DP3L1-805A/808A series Open loop stepping driver User manual Wuxi Xinje Electric Co., Ltd. Data No. D3C11 20230223EN 1.0...
Page 2
The manual involves the function, use method, installation and maintenance of the step driver. The contents described in the manual are only applicable to Xinje's DP3L1 series stepping driver products. Notice to user This manual is applicable to the following personnel: ...
Catalog 1.PRODUCT INTRODUCTION ..........................1 1-1. N ..............................1 AMING RULE 1-2. P ..............................1 ERFORMANCE 1-3. A ............................1 PPLICATION FIELD 1-4. E ............................2 LECTRIC FEATURES 1-5. S ............................2 AFETY PRECAUTIONS 2. INSTALLATION AND WIRING ........................... 3 2-1.
1-1. Naming rule DP3L1 - 80 8 - A ① ② ③ ④ ①: DP3L1 series open loop stepping driver ②: Driver output maximum peak current 8.0A ③: The maximum working voltage of the driver is 5: 50VAC or 80VDC 8: 80VAC or 110VDC ④: AC power supply...
1-4. Electric features Item DP3L1-805A DP3L1-808A Input power supply (VAC) 20-50 20~80 Input power supply (VDC) 20~80 30~110 Output peak current (A) 2.7~8.4 Matched motor (base) 57/86 Outline dimension (mm) 150*56*97.5 Step pulse frequency (Hz) 150K Control signal input voltage 24/5 (VDC)...
2-1-2 Installation environment The reliable working temperature of the driver is usually within 60℃ and that of the motor is within 80℃. To ensure that the driver works within the reliable working temperature range, the driver should be installed in the electric cabinet with good ventilation and proper protection.
PUL+ PUL- Start DIR+ Direction DIR- ENA+ Enable ENA- Controller Error output Power Driver supply Motor 2-2-2 Wiring notice (1) In order to prevent the driver from being disturbed, it is recommended to use twisted pair shielded wire for the control signal, and the shield layer is short-circuited with the ground wire.
3. Driver interface Signal indicator Green light: Power Red light: Alarm Control signal interface DIP switch Strong electricity interface 3-1. Control signal interface 3-1-1 Function Signal Function Explanation PUL+ In PUL mode, it is used as a pulse signal, and the rising edge is effective, supporting Pulse 5/24VDC.
3-1-2 Control signal circuit DP3L1 series allow receiving signals from open collector and PNP output circuits. There are two kinds of connection methods: common cathode and common anode. Now taking NPN output as an example, the schematic diagram of interface circuit is as follows: ...
3-2. Strong electricity interface 3-2-1 Function Interface Function Explanation 808A AC drive supports 20-80VAC power supply, or 30-110VDC power supply AC power supply 805A AC drive supports 20-50VAC power supply, or 20-80VDC power supply Select the voltage according to the demand. If DC power is supplied, this AC power supply terminal needs to be connected to GND of power A+,A-...
DP3L1-805A/808A 开环步进驱动器用户手册 4 电流、细分拨码开关设定 4. DIP switch DP3L1 AC series open-loop driver uses 8-bit dial switch to set subdivision or speed accuracy, dynamic current, static half-current, high and low acceleration and deceleration. Detailed description is as follows: PUL mode SW10 Dynamic current Half/full current Subdivision...
4-1. PUL mode (SW10 OFF) current subdivision setting 4-1-1 Working (Dynamic) current setting DP3L1 open loop stepping drive AC series dial code current: Output peak current Output mean current Default(4.0A) 2.7A 1.9A 3.6A 2.6A 4.6A 3.3A 5.5A 3.9A 6.4A 4.6A 7.3A 5.2A 8.4A...
4-1-4 Instruction filter time setting SW9 filter instruction dial switch: SW9=off: instruction filtering time OFF. SW9=on: instruction filtering time ON, filtering time 25ms. The instruction filtering function is only effective in the PUL mode and is used to execute pulse instructions more smoothly.
5. Protection function The green LED is the power indicator. When the driver is powered on, the LED is always on; When the drive is powered off, the LED goes off. The red LED is the fault indicator. When there is a fault, the indicator will flash continuously, then stop for one second, and then flash continuously;...
6. Common troubleshooting Fault Reason Solution Check the power supply Power supply system error circuit The power light doesn't work Increase the power supply Low supply voltage voltage The current setting is too small Set suitable current Subdivision is too small in PUL Set suitable subdivision mode Acceleration and deceleration time...
Page 17
WUXI XINJE ELECTRIC CO., LTD. No.816, Jianzhu West Road, Binhu District, Wuxi City, Jiangsu Province, China Tel: 400-885-0136 Fax: (510) 85111290 Email: fiona.xinje@vip.163.com www.xinje.com...
