • Increase the distance between the equipment and the receptor. • Connect the equipment to a socket belonging to a different circuit from the one to which the receptor is connected. Philips - WelcomeHive Pro 2...
  • Page 22: Declaration Of Conformity

    WITH the RED directive AVIDSEN hereby declares that the equipment designated below: WelcomeHive Pro 2 DES 9806 VDP monitor Complies with the EMC 2014/30/EU and LVD 2014/35/EU directives and that its conformity has been assessed pursuant to the applicable standards in force: •...
  • Page 23 ES - Corriente continua PT - Corrente contínua FR - Courant alternatif GB - Alternating Current D - Wechselstrom NL - Gelijkstroom PL - Prąd zmienny IT - Corrente alternata ES - Corriente alterna PT - Corrente alterna Philips - WelcomeHive Pro 2...
  • Page 24 2024©Avidsen. All rights reserved. Philips and the Philips shield emblem are registered trademarks of Koninklijke Philips N.V. and are used under licence. This product was manufactured and is sold by AVIDSEN SAS, and AVIDSEN SAS is the sole guarantor of the product.
