TECHNICAL DATA
MODEL
SKU
HOLDER
INPUT VOLTAGE
OUTPUT
DIMENSION
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
INSTRUCTION MANUAL
BOLLARD GARDEN LAMP
WITH 2 SOCKET
VT-1197
23403
G9 11W (Max)
AC: 220-240, 50Hz
16A/3600W (Max)
70x70x300mm
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
Advertisement
Related Manuals for V-TAC VT-1197
Summary of Contents for V-TAC VT-1197
- Page 1 70x70x300mm INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
-
Page 2: Installation Diagram
WARNING 1. Please make sure to turn off the power This marking indicates that this before starting the installation. product should not be disposed 2. Installation should be done by certified of with other household wastes. electrician. . 3 Proper grounding should be ensured Caution, risk of electric shock. -
Page 3: Installation Instruction
INSTALLATION INSTRUCTION 1. Connect the supply leads with terminal. 2. Open the lamp and install the bulb in the lamp 3. Drill holes on the ground and insert plastic expansion bolts in it. 4. Fix the base on the plastic expansion piece with self-tapping screws. 5.
