Operating Guide
Read this document when using the AK-MSU1000G Master Setup Unit in
conjunction with the AK-UB300G Series Multi-Purpose Cameras.
For details of operating Master Setup Unit AK-MSU1000G, please visit the
Panasonic website (http://pro-av.panasonic.net/en/manual/index.html), and
refer to the Operating Instructions (HTML or PDF).
W0817MN1107 -PS
  AK-MSU1000G
Model No.
Master Setup Unit
ENGLISH
DVQP1657YA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AK-MSU1000G and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic AK-MSU1000G

Summary of Contents for Panasonic AK-MSU1000G

  • Page 1 Master Setup Unit   AK-MSU1000G Model No. Read this document when using the AK-MSU1000G Master Setup Unit in conjunction with the AK-UB300G Series Multi-Purpose Cameras. For details of operating Master Setup Unit AK-MSU1000G, please visit the Panasonic website (http://pro-av.panasonic.net/en/manual/index.html), and refer to the Operating Instructions (HTML or PDF).

  • Page 2: Table Of Contents

    Table of Contents Connecting the Unit to AK-UB300G Series Cameras Connection example Connections Compatible Functions List MSU menu (when AK-UB300G is connected) MSU menu list PAINT 1 PAINT SW 2 SHUTTER SPEED 3 PED 4 CHROMA 5 RB GAIN 6 COLOR TEMP 7 FLARE 8 GAMMA 9 BLACK GAMMA...

  • Page 3: Connecting The Unit To Ak-Ub300G Series Cameras

    Connecting the Unit to AK-UB300G Series Cameras Connecting the Unit to AK-UB300G Series Cameras NOTE The descriptions in this document assume that the system version of the unit is V4.40-00-0.00 or later. Make sure that the system version of the AK-UB300G used in conjunction with the unit is V7.52-000-00.00 or later. Connection example This is a connection example for connecting one AK-UB300G and one unit.

  • Page 4: Connections

    Connecting the Unit to AK-UB300G Series Cameras Connections Set the connection setting to [LAN(AW)] in the [CONNECT SETTING] menu of [SYSTEM]. When connecting, observe the following points. Connect the [LAN] connector on this unit to the <LAN> terminal on the AK-UB300G using a LAN cable (sold separately). Configure the camera IP address and port number settings of the connection destinations in [CAMERA IP SETTING] as well.

  • Page 5: Compatible Functions List

    Connecting the Unit to AK-UB300G Series Cameras Compatible Functions List When the unit is used in conjunction with an AK-UB300G Series Multi-Purpose Camera, there will be functions that are limited or disabled for some of the unit’s buttons, dials, and other controls. Be sure to refer to the following table. NOTE The descriptions in this document assume that the system version of the unit is V4.40-00-0.00 or later.
  • Page 6 Connecting the Unit to AK-UB300G Series Cameras ✓ : Enabled Number Part name Remarks ×: Disabled ✓ [FLARE OFF] button Enabled starting with the following system version. AK-UB300G: V7.52-000-00.00 This unit: V4.40-00-0.00 ✓ [B.GAMMA ON] button Enabled starting with the following system version.
  • Page 7 Connecting the Unit to AK-UB300G Series Cameras ✓ : Enabled Number Part name Remarks ×: Disabled [MONITOR R, G, B, SEQ, ENC] (monitor × switching) buttons [HEAD] button × [ECC] button × Front panel 4 ✓ [ND] indicator ✓ [1] to [5] (ND filter selection) buttons Only [1] to [4] are enabled for ND filters.
  • Page 8 Connecting the Unit to AK-UB300G Series Cameras ✓ : Enabled Number Part name Remarks ×: Disabled [(MPED) MEMO] button × [(MPED) RECALL] button × ✓ [MPED] display ✓ [ACTIVE] button ✓ Camera number/tally display ✓ [AUTO] button ✓ [COARSE] button [(IRIS) MEMO] button ×...

