Norwood Yieldtrac 36R20 Operator's Manual

Planter bar
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Yieldtrac Planter Bar 36R20
(36 Row 20" Spacing)
Front Fold Trailing Planter
Yieldtrac Planter Bar 36R22
(36 Row 22" Spacing)
Front Fold Trailing Planter
Year 2016 Model
OPERATOR'S MANUAL
Part Number T0054345
1st Edition English
April 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yieldtrac 36R20 and is the answer not in the manual?

Questions and answers

Related Manuals for Norwood Yieldtrac 36R20

Summary of Contents for Norwood Yieldtrac 36R20

  • Page 1 Yieldtrac Planter Bar 36R20 (36 Row 20” Spacing) Front Fold Trailing Planter Yieldtrac Planter Bar 36R22 (36 Row 22” Spacing) Front Fold Trailing Planter Year 2016 Model OPERATOR’S MANUAL Part Number T0054345 1st Edition English April 2016...
  • Page 3 Case IH ® Early Riser and AFS ® are registered Read and Understand WARNING manual and all other manuals for products associated with this planter as well as in all on-product warning decals. Failure to Norwood Preface Revision History Issue Date Reasons for Change...

  • Page 4: Table Of Contents

    Contents ..................................................1-1 ........................1-2 ........................1-3 ....................1-4 ....................1-4 Machine Components (Page 1 of 3) ........................1-5 Machine Components (Page 2 of 3) ........................1-6 Machine Components (Page 3 of 3) ....................................................................2-1 ..............................2-1 ...............................
  • Page 5 ....................4-19 ......................4-19 ............................... 4-20 ................................4-20 Advanced Seed Meter (ASM) components ......................4-21 ............................. 4-22 ........................4-22 Adjusting The Clevis ............................4-24 ............................4-24 ..............................4-25 Raising the Toolbar Pitch ............................. 4-25 ........................... 4-25 ............................4-26 ..........................4-26 ............................
  • Page 6 ..........................5-20 Rear Wing Wheel Friction Joint ........................... 5-20 ..........................5-21 ................................5-22 Preparing For Storage ............................5-22 ........................... 5-23 ........................5-23 ......................5-24 ................................................................................6-1 Electronics ................................6-4 Planter Electronics ..............................6-5 ........................................................................................................................Torque –...
  • Page 7 1 - GENERAL INFORMATION 1 - GENERAL INFORMATION Note to the Owner This manual contains important information about the safe All persons who will be operating this machine shall possess a valid local vehicle operating permit and/or other applicable dealer to obtain additional manuals and approved service parts.
  • Page 8 1 - GENERAL INFORMATION Planter Model Number / Serial Number Case IH Planter Content Model Number / Location Serial Number Location (Fig. # 1-2) (Fig. # 1-4) below. below. 11202 38th St S. Horace, ND 58047 MODEL # 1-800-446-0316 YIELDTRAC XXR-XX SERIAL # YTXXRXXXXXXXX Fig.
  • Page 9 1 - GENERAL INFORMATION WARNING Electro-Magnetic Compatibility (EMC) As such interference can result in serious malfunction of the • The add-on equipment must not interfere with the functioning...
  • Page 10 1 - GENERAL INFORMATION Determining Left and Right Side of the Machine (1) and right (2) sides of the planter are the Fig. # 1-6 (Shown in Field Up Position, with Optional Rear Hitch, & Row Markers) Determining Orientation Using Directional Arrows the machine.

  • Page 11: Machine Components

    1 - GENERAL INFORMATION Machine Components (Page 1 of 3) Fig. # 1-7 Machine Components, (Shown in Field Position) Item Description Item Description Rear Wing Wheels Right Tow Bar Right Wing Shield Cradle Arm...

  • Page 12: Machine Components

    1 - GENERAL INFORMATION Machine Components (Page 2 of 3) Fig. # 1-8 Machine Components, (Shown in Field Up Position) Item Description Item Description...
  • Page 13 1 - GENERAL INFORMATION Machine Components (Page 3 of 3) Fig. # 1-9 Machine Components, (Shown in Field Up Position With Optional Rear Hitch) Item Description Item Description Rear Wing Wheel Calibration Switch...
  • Page 14 1 - GENERAL INFORMATION...
  • Page 15 2 - SAFETY INFORMATION 2 - SAFETY INFORMATION Personal safety DANGER WARNING CAUTION FAILURE TO FOLLOW DANGER, WARNING, AND CAUTION MESSAGES COULD RESULT IN DEATH OR SERIOUS INJURY. Machine safety NOTICE: Notice indicates a situation which, if not avoided, could result in machine or property damage. The color associated with Notice on the machine decals is BLUE.
  • Page 16 2 - SAFETY INFORMATION Safety rules WARNING Unexpected machine movement! Disengage power, shut down the tractor, and be sure that all moving parts have stopped before servicing, adjusting, cleaning, or unclogging the equipment. Failure to comply could result in death or serious injury. WARNING Failure to comply could result in death or serious injury.
  • Page 17 2 - SAFETY INFORMATION Contact local authorities or utilities to obtain safe clearance distances from high voltage power lines. with soap and water. Wear protective equipment when appropriate. of debris. Air and Air Hoses General Maintenance Safety...
  • Page 18 2 - SAFETY INFORMATION Reinstall guards and shields after servicing the machine. Close all access doors and install all panels after servicing the machine and before operation. engine is running. Wheels and Tires DANGER Explosion hazard! Welding to a wheel can create an explosive air and gas mixture. Removing air from the tire or loosening the the wheel before welding.
  • Page 19 2 - SAFETY INFORMATION Contact local authorities or utilities to obtain safe clearance distances from high voltage power lines. Slow down and signal before turning. Flashing amber warning lamps must be used when operating on the public roads. Fire and Explosion Prevention environment and conditions.
  • Page 20 2 - SAFETY INFORMATION Hazardous Chemicals WARNING Chemical hazard could result in death or serious injury! Failure to comply could result in death or serious injury. WARNING Chemical hazard could result in death or serious injury! Misuse including excessive application rate, uneven application, spray drift, and label violations can cause container’s labels.
  • Page 21 2 - SAFETY INFORMATION contents or the applied material. Utility safety (Self-propelled machines and applicable attachments and accessories) obtain safe clearance distances from high voltage power lines. Electrical Storm Safety protected structure. Mounting and Dismounting Face the machine when mounting and dismounting. Never mount or dismount from a moving machine.
  • Page 22 2 - SAFETY INFORMATION Noise Level Safety Decommission Safety service instructions and in compliance with local laws and regulations.
  • Page 23 2 - SAFETY INFORMATION Chemical Safety and the Environment of products of a chemical and petrochemical nature. NOTICE: The following are recommendations which may be of assistance: Helpful Hints...

