- Page 1 01234 3567ÿ ERGOFOCUS 93 321 9 HOLOGRAPHIK ÿ Installation and operation ÿ manual...
-
Page 2: Table Of Contents
Please read these instructions in full before installing. This appliance must be installed compliant to all applicable regulations. UNPACKING AND INSTALLING This manual concerns the following appliance: Operating instructions · Ergofocus Holographik INSTRUCTIONS FOR USE Maintenance MAINTENANCE INSTRUCTIONS Guarantee Recycling... -
Page 3: Warning
Warnings IMPORTANT SAFETY REGULATIONS TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR SERIOUS INJURY: WARNING To avoid the risk of electrocution, always disconnect the power supply This appliance must be connected to an electrical power supply that before handling. Contains no user serviceable parts. In the event of complies fully with the power specifications indicated on its identification malfunction, contact the supplier. -
Page 4: Technical Specifications
Technical Specifications cheminées contemporaines ERGOFOCUS HOLOGRAPHIK Input : 220-240V 50Hz Power : xxxW 26 W SN : XXXXXXX WARNING : Hazardous voltage inside Only authorized personnel may service this equipment EXPLODED VIEW HDMI Cable Câble HDMI Full HD Player Player Full HD... -
Page 5: Dimensional Drawing
Technical Specifications DIMENSIONAL DRAWING Ø 213/219 Ø 950 80°... -
Page 6: Installation Instructions
Installation instructions GENERAL INFORMATION ELECTRICAL CONNECTION To avoid damaging the fireplace, it should be unpacked and handled by Ensure that the power supply cable is disconnected from the mains supply two people. during the installation process. Package contents: The appliance should be installed by a qualified professional. - The appliance - Screen - Remote control unit... - Page 7 Installation instructions INSTALLATION 950 mm Fit the plate such that it is perfectly level. Fit a power supply cable with a female earthed connector at the end. Axe du foyer AVANT DU FOYER 1050 mm Attach the duct(s) following the tightening order shown Fit the rotation limiter onto the axis of the duct, as shown above, respecting the given height as shown.
- Page 8 Installation instructions ≤ 1 cm 28 mm AVANT DU FOYER Fit the rotation stop over the cross on the front of the hearth. Place the power supply cable inside the limiter using the supplied cable tie. 28 mm Fit the screen inside the fireplace. Connect the power supply cable and install the fireplace.
- Page 9 Installation instructions Connect the screen power supply cable. Connect the Jack cable to the screen. Connect the Player power supply cable. Install the screen by inserting the screws via the dedicated slots.
- Page 10 Installation instructions Adjust the screen such that it is parallel to the hearth opening. REAR HEARTH FRONT OF HEARTH FRONT HEARTH Place the logs as shown in the following steps.
- Page 11 Installation instructions LEFT RIGHT Place the ceramic logs as shown. Identify the ‘mirror finish’ side of the glass sheet.
- Page 12 Installation instructions Install the glass sheet with the “mirror finish” facing upwards. Place the base of the glass sheet against its support.
-
Page 13: Operating Instructions
Operating instructions INSTRUCTIONS FOR USE Set the O/I button to I to switch on. Set the O/I button to O to switch off. Volume control: hold the remote control as shown in the photo and press the “Vol + “ button to increase the volume or the “Vol - “ button to lower the volume. -
Page 14: Maintenance
The paintwork of the item may require retouching during its operational life. In this case, only use the Focus brand spray paint provided with the unit. ASSEMBLY... -
Page 15: Recycling
Recycling The presence of this logo on the product indicates that it is an appliance which should be disposed of compliant to the 2012/19/UE European directive concerning Waste Electrical and Electronic Equipment (WEEE), which states that used household appliances must be collected separately from household waste such that their different components can be recovered and recycled more effectively, thus reducing the environmental and human health impact of their disposal. -
Page 16: Appendix
DECLARATION OF CONFORMITY ATELIER DOMINIQUE IMBERT s.a.s. 3 Impasse Claque Patin F - 34380 Viols le Fort declares that the Ergofocus Holographik complies with the following directives: 2014/35/CE (DBT) 2014/30/CE (CEM) 2011/65/CE (RoHS) And with the essential requirements applicable to:... - Page 17 Notes...
- Page 18 Notes...
- Page 19 Notes...
- Page 20 Design - Publication - Distribution: Atelier dominique imbert S.A.S. (Simplified Corporation) with a capital value of 102,355 Euro 34380 Viols-le-Fort France Tel.: 00 33 (0)4 67 55 01 93 Web-site: www.focus-creation.com Email: info@focus-creation.com V.1 - March 2022...