  • Page 9: Msu Menu (When Ak-Ub300G Is Connected)

    MSU menu (when AK-UB300G is connected) MSU menu (when AK-UB300G is connected) MSU menu list When an AK-UB300G Multi-Purpose Camera is connected, the MSU menu will be as follows. NOTE The descriptions in this document assume that the system version of the unit is V4.40-00-0.00 or later. Make sure that the system version of the AK-UB300G used in conjunction with the unit is V7.52-000-00.00 or later.
  • Page 10 MSU menu (when AK-UB300G is connected) “R GAMMA” (see page 20) R GAMMA B GAMMA “B GAMMA” (see page 20) MASTER “MASTER” (see page 20) GAM MODE “GAM MODE” (see page 20) “B.STRETCH” (see page 20) 8 GAMMA B.STRETCH “DYNAMIC” (see page 20) DYNAMIC “K.POINT”...
  • Page 11 MSU menu (when AK-UB300G is connected) “MEM SEL” (see page 23) MEM SEL CURSOR “CURSOR” (see page 23) POS H “POS H” (see page 23) POS V “POS V” (see page 23) “SKIN GET” (see page 23) SKIN GET “ZEBRA” (see page 23) ZEBRA “EFFECT”...
  • Page 12 MSU menu (when AK-UB300G is connected) “TABLE” (see page 25) TABLE CORR TBL “CORR TBL” (see page 25) CORRECT “CORRECT” (see page 25) “SAT” (see page 25) “PHASE” (see page 25) PHASE “SAT G” (see page 25) SAT G “PHS G” (see page 25) PHS G “SAT CY_G”...
  • Page 13 MSU menu (when AK-UB300G is connected) “B.GAMMA R” (see page 28) B.GAMMA R B.GAMMA B “B.GAMMA B” (see page 28) B.GAMMA M “B.GAMMA M” (see page 28) B.GAMM SW “B.GAMM SW” (see page 28) “KNEE PINT” (see page 28) KNEE PINT “KNEE SLPE”...
  • Page 14 MSU menu (when AK-UB300G is connected) This is not used when connected with an AK-UB300G. 1 CCU MENU CNT (“---” is displayed for the parameter of each item.) “MENU” (see page 31) MENU “CURSOR” (see page 31) 2 CAMERA MENU CURSOR “EXECUTE”...
  • Page 15 MSU menu (when AK-UB300G is connected) “FORMAT” (see page 32) FORMAT G.LCK IN “G.LCK IN” (see page 32) 1 CAMERA G.LCK CRS “G.LCK CRS” (see page 32) G.LCK FNE “G.LCK FNE” (see page 32) “SHOOTING” (see page 32) SHOOTING 2 CCU This is not used when connected with an AK-UB300G.

  • Page 16: Paint

    MSU menu (when AK-UB300G is connected) PAINT 1 PAINT SW Item Setting details MATRIX Enables/disables matrix (linear matrix/12-axis color correction). LINEAR.M Enables/disables linear matrix. C.CORR Enables/disables 12-axis color correction. SKIN DTL Enables/disables the skin tone detail. Enables/disables the detail. Enables/disables the noise reduction function. D.HAZE Enables/disables the haze reduction function.

  • Page 17: Shutter Speed

    MSU menu (when AK-UB300G is connected) 2 SHUTTER SPEED Item Setting details STEP Sets the shutter speed. SYNCHRO The setting cannot be set. SWITCH Enables/disables the shutter function. MODE Selects the operation mode of the shutter. 3 PED Item Setting details R PED Sets the correction level of red to the master pedestal.

  • Page 18: Chroma

    MSU menu (when AK-UB300G is connected) 4 CHROMA Item Setting details LEVEL Adjusts the chroma gain when [LEVEL SW] is set to [ON]. LEVEL SW Enables/disables the gain adjustment of chroma. 5 RB GAIN Item Setting details Sets the correction level of red to the gain. Sets the correction level of blue to the gain.

  • Page 19: Color Temp

    MSU menu (when AK-UB300G is connected) 6 COLOR TEMP Item Setting details TEMP Sets color temperature settings. 7 FLARE Item Setting details R FLARE Adjusts the Rch flare. G FLARE Adjusts the Gch flare. B FLARE Adjusts the Bch flare. M FLARE Adjusts the master flare.

  • Page 20: Gamma

    MSU menu (when AK-UB300G is connected) 8 GAMMA Item Setting details R GAMMA Adjusts the red gamma characteristic for the master gamma. B GAMMA Adjusts the blue gamma characteristic for the master gamma. MASTER Adjusts the gamma characteristic. GAM MODE Sets the gamma characteristic type.

  • Page 21: Knee

    MSU menu (when AK-UB300G is connected) 10 KNEE Item Setting details R POINT % Adjusts the red knee point for [POINT MASTER]. B POINT % Adjusts the blue knee point for [POINT MASTER]. M.POINT % Sets the knee point position. R SLOPE Adjusts the red knee slope for [SLOPE MASTER].