  • Page 24: Transporting On Public Roads

    2 - SAFETY INFORMATION Transporting on Public Roads WARNING Transport hazard! Failure to comply could result in death or serious injury. Fig. # 2-1 Transporting on Public Roads Slow Moving Vehicle (SMV) Sign Red Warning Lamp / Brake Lamp Amber Warning Light Reflectors For safe transportation of the Yieldtrac planter on public roads are installed before transporting.
  • Page 25 2 - SAFETY INFORMATION WARNING Unexpected movement! Stay clear when lowering the ladder. Failure to comply could result in death or serious injury. WARNING Fall hazard! handrails and one foot on the step, or one hand on the handrail and both feet on the steps. Failure to comply could result in death or serious injury.
  • Page 26 2 - SAFETY INFORMATION WARNING Crushing hazard! Failure to comply could result in death or serious injury. or stored to avoid the left and right wings shifting during (See Fig. # 2-5) (See Fig. # 2-4) is unfolded. IMPORTANT stowed position on the cradle arms. The cradle lift arm planter when not in use.
  • Page 27 2 - SAFETY INFORMATION position before the planter is unfolded. (See Fig. # 2-8) IMPORTANT (See Fig. # 2-7) position on the planter when not in use. Transport Transport Fig. # 2-8 Main lift cylinder Service / Transport locks ( Storage / Field Position) Fig.
  • Page 28 2 - SAFETY INFORMATION Wing Wheel Cylinder Stops (See Fig. # 2-9) Wing Wheel Wing Fig. # 2-9 Wing Wheel Cylinder Stop ( Service Position) IMPORTANT position on the planter left and right toolbar wing assemblies. planter when not in use. stowed position before the planter is unfolded.
  • Page 29 2 - SAFETY INFORMATION Wing Wheel Arm Transport Stowed wing assemblies. The wing wheel arm transport / storage Position Fig. # 2-11) whenever settling. Wing Wheel Arm Transport Position Fig. # 2-12 Wing Wheel Arm Transport / Storage Locks (Unlocked Position - Install on Both Sides) Transport / Storage Locks...

