- Page 1 Universal screen mount/Universalhalterung PZX/PZW/KPL INSTRUCTION MANUAL / AUFBAUANLEITUNG...
- Page 2 Thank You! For choosing a UNICOL product which is designed and manufactured using state of the art technology and materials. According to our policy of steady development and improvement, we reserve the rights to make changes in specifications concerning equipment, material and design of this product at any time without notice.
- Page 3 if required use spacer (G) / falls nötig Abstandhalter (G) benutzen: screen/Bildschirm screw/Schraube arm/Arm Caution: Ensure all fittings are correctly tightened before screen is hooked on centrally! Achtung: Alle Schrauben müssen fest angezogen sein, bevor der Bildschirm mittig eingehängt wird! tighten M6x35 screws (C) for securing and adjusting screen –...
- Page 4 Parts/Teile: A: 1x back plate / Rückenplatte B: 2x arm / Arm C: 4x M6x35 D: 2x security tag / Sicherungsplatte Universal Fixing Kit contains: 2 x Griplock plates with tags (E) 2 x Griplock plates with 4 holes (F) 4 pairs of 2-part plastic spacers (G) 4 x M8 x 40 screws 4 x M8 x 35 screws...
