01865 767676
sales@unicol.com
www.unicol.com
SG3 / SG4 / SG5
Screen Size: 33 - 57"
Guide Max. Weight: 40-50kg per screen
Revised 16/07/24
*Please check model specific details before installing*
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
Advertisement
Related Manuals for Unicol SG3
Summary of Contents for Unicol SG3
- Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
- Page 2 INSTALLERS REQUIRED 4mm & 5mm Allen Keys Pozi Head Screwdriver 17mm Spanner COMPONENTS DESCRIPTION SG3 - Three Arm Gantry SG4 - Four Arm Gantry SG5 - Five Arm Gantry Heavy Duty Column Length CP5 Gantry Ceiling Plate Universal Screen Mount (PZW)
- Page 3 01865 767676 sales@unicol.com www.unicol.com STEP 1 STEP 2 Fix the CP5 ceiling plate into position via the 8 pre- Offer up the Spider Gantry of your choice to the defined fixing holes. other end of the column and thread into socket.
- Page 4 01865 767676 sales@unicol.com www.unicol.com STEP 6 STEP 5 Once centered, ensure the bottom screws are not Using another team member, lift the screen up and screwed tight and screw down the top screws to gradually offer it up to the back plate. Gently tilting level the screen.