  • Page 30: Environment

    2 - SAFETY INFORMATION Maintenance Safety WARNING Improper operation or service of this machine can result in an accident. Read and understand the SAFETY INFORMATION Section before you operate or service the machine. Failure to comply could result in death or serious injury. Environment WARNING Chemical hazard!
  • Page 31 2 - SAFETY INFORMATION Safety Signs NOTE: Replacement decals are available from your Yieldtrac planter dealer. Safety Sign Locations Fig. # 2-14 Safety Sign Locations Item Part number Description Qty. Item Part number Description Qty. T0051588 T0051589 T0052291 T0051592 T0052802 T0051593 T0052826 T0051595...
  • Page 32 2 - SAFETY INFORMATION Safety Sign Locations Cont... Fig. # 2-15 Safety Sign Locations Item Part number Description Qty. Item Part number Description Qty. T0051588 T0051589 T0052291 T0051592 T0052802 T0051593 T0052826 T0051595 T0053462 T0051596 T0051653 T0053639 T0051669 T0053939 T0053942 * Not shown In this view 2-18...
  • Page 33 2 - SAFETY INFORMATION Before operating machine, read operator’s manual and ALL SAFETY instructions. If manual is missing, contact your dealer or service department. Before starting engine or Use Slow-Moving Vehicle (SMV) operation, clear area of identification emblem and bystanders. flashing warning lights when Disengage drives, stop engine, operating on highways, except...
  • Page 34 2 - SAFETY INFORMATION Properly prepare machine for transport / roading. Transport with Ag Tractor only. 20 mph [32 km/h] - MAX. road speed. Transport with EMPTY tanks and hoppers only. Towing unit must weigh at least .67 x GROSS weight of towed machine include weight in tanks or hoppers.
  • Page 35 2 - SAFETY INFORMATION TIPPING HAZARD Fold or lower implement before unhooking from tractor drawbar. Failure to comply could result in death or serious injury. P/N T0051575 Fig. # 2-20 Warning Decal Qty 2 Per Machine P/N T0051575 See Fig. # See Fig.
  • Page 36 2 - SAFETY INFORMATION HIGH-PRESSURE FLUID HAZARD To prevent serious injury or death: Relieve pressure on hydraulic system before repairing or adjusting. Wear proper hand and eye protection Keep all components in good repair. P/N T0051669 Fig. # 2-23 Warning Decal Qty 1 Per Machine, P/N T0051669 See Fig.
  • Page 37 2 - SAFETY INFORMATION IMPORTANT CASE DRAIN AND MOTOR RETURN LINES The case drain and motor return lines must be connected before folding/unfolding the toolbar and before pulling the toolbar in working position. Failure to connect these lines will result in failure to the wing fold drive system and void the warranty.
  • Page 38 2 - SAFETY INFORMATION CRUSH HAZARD Stand clear of machine when folding to transport position, or unfolding to planting position. Failure to comply could result in death or serious injury. P/N T0051588 Fig. # 2-27 Warning Decal Qty 2 per machine P/N T0051588 See Fig.
  • Page 39 2 - SAFETY INFORMATION CRUSH HAZARD Stand clear of machine when folding to transport position, or unfolding to planting position. Failure to comply could result in death or serious injury. P/N T0051588 Fig. # 2-30 Warning Decal Qty 2 per machine P/N T0051588 See Fig.
  • Page 40 2 - SAFETY INFORMATION PRESSURIZED HAZARD Avoid serious injury from exploding parts due to overpressurization or operating systems without all components in place. Do not inflate system above 105 psi. Do not remove pressure relief valve. Do not pressurize system unless all row unit components are in place.
  • Page 41 2 - SAFETY INFORMATION WARNING Pin Transport Lock Into Position Before Servicing Transporting CRUSH HAZARD BEFORE SERVICING OR TRANSPORTING UNIT • Install transport locks on the left and right side of the machine to avoid cylinders settling during servicing or transport. Failure to comply could result in death or serious injury.
  • Page 42 2 - SAFETY INFORMATION IMPORTANT WARNING CHEMICAL HAZARD • Wear Protective Equipment as directed on Chemical Label. 1. Main Fill Valve: (Located on Ladder) Failure to comply 2. Tank Shut-Off Valve: Is used to stop the flow of fertilizer from the could result in tank to the pump.
  • Page 43 2 - SAFETY INFORMATION WARNING Transport / Storage Locks Stow Position Lock Position CRUSH HAZARD BEFORE TRANSPORTING OR STORING UNIT • Install transport / storage locks on the left and right side wing wheel arms to avoid cylinders settling. Failure to comply could P/N T0053939 result in death or serious injury.
  • Page 44 2 - SAFETY INFORMATION WARNING Transport Locks Lock Position Stow Position CRUSH HAZARD BEFORE SERVICING OR TRANSPORTING UNIT • Install transport locks on the left and right side cradle lift arms to avoid cylinders settling during transport or servicing. P/N T0053715 Failure to comply could result in death or serious injury.
  • Page 45 2 - SAFETY INFORMATION WARNING Locked Position Stowed Position CRUSH HAZARD BEFORE SERVICING OR TRANSPORTING UNIT • Install transport lock to avoid left and right wings shifting during servicing or transport. Failure to comply could result in death or serious injury. P/N T0052802 Fig.
  • Page 46 2 - SAFETY INFORMATION WARNING left and right wings shifting during servicing or transport. Failure to comply could result in death or serious injury. P/N T0052826 Fig. # 2-47 Important Decal Qty 1 Per Machine P/N T0052826 See Fig. # 2-47 Important Decal Fig.
  • Page 47 2 - SAFETY INFORMATION Install Cylinder Stop Before Servicing CRUSH HAZARD BEFORE SERVICING UNIT Install cylinder stops on the left and right side of the wing lift cylinders to avoid cylinders settling during servicing. Failure to comply could result in death or serious injury. P/N T0051737 Fig.
  • Page 48 2 - SAFETY INFORMATION DANGER CRUSHING HAZARD • Keep everyone away from the wing wheel arm and wing folding / unfolding area. • Always use wing wheel arm transport / storage locks to avoid cylinders settling. Failure to comply, will result in death or serious injury.
  • Page 49 2 - SAFETY INFORMATION CHEMICAL HAZARD Wear Protective Equipment as directed on Chemical Label. Failure to comply could result in death or serious injury. P/N T0051589 Fig. # 2-54 See Fig. # 2-54 Warning Decal Fig. # 2-55 Safety Sign Location - Rear, Right Side On Step Ladder 2-35...
  • Page 50 2 - SAFETY INFORMATION Ladder may move unexpectedly, stay clear when lowering. Face the ladder when climbing up and down. One person on the ladder at a time. Raise and lock the ladder when not in use. P/N T0051596 Fig. # 2-56 Warning Decal Qty 1 Per Machine, P/N T0051596 See Fig.
  • Page 51 2 - SAFETY INFORMATION Fig. # 2-58 Warning Decal Qty 2 Per Machine, P/N 47433195 See Fig. # 2-58 Warning Decal Fig. # 2-59 Warning Decal - On The Top Of The Bulk Fill Hopper Lids 2-37...
  • Page 52 2 - SAFETY INFORMATION WARNING NO STEP Failure to comply could result in death or serious injury. P/N T0051653 Fig. # 2-60 Warning Decal Qty 1 Per Machine, P/N T0051653 See Fig. # 2-60 Warning Decal Fig. # 2-61 Warning Decal Located on Bulk Fill Frame 2-38...
  • Page 53 2 - SAFETY INFORMATION NOTICE FAN MOTOR CASE DRAIN LINE Failure to connect this line to a case drain pressure will result in motor failure and void the warranty. FAN MOTOR CASE DRAIN LINE Failure to connect this line to a case drain port with less than 25 psi (170 kPa) back- pressure will result in...
  • Page 54 2 - SAFETY INFORMATION NOTICE MOTOR RETURN LINE This line must be connected to the motor return coupler Failure to connect the motor return line will result in failure to the wing fold drive system and void the warranty. MOTOR RETURN LINE This line must be connected to the motor return coupler before folding/unfolding the toolbar, and...
  • Page 55 2 - SAFETY INFORMATION DANGER ELECTROCUTION HAZARD Keep markers away from overhead electrical wires. Failure to comply will result in death or serious injury. CRUSH HAZARD KEEP CLEAR Markers actuate automatically. Failure to comply could result in death or serious injury. P/N T0051591 Fig.
  • Page 56 2 - SAFETY INFORMATION NOTICE 172 - 156 N·m (127 - 115 lb ft). to the planter and property. Fig. # 2-69 Notice Decal Qty 2 Per Machine, P/N T0052464, Case IH P/N 47450633 See Fig. # See Fig. # 2-69 Notice 2-69 Notice Decal...

  • Page 57: Road Transport

    3 - TRANSPORT OPERATIONS 3 - TRANSPORT OPERATIONS Road Transport Transporting on Public Roads WARNING Transport hazard! visible. Failure to comply could result in death or serious injury. WARNING Hazard to bystanders! Be sure all persons and pets are standing clear during planter folding and unfolding. Failure to comply could result in death or serious injury.

  • Page 58: Tractor Requirements

    3 - TRANSPORT OPERATIONS Tractor Requirements Minimum Tractor Power Required Tractor Remote Relief Pressure Remote control valves The tractor remote should have a minimum relief pressure of Hydraulic Flow Requirement Case Drain Line to the tractor remote valves are included with the planter. proper connection to the tractor remote valves.
  • Page 59 3 - TRANSPORT OPERATIONS Hitch Requirements IMPORTANT the hitch coupler. IMPORTANT manual for important information on seasoning the rubber Note: The drawbar must be extended to the center position on Magnum tractors and to the outer position Steiger tractors. as soon as possible. Avoid high speed roading with new or the Yieldtrac planter.