  • Page 22: Dtl

    MSU menu (when AK-UB300G is connected) 11 DTL Item Setting details MASTER Adjusts the level of master detail. H LEVEL Adjusts the level of horizontal detail. V LEVEL Adjusts the level of vertical detail. PEAK FRQ Sets the peak frequency of the horizontal detail. VDTL FRQ Sets the vertical detail frequency.

  • Page 23: Skin Dtl

    MSU menu (when AK-UB300G is connected) 12 SKIN DTL Item Setting details MEM SEL Selects the skin tone table for the subject to apply the skin tone detail to. CURSOR Enables/disables the position cursor that obtains the saturation and color phase information for controlling skin tone detail effects.

  • Page 24: Matrix

    MSU menu (when AK-UB300G is connected) 13 MATRIX Item Setting details TABLE Selects the table for linear matrix. CLR CORR Selects the table for color correction. R-G P Adjusts the linear matrix between red and green. R-G N Adjusts the linear matrix between red and green. R-B P Adjusts the linear matrix between red and blue.

  • Page 25: Color Corre

    MSU menu (when AK-UB300G is connected) 14 COLOR CORRE Item Setting details TABLE Selects the table for linear matrix. CORR TBL Selects the table for color correction. CORRECT Selects the color component in 12-axis matrix memory to adjust. Adjusts the saturation of the color component selected in [CORRECT]. PHASE Adjusts the hue of the color component selected in [CORRECT].
  • Page 26 MSU menu (when AK-UB300G is connected) Item Setting details SAT CY_G Adjusts the color saturation between cyan and green. PHS CY_G Adjusts the hue between cyan and green. SAT CY Adjusts cyan color saturation. PHS CY Adjusts cyan hue. SAT B_CY Adjusts the color saturation between blue and cyan.

  • Page 27: Skin Corre

    MSU menu (when AK-UB300G is connected) 15 SKIN CORRE Item Setting details Finely adjusts the hue of the skin tone area. TONE Finely adjusts the tone of the skin tone area. SWITCH Enables/disables the function to finely adjust the color of the skin tone area. TABLE Selects the table for the skin tone area.

  • Page 28: Hdr Paint

    MSU menu (when AK-UB300G is connected) 17 HDR PAINT Item Setting details B.GAMMA R Adjusts the red gamma characteristic near black for the master gamma. B.GAMMA B Adjusts the blue gamma characteristic near black for the master gamma. B.GAMMA M Adjusts the gamma characteristic near black.

  • Page 29: Function

    MSU menu (when AK-UB300G is connected) FUNCTION 1 SYSTEM CAM Item Setting details CROP OUT Sets the crop output image during cropping. MARKER Sets the crop frame to display during cropping. CROP ADJ Sets the crop frame to adjust the position during cropping. CROP H % Sets the horizontal position of crop during cropping.

  • Page 30: Haze Clear

    MSU menu (when AK-UB300G is connected) 3 D.HAZE CLEAR Item Setting details LEVEL Sets the level of the haze elimination. The larger the value, the stronger the haze elimination effect. SWITCH Enables/disables the haze elimination function. - 30 -...

  • Page 31: Maintenance

    MSU menu (when AK-UB300G is connected) MAINTENANCE 1 CCU MENU CNT This is not used when connected with an AK-UB300G. (“---” is displayed for the parameter of each item.) 2 CAMERA MENU Item Setting details MENU Turns the menu on or off. CURSOR Moves the menu cursor or changes setting values.

  • Page 32: System

    MSU menu (when AK-UB300G is connected) SYSTEM 1 CAMERA Item Setting details FORMAT Displays the system format. (This cannot be changed.) G.LCK IN Sets whether the synchronization signal is inputted from BNC or from D-SUB. G.LCK CRS Roughly adjusts the phase of horizontal synchronization. G.LCK FNE Finely adjusts the phase of horizontal synchronization.

  • Page 33: Connect Setting

    MSU menu (when AK-UB300G is connected) 3 CONNECT SETTING Item Setting details CAM1 Sets the connection method for camera 1. The settings are applied when [UPLOAD] is selected after changing the settings. Select [LAN(AW)] when connecting to the AK-UB300G series. CAM2 to 99 Sets the connection method for cameras 2 to 99.

  • Page 34: Cam Ip Setting

    MSU menu (when AK-UB300G is connected) 4 CAM IP SETTING For details on operations and settings, refer to the following sections in the Operating Instructions. “SYSTEM - 4 CAM IP SETTING” 5 MSU IP SETTING For details on operations and settings, refer to the following sections in the Operating Instructions. “SYSTEM - 5 MSU IP SETTING”...
