- Page 1 QUICK GUIDE EOC990 Sewing Machine...
-
Page 2: Check Accessories
Check accessories All accessories are in the accessories box Standard accessories: Needle*3 Twin needle*1 Bobbin*3 Thread*4 Ripper/brush*1 Screwdriver for needle plate*1 Auxiliary spool pin*1 Spool pin cap*1, Small screwdriver*1 Presser feet*8 ( universal presser foot / hemmer foot / zipper foot / blind stitch foot / buttonhole foot / embroidery free motion foot / button presser foot / guide presser foot ) Check the built-in bobbin... - Page 3 Note:The bobbin turns clockwise in the bobbin case. Installing the bobbin and bobbin case Installing the bobbin When you pull the thread, the bobbin should spin clockwise. Note: Leave about 10cm (4 inches) of the thread hanging out of the bobbin case.
-
Page 4: Threading The Machine
Threading the machine Until the thread take-up lever is raised please read the automatic needle threader on the next page Note：Pass the thread through the eye of the needle from the front. For the convenience of threading, you can use scissors to cut off the excess thread. -
Page 5: Using Automatic Needle Threader
Using automatic needle threader Note: When using the automatic needle threader, please adjust the needle to the highest position, otherwise the automatic needle threader will be damaged. Note: Automatic needle threader cannot be used for double needle. When using automatic threading, the needle should be at a high position. -
Page 6: Twin Needle
Twin needle Note: If you are testing a single needle, please skip this step. Left needle Right needle thread thread Right needle thread Left needle thread Note: Thread the left needle thread first then thread the right needle thread. Make sure that the left thread run anticlockwise, and the right thread run clockwise. - Page 7 Place the fabric under the presser foot,put down the presser foot. When you have finished, remove your foot from the foot controller, then the sewing machine will stop. needle in its highest position Pull the fabric and threads about 6inch (15cm) backward, then cut threads with the thread cutter from back to front.
-
Page 8: Selecting Stretch Stitch Patterns
Selecting stretch stitch patterns Pattern knob selection D Set the stitch length knob to the "S1" position. (“S1” and “S2” settings are the same.) When the length of the pattern is to be extended, adjust the stitch length knob to the "+" direction. When the length of the pattern needs to be reduced, the stitch length knob should... -
Page 9: Troubleshooting
Troubleshooting 1.Machine not working Bobbin winder shaft needs to push to the left. Keep the bobbin lever to the left while sewing and push the bobbin winder lever to the right when winding the bobbin. Sewing thread wrapped around Spool pins. If the thread is entangled on the Spool pins, the thread cannot be fed, you need to clean the sewing threads to make sure they feed smoothly. - Page 10 The fabric is too soft, thin or elastic. Please put a piece tear away stabilizer under the fabric, and increase stitch length (Adjust the stitch length knob to 3 or 4) Needle is bent or blunt. Check your needles for bent or blunt and replace them promptly. (Please refer to page 10 of the instruction manual for needle replacement.) The threads are not drawn to the rear after finishing sewing.
- Page 11 The tension of the bobbin thread is too tight. Remove the bobbin case with the bobbin from the machine, then hold the thread and let the bobbin case hang down naturally,to test the tension of the bobbin. Stiff or thick fabric is sewn, but the needle size does not suit the fabric Please read the needle and fabric options.
- Page 12 CONTACT US E-mail PoolinService@richword.com Whatsapp +86 189 0063 0275 +86 189 0063 3167 Facebook Poolin Users Group Youtube PooLin sewing machine...