  • Page 60: Planter Weights

    3 - TRANSPORT OPERATIONS Planter Weights Planter Weights 36R-20: Planter Load Status Weight Total Without and Row Cleaners With Row Cleaners Planter Weights 36R-22: Planter Load Status Weight Total Without and Row Cleaners With Row Cleaners...
  • Page 61 3 - TRANSPORT OPERATIONS Hydraulic Connections “Motor Return” must be connected to the motor return coupler before folding/ Connect the Yieldtrac Planter Bar 36R22 Failure to connect the motor return line will result in failure to the wing fold drive system and void the fan circuit labeled “Case Drain”...
  • Page 62 3 - TRANSPORT OPERATIONS Motor Case Drain Kits Magnum (7100, 7200, 8900) - 367010A* Fig. # 3-6 Part Description Number 810139C2 tee connector. (2) to the opposite end of the supplied hose (1). 201-422 Plate 4. Route the hose to the rear of the tractor and attached with tie straps as needed.
  • Page 63 3 - TRANSPORT OPERATIONS Magnum (MX180-270) Fig. # 3-8 Part Description Number 385358A1 220066A1 220068A1 814-10150 218-5058 Fig. # 3-7 NOTICE: Clean the area around the hydraulic coupler to avoid contaminating the hydraulic system when the system er case drain line. is opened.
  • Page 64 3 - TRANSPORT OPERATIONS Magnum Tractors Motor return equipped tractors return casting as the low pressure return for the vacuum fan NOTE: The 3/4 in ID return line from the multivalve for the planter fan and seed drives may be connected to the motor return port (3) on the casting.
  • Page 65 3 - TRANSPORT OPERATIONS Power Beyond Equipped Tractors use the case drain (low pressure return) port on the casting tion. in coupler. This table lists the mating male couplers to the Port Nom. Size Part No. Thread Size 3/4 in 347755A * 1-1/16-12 orb 3/4 in...
  • Page 66 3 - TRANSPORT OPERATIONS Fig. # 3-12 Part Description Number 187563C1 218-5057 Connector, 9/16-18 the hose to the rear of the tractor. Secure the hose with 91163C1 Hose, 3/8 X 47 in tie straps as required. 218-5367 Fitting, 3/4 male X 3/8 female orb 218-5135 (1) on the hose with the connector (2).
  • Page 67 3 - TRANSPORT OPERATIONS Steiger 9100, 9200, 9300 - 367011A* Part Description Number 380739A1 NOTICE: DO NOT connect the planter fan case drain hose to the load sense (3) or pilot supply (4) ports. Fan motor casting. damage will occur. Neither port is a low pressure return. The properly mates with the case drain port (1) shown.

  • Page 68: Electrical Connections

    3 - TRANSPORT OPERATIONS Electrical Connections power outlet at the rear of the tractor. Connect the 9-pin connector (2) from the planter harness to Fig. # 3-16 Description 9-Pin Connector Advanced Farming System (AFS ) Dis- ® play harness. Refer to the AFS® software manual for setup and complete operating instructions.

  • Page 69: Planter Lighting

    3 - TRANSPORT OPERATIONS Planter lighting illuminate along with the tractor's. in detail (A) in (Fig. # 3-17) on the hitch harness behind the (2). Fig. # 3-18 Planter lighting should follow the pattern indicated in the table below. The Yieldtrac Planter Bar 36R20/22 Front Fold Tractor Lights Road Lights ON...
  • Page 70 3 - TRANSPORT OPERATIONS SHIPPING TRANSPORT WARNING Hazard to bystanders! the area. Failure to comply could result in death or serious injury. S e c u r e secure the planter to the trailer bed with the original shipping C h a i n s dealer to obtain the stand.

  • Page 71: Planter Preparation

    4 - WORKING OPERATIONS 4 - WORKING OPERATIONS GENERAL INFORMATION Planter Preparation DANGER Unexpected machine movement! Air in the hydraulic system could cause unexpected machine movement. Purge the air from the hydraulic system after any hydraulic system maintenance or repair. Failure to comply will result in death or serious injury.

  • Page 72: Planter Preparation Frame Control

    4 - WORKING OPERATIONS Planter Preparation Frame Control IMPORTANT Before unfolding the planter, consult pages 2-12 thru. Unfolding and Folding the Planter IMPORTANT ® See Fig. # 4-1 CASE DRAIN AND MOTOR RETURN LINES The case drain and motor return lines must be button.
  • Page 73 4 - WORKING OPERATIONS (See Fig. to access the planter unfold functions. (See Fig. # 4-3) # 4-5) Fig. # 4-3 Fig. # 4-5 are not used for the Yieldtrac Planter. function to lower the wing wheels. (See Fig. # 4-6) NOTE: The frame control functions can also be placed on (See Fig.
  • Page 74 4 - WORKING OPERATIONS Wing Wing Wheel Wheel Wing Wing Wheel Wheel Fig. # 4-7 Fig. # 4-8...
  • Page 75 4 - WORKING OPERATIONS (See Fig. # 4-9) Fig. # 4-9 11. Push the corresponding remote lever forward for the wing wheels to the ground. (See Fig. # 4-10 & Fig. # 4-11) Fig. # 4-10...
  • Page 76 4 - WORKING OPERATIONS Fig. # 4-11 Unfolding - Wing Wheels on the ground with Row Units Up (Step # 2)
  • Page 77 4 - WORKING OPERATIONS 12. Place the gear shifter lever in the “Neutral” position or “Reverse” Wings” ter Section”. (See Fig. # 4-12). Fig. # 4-12 13. Push the corresponding remote lever forward for the lift and fold function to unfold the left and right wings. 14.
  • Page 78 4 - WORKING OPERATIONS Fig. # 4-13 Unfolded Field Position with Row Units Up (Step 3) Fig. # 4-14 Unfolding - Left and Right Wings unfolded (Step # 3)
  • Page 79 4 - WORKING OPERATIONS (See the planting position. (See Fig. # 4-16) Fig. # 4-15) Fig. # 4-16 Front Hitch Locked begin the planting sequence. Fig. # 4-15...

  • Page 80: Folding The Planter

    4 - WORKING OPERATIONS Folding the Planter IMPORTANT CASE DRAIN AND MOTOR RETURN LINES The case drain and motor return lines must be connected before folding/unfolding the toolbar tion. Failure to connect these lines will result in failure to the wing fold drive system and void the warranty.
  • Page 81 4 - WORKING OPERATIONS access the planter fold functions. (See Fig. # 4-20) Fig. # 4-20 (Fig. # 4-21). Fig. # 4-21 Planter Frame Control “Fold” Screen 4-11...
  • Page 82 4 - WORKING OPERATIONS button (See Fig. # 4-22) Fig. # 4-22 Planter Frame Control “Fold” Screen fold function to raise the planter to fold height. position. (See Fig. # 4-23) Fig. # 4-23 Unfolded Field Position with Row Units Up (Step # 1) 4-12...
  • Page 83 4 - WORKING OPERATIONS button (See (See Fig. # 4-26) Place Fig. # 4-24) the gear shifter lever in the “Neutral” position or “Forward” depending on the terrain. Fig. # 4-24 Planter Frame Control “Fold” Screen Fig. # 4-26 Planter Frame Control “Fold” Screen 11.
  • Page 84 4 - WORKING OPERATIONS Fig. # 4-28 Folding Left and Right Wings (Step # 2) (See Fig. # 4-29) Fig. # 4-29 Folding - Wing Wheels on the Ground with Row Units Up (Step # 3) 4-14...
  • Page 85 4 - WORKING OPERATIONS fold function to raise the center section from the ground. (See (See Fig. # 4-31) Fig. # 4-30) Fig. # 4-30 Planter Frame Control “Fold” Screen Fig. # 4-31 4-15...
  • Page 86 4 - WORKING OPERATIONS fold function to raise the wing wheels. (See Fig. # 4-32) (See Fig. # 4-33) Fig. # 4-32 Planter Frame Control “Fold” Screen Fig. # 4-33 4-16...
  • Page 87 4 - WORKING OPERATIONS 19. The planter should now be in the transport position. (See Fig. # 4-34) Fig. # 4-34 (See Fig. # 4-36) (SeeFig. # 4-35) Fig. # 4-36 IMPORTANT After the folding operation is completed, consult pages 2-12 thru.
  • Page 88 4 - WORKING OPERATIONS Labeling Row Unit Components Row units are referenced from left to right on all Yieldtrac Planter Bar 36R22 (Fig. # 4-37 & Fig. # 4-38) (Fig. # 4-39) with the Frame Fig. # 4-39 Advanced Seed Meter Components Singulator Agitator Brushes...
  • Page 89 4 - WORKING OPERATIONS Advanced Seed Meter (ASM) Planting System Fig. # 4-40 Advanced Seed Meter (ASM) planting system Yieldtrac Front Fold Planter Bar Over- view application rate without leaving the cab and enhanced control meter drive as standard equipment. applied rates on the go.
  • Page 90 4 - WORKING OPERATIONS Liquid fertilizer Meters. ® ® control. Application rate can be changed while planting without changing seed population. mini-hoppers to feed the Advanced Seed Meters. ® ® monitored and controlled. 4-20...

