RACWDV30MC2
1500W 30L WET & DRY VACUUM CLEANER M-CLASS
OWNER'S OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RACWDV30MC2 and is the answer not in the manual?

Questions and answers

Related Manuals for Ryobi RACWDV30MC2

Summary of Contents for Ryobi RACWDV30MC2

  • Page 1 RACWDV30MC2 1500W 30L WET & DRY VACUUM CLEANER M-CLASS OWNER’S OPERATING MANUAL...
  • Page 2 Important! It is essential that you read the instructions in this manual before operating this machine. Subject to technical modifications...
  • Page 3 Don’t vacuum up liquids that are hotter than 60°C or any WORKSHOP VACUUM SAFETY WARNINGS poisonous or flammable dusts. Never lay the appliance on its side. Pay particular WARNING! attention to a horizontal position and adequate stability This appliance complies with the compulsory safety on stairs.

  • Page 4: Special Safety Rules

    Only store the appliance in a safe and dry location WARNING outside the reach of children. Always switch off and unplug the machine from the Please also pay particular attention to the following electrical outlet before assembling, opening, emptying “Special Safety Rules”. the dirt container, before connecting/disconnecting the This appliance is not intended for use by persons attachments, or carrying out maintenance or...

  • Page 5: Environmental Protection

    ENVIRONMENTAL PROTECTION Recycle raw materials instead of disposing of as waste. The machine, accessories and packaging should be sorted for environmental-friendly recycling. SYMBOL Safety Alert Volts Hertz Alternating Current Watts Regulatory Compliance Mark (RCM). Product meets applicable regulatory requirements. Please read the instructions carefully before starting the machine.
  • Page 6 Know Your Product 1. Stainless steel tube 15. Safety float valve 2. Universal floor nozzle 16. Washable HEPA12 cartridge filter 3. Anti-static crevice tool 17. ON/OFF/PTO switch 4. Anti-static dust brush 18. Connector for the vacuum hose 5. Anti-static hose 19.

  • Page 7: Packaging Content

    PACKAGING CONTENT Undo the locking latches, lift the top section off the tank and remove the accessories from inside the tank. ASSEMBLY Turn the tank upside down, and insert the casters onto the four feet of the tank. Ensure that they are pressed in firmly. Use the screws supplied and do not over tighten the screws.
  • Page 8 Lightly squeeze the ends of the hose retaining bracket together, then click them onto the motor housing. Insert the handle into the slots on the motor head and fasten into place. Insert the large end of the hose into the front inlet of the tank, then turn to lock it in place firmly.
  • Page 9 Floor nozzle Brush Squeegee Floor nozzle attachment Squeegee Brush Squeegee Brush Brush Squeegee FLOOR NOZZLE COMBINATIONS The floor nozzle comes supplied with additional attachments to ensure correct suction across different floor A: Brush and Squeegee Combination: For use with surfaces and applications. mixture of wet or dry liquids.

  • Page 10: Operation

    OPERATION POWER SWITCH Position Status Vacuum Operation ON Vacuum and PTO OFF Power Take-Off ON POWER TAKE-OFF (PTO) OPERATION WARNING Avoid overloading of the PTO outlet, ensure the tool is not rated over 900W Avoid underload, PTO outlet will not work with load under 100W The moment you switch on the power tool, the vacuum cleaner will also switch on.
  • Page 11 DRY VACUUMING-STANDARD APPLICATION WARNING 1. Firstly install the paper dust bag onto the inlet of the hose. BEFORE INSTALLING, REMOVING OR CLEANING 2. Carefully install the cartridge filter over the filter cage. THE VACUUM CLEANER FILTER, ENSURE THAT 3. Push the filter until it sits flush forming a tight seal. THE POWER CORD IS SWITCHED OFF AND UNPLUGGED.

  • Page 12: Wet Vacuuming

    WET VACUUMING WARNING WARNING BEFORE INSTALLING, REMOVING OR CLEANING The foam filter must be removed after wet vacuuming, THE VACUUM CLEANER FILTER, ENSURE THAT and a cartridge filter must be installed before dry THE POWER CORD IS SWITCHED OFF AND vacuuming again.
  • Page 13 M CALSS APPLICATION WARNING when using M class applications, appropriate PPE must be worn (eg. P2, OEL value etc) IMPORTANT! TO MAINTAIN M CLASS APPLICATION, THE VACUUM CLEANER MUST BE USE D WITH THE PLATIC DISPOSAL BAG. 1. Install the cartridge filter following the same procedure as the standard application. 2.
  • Page 14 FOR M CLASS Cartridge Filter + Dust Bag + Plastic disposal bag APPLICATION Cartridge Filter + Dust Bag FOR STANDARD APPLICATION Cartridge Filter FILTER AND BAG RECOMMENDATION IMPORTANT! The filter needs to be maintained regularly and dust bag needs to be emptied. Follow the instruction on page 7-9 on how to empty dust bag for WD dust and M Class Dust.
  • Page 15 SELF-CLEANING FILTER SYSTEM Self-Cleaning Filter System The Self-Cleaning function should be used regularly. How often The Self-cleaning needs to be carried out will depend on the type and quantity of dust that has been vacuumed. A clogged filter can trigger air flow reduction and cause press 3-4 times decrease of suction power.
  • Page 16 Cleaning Foam Filter (only for wet application) Carefully remove the foam filter from the filter cage. Use a mild soap and water solution to wash foam filter and rinse with clean water, air dry before next use. STORAGE Wind up the hose around the motor head and put it on the hose retaining bracket.

  • Page 17: Specifications

    SPECIFICATIONS Model No.: RACWDV30MC2 Supply Voltage: 220-240V ~ 50Hz Motor Power: 1500W Max Power Take Off: 900W Min Power Take Off: 100W Tank Capacity: Hose System: Ø35mm Filter - Dry Vacuum: Washable HEPA12 Cartridge Filter Filter - Wet Vacuum: Foam filter...

  • Page 18: Troubleshooting

    TROUBLE SHOOTING WARNING To reduce the risk of personal injury, unplug the cleaner before performing maintenance/troubleshooting checks. Problem Cause Solution The appliance doesn’t work Check the power supply. No power Check Overload Protection switch. Check if switch is in position II without appliance plugged in Functional fault in the power cord, switch, Have the damaged part checked by...
  • Page 19 DISCLAIMER - Techtronic Exposure to silica and other dust conditions can be a health risk. Organisations have legal responsibilities to protect the health of their workers. Techtronic Industries Australia Pty Ltd, (ACN 002 277 509) (TECHTRONIC) considers the safety of all users of our products to be of paramount importance.
  • Page 20 Techtronic Industries (Australia) Pty. Ltd. 31Gilby Road, Mt. Waverley, VIC 3149, Australia Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand...
