Extension board with 16-input
4.2
Unmounting the device from a mounting rail
Notice!
i
To remove the extension from a mounting rail, first remove all wired pluggable connectors.
Push down the extension until the lower edge snaps out of the mounting rail [1]. Pull the
lower end of the extension from the mounting rail [2].
Figure 4.2: Unmounting the AMC2 device on a mounting rail
Bosch Security Systems B.V.
1
2
Installation manual
Installation | en
11
2024-01 | V02 |