  • Page 91: Advanced Seed Meter (Asm) Components

    4 - WORKING OPERATIONS Advanced Seed Meter (ASM) components Releasing a latch on the seed hopper provides access to the Fig. # 4-41 Advanced Seed Meter Components ® ® software operator Singulator manual for more information. Agitator Brushes Baffle Brushes (3) Singulator (1) in the Seed Meter Settings chart.
  • Page 92 4 - WORKING OPERATIONS Leveling the Planter Toolbar height and level adjustment should be performed in The planter row units must be parallel to the ground when to the correct height will guarantee that the row units are level to the ground. (1) should be level from the front hitch to the front of the center toolbar.
  • Page 93 4 - WORKING OPERATIONS 3. The planter hitch is equipped with a clevis which can be which creates level row units. The clevis can be installed (See Fig. # 4-44) NOTE: The planter was leveled at the factory at “Position 2” NOTE: 1st Position 2nd Position...

  • Page 94: Adjusting The Clevis

    4 - WORKING OPERATIONS Adjusting The Clevis hitch clevis to a lower position. (The default location from Note: The planter was leveled at the factory at “Position 2” hitch clevis to a higher position. (3). hardware securing the hitch clevis to the planter tongue. Fig.

  • Page 95: Raising The Toolbar Pitch

    4 - WORKING OPERATIONS Toolbar Leveling P l a c e Fig. # 4-48 Rotate Turnbuckle Counter Clockwise to Raise Toolbar Pitch Fig. # 4-46 Place Level Here Lowering the Toolbar Pitch (See Fig. # 4-47) lowers the pitch of the toolbar. Perform this at each upper End Wrench Fig.
  • Page 96 4 - WORKING OPERATIONS Liquid Fertilizer System ® control. ® The application rate can be changed on the AFS monitor while planting without changing seed population. Description Fig. # 4-50 Pressure Gauge Filter Fig. # 4-51 4-26...
  • Page 97 4 - WORKING OPERATIONS ” (3) is located on the (See Fig. # 4-54) and is used to (Located on Ladder) (Located on Left Side Near Filter) NOTE: This valve needs to be open during operation. (Right Side Under Tank) ”...
  • Page 98 4 - WORKING OPERATIONS (See Fig. # 4-56) NOTE: Fig. # 4-56 (See Fig. # 4-57) Fig. # 4-57 4-28...
  • Page 99 4 - WORKING OPERATIONS Liquid Fertilizer System Operation (1) and then “ON” (See Fig. # 4-58) Fig. # 4-59 Inline Filter and Intake Port ® the AFS an air pressure of 10 psi (about 20% of the normal operating at the air valve (4) on the pump. Fig.
  • Page 100 4 - WORKING OPERATIONS NOTE: Cont’d... (1) to the sectional control valves (2) and pressure gauge (3). Readouts from cleaning. sure. The operator controls the sectional control valves (2) from ® the AFS ® the AFS ® same time. Refer to the AFS operating manual.
  • Page 101 4 - WORKING OPERATIONS Refer to the table on the following pages to select the correct NOTE: 100 mesh screens are available from your Norwood raised out of planting position. system must be re-calibrated if the mesh screens are added.
  • Page 102 4 - WORKING OPERATIONS precise. Fertilizer Weight (lbs/gallon) Conversion Factor 0.84 0.92 0.96 0.98 8.34 (water) 1.00 1.00 1.08 1.04 10.0 1.20 1.10 10.65 (28% nitrogen) 1.28 1.13 11.0 1.32 1.15 12.0 1.44 1.20 14.0 1.68 1.20 Example: 10 g/ac Weight of one gallon = 10.65 lb Conversion factor from chart = 1.13 4-32...
  • Page 103 4 - WORKING OPERATIONS 20 in spacing Pressure Gallons/Acre - 20 Inch Spacing Per Nozzle (PSI)* Size 4 MPH 5 MPH 6 MPH 7 MPH 8 MPH Oz/Min. CP4916-29 0.094 0.108 0.132 11.3 0.153 CP4916-35 0.111 10.1 0.136 14.3 11.4 0.193 16.5 13.2...
  • Page 104 4 - WORKING OPERATIONS 22 in spacing Pressure Gallons/Acre - 22 Inch Spacing Per Nozzle (PSI)* Size 4 MPH 5 MPH 6 MPH 7 MPH 8 MPH Oz/Min. CP4916-29 0.094 0.108 0.132 10.3 0.153 CP4916-35 0.111 0.136 10.6 13.0 10.4 0.193 15.0 12.0...
  • Page 105 4 - WORKING OPERATIONS In-Furrow Fertilizer Applicators the seed shoe (1) (See Fig. # 4-64) Fig. # 4-64 Seed being dragged out of position by Seed Shoe residue which interferes with accurate placement of the seed. (See Fig. # 4-65) NOTE: The display cannot detect interference from an in-furrow attachment.
  • Page 106 4 - WORKING OPERATIONS • Center the tip of the applicator tube (1) over the seed trench (2). NOTE: Following these guidelines should eliminate most seed spacing interference, but cannot guarantee success in determine if seed placement is acceptable. Fig. # 4-68 Center the Tip of the Applicator 4-36...

