NuWave OXYPURE ZERO PLUS Quick Start Manual

Cleaning the Top Vent and In Flow Vent
The Top Vent of your OxyPure can be removed to clean with a
vaccum with a brush attachement or cleaned in mild soapy water and
dried thoroughly.
Depending on the environment the Oxypure is placed in, more
frequent cleaning may be needed.
1. Turn off and unplug the OxyPure.
2. Use a vacuum with a brush
attachment to remove any dust
and debris.
3. If needed, use a paper towel
or cloth slightly dampened to
remove heavier buildup. Do
not use any harsh abrasives
or cleaning pads on the Top
Vent or any other part of the
OxyPure.
To clean fan area or check for a
foreign object
1. Remove the screws as shown
and set on the magnetic strip.
2. Lift off the vent as shown.
3. Can wipe the side walls with a
cloth or duster.
4. Replace the vent and screws
Note: Careful to unscrew at the
small inner vent, as not to void the
warranty.
OXYPURE ZERO PLUS
®
OXYPURE ZERO PLUS
®
©2024 NuWave LLC • All Rights Reserved.
®
Item: BQ47602 • Rev.1-V3-JL • 07-03-24
Customer Service: For Amazon Purchases: support@nuwavenow.com ● For All Other Purchases: help@nuwavenow.com
Nu Wave
The OxyPure is equipped to operate using WI-FI. This allows you to conveniently
operate your new air purifier from nearly any location, whether at home or while
you are out and about, as long as you have a reliable Internet connection.
Download the NuWave Connect App
This is an optional feature that is not
required to operate your OxyPure.
Lift the Top Vent Using the QR reader in your Camera
App:
1. Scan the QR code below.
2. It will take you to the App's download
Downloading a QR reader App:
If your phone doesn't have that capability
built-in, simply download a 3rd-Party QR
Scanning App before scanning the NuWave
QR Codes and you are ready to go.
1. Open your devices' mobile app store
2. Search for "QR code readers."
3. Simply download the QR code reader to
Connect App (Optional)
®
page on either the Google Play Store or
the Apple AppStore, then just follow the
download and installation instructions.
(Apple App Store or the Google Play
Store).
your phone, open it, scan the code and
you are ready to go.
Wi-Fi
uto Scan Mode
A
1. Once you download the NuWave®
Connect app, ensure your phone is
connected to your home Wi-Fi network
on the 2.4GHz or 5GHz frequency and
that your phone's Bluetooth is on.
2. Turn on the OxyPure and activate Wi-Fi
Pairing Mode by pressing and holding
AUTO until the light next to the Wi-Fi
symbol begins to blink rapidly.
3. In the NuWave® Connect app, tap the +
symbol, then tap Auto Scan and select
your device.
4. Enter your Wi-Fi network's password
and tap Confirm. If the connection is
successful, the app will display "Added
Successfully" on the screen.
WiFi LED Status Light
Pairing Mode & Standby Mode
Solid Light.
The OxyPure is paired with the wifi
network and ready to be used.
Rapid Blinking Light.
The OxyPure is in Pairing Mode.
The OxyPure will stay in Pairing Mode for up
to 10 minutes or until your device is paired.
Slowly Blinking Light.
The OxyPure is in AP Pairing Mode.
