Aircat PNEUMATIC TOOLS 809-SH Operating Instructions, Parts List & Warranty

3/8” sealed flat head ratchet

Download this manual

MODEL: 809-SH

3/8" Sealed Flat Head Ratchet

Need help?

Do you have a question about the PNEUMATIC TOOLS 809-SH and is the answer not in the manual?

Page 1 MODEL: 809-SH 3/8” Sealed Flat Head Ratchet...
Page 2 Important Warnings - Ratchets 1. Eye protection and hearing protection and safety gloves must always be worn when operating an impact wrench or impact driver. 2. When using heavy impact sockets or sockets on impact wrenches with 3/4” drive anvils or larger, a socket retaining ring and pin should be used to prevent the socket falling off and causing injury.
Page 3 MODEL: 809-SH 3/8” Sealed Flat Head Ratchet Exploded View & Parts List ITEM PARTS NO PARTS NAME ITEM PARTS NO PARTS NAME 12302-1010003-1 HOUSING 1230B-1010005-1 ADJUSTING ROD PINS 12305-1000001-1 VALVE PIN 1235P-1014701-1 RIGHT ADJUSTING ROD 12310-1014702-1 TRIGGER 1235P-1014702-1 LEFT ADJUSTING ROD 2040400-05100-0 SPRING PIN 2042400-00040-0...
Page 4 Florida Pneumatic Manufacturing Company (“Florida Pneumatic”) warrants that its AIRCAT and NITROCAT air tools will be free from defects in material and workmanship for a period of two years from the date of original purchase, except for our AIRCAT VIBROTHERM DRIVE air tools that are warrantied to be free from defects in material and workmanship for 3 years from the original date of purchase (the “Warranty Period”).