  • Page 107: Planting

    4 - WORKING OPERATIONS Planting Fig. # 4-69 Bulk Hopper System Components (Left Side Shown) Fig. # 4-70 Bulk Hopper System Components (Right Side Shown) Description Description Your Yieldtrac Planter Bar 36R22 is equipped with two cen- tral 2.1 m³ ( 60 Bu) and controlled.
  • Page 108 4 - WORKING OPERATIONS WARNING Unexpected movement! Stay clear when lowering the ladder. Failure to comply could result in death or serious injury. The hopper platform can be accessed with the folding step storage position. The step ladder can be folded or unfolded depending on planter is lowered to the planting position.
  • Page 109 4 - WORKING OPERATIONS retaining bolt on the side of the platform railing. (See Fig. # Loosen bolt and raise light to desired height Tighten bolt when desired height is achieved. Fig. # 4-74 Bulk Fill Platform Light Down Fig. # 4-75 Bulk Fill Platform Light Up 3.
  • Page 110 4 - WORKING OPERATIONS Seed Population/Spacing Chart for 36R-20, & 36R-22 Seed Population Seed Population Seed Seed Spacing Spacing Seed/Acre Seed/Acre Seed/Acre Seed/Acre (Inch/seed) (Inch/seed) 20 inch rows 22 inch rows 20 inch rows 22 inch rows 0.25 0.50 8.00 8.25 1.00 8.50...

  • Page 111: Environment

    5 - MAINTENANCE 5 - MAINTENANCE GENERAL INFORMATION Maintenance Safety Environment WARNING Improper operation or service of this machine can result in an accident. Read and understand the SAFETY INFORMATION Section before you operate or service the machine. Failure to comply could result in death or serious injury. WARNING Chemical hazard! When handling fuel, lubricants, and other service chemicals, follow the manufacturer’s instructions.
  • Page 112 5 - MAINTENANCE WARNING Improper operation or service of this machine can result in an accident. Read and understand the SAFETY INFORMATION Section before you operate or service the machine. Failure to comply could result in death or serious injury. WARNING Failure to comply could result in death or serious injury.
  • Page 113 5 - MAINTENANCE MAINTENANCE CHART Replace Cleaning Change Fluid Adjust Drain Fluid Grease # of Interval Page # Maintenance Action Pts. IMMEDIATE BEFORE ROADING FIRST 1 HOUR *5-9 OR EACH DAY *5-11 5-10 5-10 *5-13 *5-16 Pneumatic Air Compressor Filter *5-16 *5-17 5-11...
  • Page 114 5 - MAINTENANCE Replace Cleaning Change Fluid Adjust Drain Fluid Grease # of Interval Page # Maintenance Action Pts. *5-31 *5-33 *5-38 *5-42 Pneumatic down pressure (if equipped) *5-44 Wing wheel drive chain case 5-18 Rear Wing Wheel Friction Joint 5-18 5-19 Seed meter inspection...
  • Page 115 5 - MAINTENANCE Immediate / Before Roading Note: The track system must be dry and properly seasoned before checking the alignment. Note: For proper track operation the track toe setting needs to be within proper range. The track toe setting is set at the factory and does not need to be adjusted.
  • Page 116 5 - MAINTENANCE Alignment Adjustment Screw Both Sides Fig. # 5-4 Outer Right Side Track Alignment Adjusting Fig. # 5-6 Checking Gaps at Front Idler Screw location Check Check For Wear For Wear Here Here Alignment Fig. # 5-7 Checking Guide Lug Gap and Wear Adjustment Screw Fig.
  • Page 117 5 - MAINTENANCE Before Planting To Adjust the Steering: Steering Adjustment: See Fig. # 5-9) • Turn each tie rod in equal amounts in the same direction. Note: Ensure each tie-rod is adjusted in equal amounts so on toe adjustment for additional information. •...
  • Page 118 5 - MAINTENANCE Alignment Method Note: Do not adjust screws by more than 1/2 turn at a time. Re-tighten lock nuts before driving tractor. Note: The track will not likely center, what is important is that the track is not running hard to one side or the other. Tracks due to rubbing, is the best way to achieve correct alignment.
  • Page 119 5 - MAINTENANCE To Move RH To Move LH Forward Direction Track Outward Track Inward of Travel Inner Outer Right Left Side Side Tighten Tighten Tighten Tighten This Side This Side This Side This Side Outer Inner Right Left Side Side To Move RH To Move RH...
  • Page 120 5 - MAINTENANCE Toe Adjustment: below the rear idler wheel hubs (See Fig. # 5-11). Toe is the steer relationship between the left and right • The measured distance between the front and rear idler undercarriage. For proper operation the left and right undercarriage needs to be running parallel to each other.
  • Page 121 5 - MAINTENANCE First 1 Hour (See Fig. # 5-10) Number Location Wheel Torque of Lug Size Nuts Ø25.5 320 ft-lbs (434 N-m) Ø25.5 320 ft-lbs (434 N-m) Idler Wheel Idler Wheel Lug Nuts Lug Nuts Fig. # 5-13 Checking For Correct Lug Nut Torque Wing Wheel Lug Nut Torque (See Fig.
  • Page 122 5 - MAINTENANCE Every 10 Hours or Daily re-torque all lug nuts. (See Fig. #5-9) Number Location Wheel Torque of Lug Size Nuts 320 ft-lbs (434 N-m) Ø25.5 Ø25.5 320 ft-lbs (434 N-m) Idler Wheel Idler Wheel Lug Nuts Lug Nuts Wing Wheel Lug Nut Torque Fig.
  • Page 123 5 - MAINTENANCE Every 10 Hours or Daily NOTICE: Liquid Fertilizer System Maintenance rate from the liquid and clog the system. NOTE: Refer to Storage pages in this section for instruc- system. Fig. # 5-17 Inline Filter and Intake Port Fig.
  • Page 124 5 - MAINTENANCE Every 10 Hours or Daily CAT 5 Ball Hitch Assy the grease becomes visible) ft). (See Fig. # 5-13) Fig. # 5-20 Grease CAT 5 Ball Hitch Fig. # 5-19 Check Marker Breakaway Bolt NOTE: Grade 5 bolts must be used on all 36R22 planter row marker breakaway applications.
  • Page 125 5 - MAINTENANCE Left & Right Tow Bar Gate Assy’s Every 50 Hours Grease 3 points (6 points total) (1) Rear Wing Wheel Caster Hub Bearing the grease becomes visible) Grease 1 point on each wheel (4 points total) (1) on the rear 3 Pumps).

