SUMMIT
VIDEO CONFERENCE WALLS
TM
Revised 16/07/24
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SUMMIT VIDEO CONFERENCE WALLS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Unicol SUMMIT VIDEO CONFERENCE WALLS

  • Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
  • Page 2: Tools Required

    01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED 3/16th, 4mm & 5mm Allen Keys Pozi Head Screwdriver 19mm Spanner 17mm Spanner COMPONENTS DESCRIPTION Inner Frame (inc. ScreenRail) Outer Leg Support Micro Adjustable Screen Arm (Pair of) Dedicated Sound/Video Bar Mount...
  • Page 3 01865 767676 sales@unicol.com www.unicol.com STEP 2 STEP 1 With the help of another person, remove the inner Affix the outer legs to the frame using M8x45 frame from the box and lay it flat (preferably on a screws, slotting them in from the top and tightening sturdy table where possible).
  • Page 4 01865 767676 sales@unicol.com www.unicol.com STEP 6 STEP 5 Slot the central frame between the bottom plate and With the help of another person, stand the Summit the bottom of the inner frame. Please ensure that frame upright, so that it is now freestanding on the the side with keyhole slots is facing the front of the floor.
  • Page 5 01865 767676 sales@unicol.com www.unicol.com STEP 10 STEP 9 Offer each fan support up to the rear of the outer In some cases, especially with screens over 75” frame, ensuring that the fans and cabling face the there may be a central door panel which will need rear and that the connecting cable runs along the fitting next.
  • Page 6 01865 767676 sales@unicol.com www.unicol.com STEP 13 STEP 14 Utilising the fixing pack provided with Populate the AV trays as necessary then fit them into your mount, attach the arms to the back of your the cabinet. To do this, ensure that the longer edges screen.
  • Page 7 01865 767676 sales@unicol.com www.unicol.com STEP 18 STEP 17 To adjust the screen within the frame alcove, use the Connect your device to mount plate. Each mount rear adjustment brackets to change both the depth is dedicated to your device so may vary from the and the vertical positioning of the screen (allowing image above.
  • Page 8 Any Questions? +44 (0)1865 767676 sales@unicol.com unicol.com/instructions...
