Summary of Contents for Aircat Pneumatic Tools 1056-XL
- Page 1 MODEL: 1056-XL / 1076-XL 1/2” & 3/8” IMPACT WRENCH...
- Page 2 Important Warnings - Impacts 1. Eye protection and hearing protection and safety gloves must always be worn when operating an impact wrench or impact driver. 2. When using heavy impact sockets or sockets on impact wrenches with 3/4” drive anvils or larger, a socket retaining ring and pin should be used to prevent the socket falling off and causing injury.
- Page 3 MODEL: 1056-XL / 1076-XL 1/2” & 3/8” IMPACT WRENCH Exploded View & Parts List Ref. Ref. Part Number Description Part Number Description 9638001M AIR INLET 28 9651235 VALVE BODY 9638001M-BSP AIR INLET (UK) 29 9OR8501 O-RING 9638003 O-RING 30 9611238 REVERSE VALVE LEVER 9ORAS-115 O-RING...
- Page 4 Florida Pneumatic Manufacturing Company (“Florida Pneumatic”) warrants that its AIRCAT and NITROCAT air tools will be free from defects in material and workmanship for a period of two years from the date of original purchase, except for our AIRCAT VIBROTHERM DRIVE air tools that are warrantied to be free from defects in material and workmanship for 3 years from the original date of purchase (the “Warranty Period”).