  • Page 126: Stub Arm Pivots

    5 - MAINTENANCE Every 50 Hours Wing Wheel Pivots Grease the 2 point (4 Points Total) on the left and right wing Wing Flex Pivots wheel rotation pins (1) Grease the point (1) (Pump until the grease becomes visible) becomes visible) Fig.
  • Page 127 5 - MAINTENANCE Every 50 Hours locat- Main Lift Pivots Grease the 4 points on the left and right side of the main lift pivots (1) the grease becomes visible) Fig. # 5-28 Main Lift Pivot Grease Zerks (Front Left) Fig.
  • Page 128 5 - MAINTENANCE Every 50 Hours Telescoping Hitch Rollers located as shown below (1) lent. (Note: Both hitch rollers are greased by the one grease assemblies (1) comes visible) (See Fig. # 5-26) . (Pump until the grease becomes visible) Fig.

  • Page 129: Tie Rods

    5 - MAINTENANCE Every 50 Hours Tie rods tie rods located on Wing Wheel Arm Cylinder Pivots EP or equivalent. (See Fig. # 5-31) . (Pump until the grease (1) (4 points total) on the wing becomes visible) ible) Fig. # 5-37 Tie rod Grease Zerk Points Fig.

  • Page 130: Rear Wing Wheel Friction Joint

    5 - MAINTENANCE Every 200 Hours Wing Wheel Drive Chain Case Allen wrench to remove the 3/8” NPT drain plug at the (See Fig. #5-32) Gear Remove Plug Fig. # 5-40 Fill Gear Lube Until it Reaches the Bottom of the Fill Plug Threads Fig.
  • Page 131 5 - MAINTENANCE Every 200 Hours cated as shown below (1) (See Fig. # 5-36, & Fig. # 5-37) (Approx. 3 Pumps) Fig. # 5-42 Implement Jack Grease Points Fig. # 5-43 Implement Jack Grease Points 5-21...

  • Page 132: Preparing For Storage

    5 - MAINTENANCE STORAGE Preparing For Storage WARNING Crushing Hazard! planter. Failure to comply could result in death or serious injury. WARNING Equipment Rolling Hazard! tions. Failure to comply could result in death or serious injury. 1. Store the planter inside for protection from the weather. soil.
  • Page 133 5 - MAINTENANCE or stored to avoid the left and right wings shifting during (See Fig. # 5-41) storage position on the left wing. The left to right wing (See Fig. # 5-41) before the planter is unfolded. IMPORTANT stowed position on the cradle arms. The cradle lift arm planter when not in use.
  • Page 134 5 - MAINTENANCE Wing Wheel Arm Transport Stowed wing assemblies. The wing wheel arm transport / storage Position Fig. # 5-44) whenever settling. Wing Wheel Arm Transport Position Fig. # 5-50 Wing Wheel Arm Transport / Storage Locks (Unlocked Position - Install on Both Sides) Transport / Storage Locks...
  • Page 135 5 - MAINTENANCE (See WARNING Fig. # 5-48) CRUSH HAZARD Stowed Position Failure to comply could result in death or seri- ous injury. (See Fig. # 5-46) Fig. # 5-54 Rotate Jack Handle From the Stowed Position (See Fig. # 5-49) Fig.
  • Page 136 5 - MAINTENANCE engage the lower gearing. (See Fig. # 5-51) (See Fig. # 5-50) 2-Speed Shifting Jack Fig. # 5-57 With a Pushing, Twisting Motion, Set the Jack Handle in High Gear position. (See Fig. 5-52) P/N T0053639 Stowed Position Fig.
  • Page 137 5 - MAINTENANCE NOTICE: Be sure that the water is not released on any electrical components or on any other equipment that may be sen- sitive or damaged due to water and/or high pressure. Equipment damage may result. Liquid Fertilizer System Tee Jet (See Fig.
  • Page 138 5 - MAINTENANCE NOTE: Follow the manufacturer's instructions for system soap and water until all material is removed. Reinstall the preparation and proper concentration for your winter con- ditions. NOTE: Leave the applicator lines and check valves open to NOTE: aid evaporating moisture from the system.
  • Page 139 6 - TROUBLESHOOTING 6 - TROUBLESHOOTING SYMPTOM(S) Problem Possible Cause Correction Low vacuum or Tractor output less than required. Connect as recommended. Flow” alarm. Set as recommended. Worn fan motor. Replace motor. Row unit vacuum hose(s) damaged. Repair or replace as required. Replace as required.
  • Page 140 6 - TROUBLESHOOTING Problem Possible Cause Correction Tractor engine RPM too low reducing Planter frame pump output. draulic pump output. does not raise to full up position. viced. Remote valve lever detent set too low The tractor must be equipped with 2500 psi relief valve.
  • Page 141 6 - TROUBLESHOOTING Problem Possible Cause Correction Erratic fertilizer system operation. Set as recommended. Reduce height planter frame is raised Wing wheels create berms on enough to lift row unit out of the ground. headland turns. Set as recommended.

  • Page 142: Electronics

    6 - TROUBLESHOOTING Electronics The new electronics on the Yieldtrac Planter Bar 36R22 Rate (2) (1) are located on the left and right side of the center bar. Fig. # 6-1 Right Side ECU Locations Shown Fig. # 6-2 Left Side ECU Location Shown •...

