Summary of Contents for Global Industrial 270315
- Page 2 *This unit doesn't include drainpipe kit...
- Page 3 User's Manual A. Water Inlet B. Water drainage C. Power cable position Check local codes for plumbing requirements prior to installation.
- Page 4 Assembly Instructions Surface Mount Water Bottle Refilling Station Surface Mount Water Bottle Refilling Station Model 270315 Ref. Qty. Description Tor>< Key Filter Access Door Key ---- ---- ---- -------- -------- -------- lr· c:ro Save after removal Remove top mounting bracket...
- Page 5 Assembly Instructions Remove the lower cover Unscrew the four screws on the bottom • of the lower cover with a screwdriver. Remove the cover carefully and place it • aside. Unscrew the four screws See wall mounting template Attach mounting bracket to the wall Affix stencil with tape to appropriate wall.
- Page 6 Fix the bottle refilling station onto the wall • Fix the bottle refilling station on the wall with screws through the three holes. • Put the lower cover back on the bottle refilling station. • Fix and tighten the four screws on the bottom of the lower cover.
- Page 7 Installing/Replacing Filter 1. Turn off the water supply to minimize water spillage before installing or replacing the filter. 2. Remove the filter access door on the lower cover using the provided key (H6) or the integrated key on the bottom of the filter cartridge. 3.
- Page 9 Power cord or wire loose...