  • Page 143: Planter Electronics

    6 - TROUBLESHOOTING Planter Electronics Liquid Fertilizer Harness The electronics on the Yieldtrac Planter Bar 36R22 use 7-Pin Extension Harness current protected outputs thus reducing the number of fuses required. Hitch Harness Clutch and Seed Harness The hitch harness distributes power from the tractor to the The center clutch and seed harness connects to the toolbar harness with a single or double row clutch adaptor harness and the lighting module are also on this harness.
  • Page 144 6 - TROUBLESHOOTING...
  • Page 145 7 - SPECIFICATIONS 7 - SPECIFICATIONS Flat Fold: Planter Type: Yieldtrac Planter Bar 36R20 - Front Fold Trailing Planter Wing Wheels (Qty. 8) Titan Trac Loader TL 14-17.5NHS Safety Equipment: 6 Ply, Tubeless Monitor ® • AFS Row Units: manuals for additional information. Row Unit Empty Weight: Rear Hitch Capacity Seed Openers:...
  • Page 146 7 - SPECIFICATIONS Wing Float 36R-20: 19° Do not exceed slopes with grades greater than 19° Damage to the machine may result. Fig. # 7-1 Wing Float (Upward) 18° Do not exceed slopes with grades greater than 18° Damage to the machine may result. Fig.
  • Page 147 7 - SPECIFICATIONS Planter Over All Width 36R-20: (See Fig. # 7-3) Fig. # 7-3 Transport Position Planter Width. With, or Without Markers Transport Position Dimensions With, or Without Row Planter Over-All Height 36R-20: (See Fig. # 7-4) Planter Over All Length: Fig.
  • Page 148 7 - SPECIFICATIONS 36R-20 Field Position Dimensions: 36R-20 Field Down & Up Position Length: 36R-20 Planter Width: (See (See Fig. # 7-5) Fig. # 7-5) 16” Fig. # 7-5 Field Position Planter Width and Length...
  • Page 149 7 - SPECIFICATIONS Planter Undercarriage 36R-20 (center to center) (See Fig. # (See Fig. # 7-6) 7-6) 18” 120” Fig. # 7-6 Undercarriage Center to Center and Width Planter Weight 36R-20: Planter Load Status Weight Total Without and Row Cleaners With Row Cleaners...
  • Page 150 7 - SPECIFICATIONS Planter Type: Yieldtrac Planter Bar 36R22 - Front Fold Flat Fold: Trailing Planter Wing Wheels (Qty. 8) Titan Trac Loader TL 14-17.5NHS 6 Ply, Tubeless Safety Equipment: Monitor Row Units: ® • AFS Row Unit Empty Weight: manuals for additional information.
  • Page 151 7 - SPECIFICATIONS Wing Float 36R-22: 16° Do not exceed slopes with grades greater than 16° Damage to the machine may result. Fig. # 7-7 Wing Float (Upward) 20° Do not exceed slopes with grades greater than 20° Damage to the machine may result. Fig.
  • Page 152 7 - SPECIFICATIONS Planter Over All Width 36R-22: (See Fig. # 7-9) Fig. # 7-9 Transport Position Planter Width With or Without Markers Transport Position Dimensions With or Without Row Planter Over All Height 36R-22: (With or Without Row (See Fig. # Planter Over All Length36R-22: (With or Without Row 7-10) Fig.
  • Page 153 7 - SPECIFICATIONS Field Position Dimensions 36R-22: Field Position Length 36R-22: Planter Width 36R-22: down position) 39 ft 5 in (See Fig. # 7-11) (See Fig. # 7-11) Position Fig. # 7-11 Field Position Planter Width and Length...
  • Page 154 7 - SPECIFICATIONS Planter Undercarriage 36R-22 (center to center) (See Fig. # (See Fig. # 7-12) 7-12) 18” 88” Fig. # 7-12 Undercarriage Center to Center and Width Planter Weight 36R-22: Planter Load Status Weight Total Without and Row Cleaners With Row Cleaners 7-10...
  • Page 155 7 - SPECIFICATIONS WARNING CRUSH HAZARD Planter Height (See Fig. # 7-13) DANGER Contact local authorities or utilities to obtain safe clearance distances from high voltage power lines. 36R-20 36R-22 Fig. # 7-13 Approximate Maximum Row Marker Height While Unfolding Markers (Shown in Field/Planting Position) 7-11...
  • Page 156 7 - SPECIFICATIONS Torque – Hydraulic Tubes and Fittings O-Ring Boss Plugs, Adjustable Tube Nuts for 37° Flared Fittings 37 ° Seats Tubing OD ft-lbs ft-lbs Size Thread Size Inches 5/16 1/2-20 9/16-18 3/4-18 15.9 19.1 1-1/6-12 22.2 1-3/16-12 25.4 1-5/16-12 1-1/4 31.8...
  • Page 157 7 - SPECIFICATIONS Torque – Fasteners Society of Automotive Engineers (SAE) fastener torque SAE Grade No. Grade 2 Grade 5 Grade 8 (See Note below.) Bolt Head (See Note below.) ft-lbs ft-lbs ft-lbs Bolt Size Min. Max. Min. Max. Min. Max.
  • Page 158 7 - SPECIFICATIONS Metric International Standards Organization (ISO) Fastener Torque ISO Class No. 10.9 12.9 Bolt Head 10.9 12.9 (See Note below.) ft-lbs ft-lbs ft-lbs Bolt Size Min. Max. Min. Max. Min. Max. Min. Max. Min. Max. Min. Max. range is to be determined 10.9 fasteners can be used 1050 1100...
  • Page 159 8 - FORMS AND DECLARATIONS 8 - FORMS AND DECLARATIONS...
  • Page 160 8 - FORMS AND DECLARATIONS...
  • Page 161 8 - FORMS AND DECLARATIONS Dealer to inspect the following items and adjust if necessary: protective covering as required. electrical harnesses. unit. ordering and record the serial number on this sheet Couplers. T0053896 03/06/2015...
  • Page 163 8 - FORMS AND DECLARATIONS Dealer to inspect the following items and adjust if necessary: protective covering as required. electrical harnesses. unit. ordering and record the serial number on this sheet Couplers. T0053896 03/06/2015...
  • Page 165 Index Symbols ..........................1-1 ..................................3-6 ..............................3-6 9200 ..................................3-11 ..............................3-11 ......................5-8 Adjusting The Clevis ............................4-24 ......................3-12 Advanced Seed Meter (ASM) components ......................4-21 ....................4-19 Alignment Method ..............................5-8 ............................... 4-20 ................................4-20 .....................................................
  • Page 166 ..............................Flat Fold ......................................................4-30 Folding the Planter ............................... 4-10 ..........................8-1 ..................................................2-3 ......................................................2-6 ................................2-9 ............................3-5 ..........................3-2 ............................3-12 ..........................5-21 ..........................4-35 ............................5-5 .......................... 4-18 ............................5-8 ..............................4-20 ..........................................
  • Page 167 ..............................2-8 Note to the owner ..............................1-1 ..............................1-1 ..............................4-32 ..............................Personal Protective Equipment (PPE) ........................2-5 ..............................2-1 .......................... 5-2 ........................................................................Planter lighting ..............................3-13 Planter Preparation ..............................4-1 Planter Preparation Frame Control ........................4-2 ............................
  • Page 168 ............................. 5-18 Titan Yieldtrac Front Fold Planter Bar overview ....................4-19 ..............................4-25 Torque – Fasteners ............................................................................. 4-22 ......................................................5-18 ........................................................5-18 ............................ Tractor Ballast ................................ 3-3 Tractor drawbar vertical load requirements ......................3-3 Tractor Remote Relief Pressure ..........................3-2 Tractor Requirements ............................
  • Page 170 11202 38th St S Horace, ND 58047...

This manual is also suitable for:

Yieldtrac 36r22

Table of Contents
